Himpel Zeroc FZA-L110S User Manual

Led lighting ventilation fan

Hide thumbs

Table of Contents

Quick Links

Download this manual

Made in Korea

User Manual

Thanks for your purchase of a product of HIMPEL Co., Ltd.

Please read this instruction manual carefully before use so that you may

use the product long, more conveniently and safely.

You must read

Cautions for Safe before use and use the product correctly.

Model: FZA-L110S

☞

For more detailed information of service request or any inquiry,

please contact purchasing place.

Table of Contents

Need help?

Do you have a question about the Zeroc FZA-L110S and is the answer not in the manual?

Questions and answers

Summary of Contents for Himpel Zeroc FZA-L110S

Page 1 Made in Korea User Manual Thanks for your purchase of a product of HIMPEL Co., Ltd. Please read this instruction manual carefully before use so that you may use the product long, more conveniently and safely. You must read Cautions for Safe before use and use the product correctly.
Page 2 Instructions for Safety This manual covers safety instructions, installation methods, etc. for bathroom ventilation fans that we manufacture and sell. Please read the instructions, operation and how to check in this user manual carefully and then use the product. This product is a ventilation system to discharge contaminated air in a bathroom and toilet of buildings such as an apartment house, a multipurpose building, commercial buildings, offices and it is a product to realize a comfortable indoor environment by constantly discharging contaminated air.
Page 3 Caution Please check if the Do not use it for the direct installation of ceiling support discharge in a place where and brace bar is correct. there are a lot of fumes. Due to poor installation of a The life of the product may be product, the product may fall.
Page 4 Installation of the Product This product is a unit which is installed on the ceiling in the interior space of the room to exhaust contaminated air to the outside. This product should be installed on the ceiling surface 2-3m high from the floor, so please be careful of the product safety to prevent it from crashing or falling during the installation of the product.
Page 5 Product Specifications Product Static Pressure Ventilation Fan LED Lighting (Zeroc) Model FZA-L110S Power consumption Ventilation fan: 40W / Lighting: 9W Illumination 130~150Lux Size of opening 235*235mm (±5mm) ※ The specifications and performance of the product are subject to change without notice to improve the quality. Precautions when using the product In the event of strange sound, odor or smoke when using the product, please turn off the main power...
Page 6 Product Specifications Grill Dimensions Product Dimensions □230 Checklist Prior to Reporting Faults Status Causes Corrective Actions 1. Blackout Please wait until the power is turned on. Please make sure that fan switch is in -operating 2. The power switch is off. the ON position.
Page 7 MEMO...
Page 8 HIMPEL CO., LTD Head Office / Factory 183-1 Annyeong-dong, Hwaseong-si, Gyeonggi-do, Korea E-mail : sales@himpel.co.kr For more services and consultation, please contact the purchasing place...
