Panasonic DMP-BDT270 Basic Owner's Manual

Basic Owner's Manual
TM
Blu-ray Disc
Unless otherwise indicated, illustrations in these Model No. DMP-BDT270
Owner's Manual are of DMP-BDT270.
DMP-BD93
Firmware updates
Panasonic is constantly improving the unit's firmware
to ensure that our customers are enjoying the latest
technology.
Panasonic recommends updating your firmware as
soon as you are notified.
If you have any questions, visit :
U.S.A. : www.panasonic.com/support
Canada : www.panasonic.ca/english/support
Register online at www.panasonic.com/register SQT0698-1
P PC (U.S. customers only) F1214JY1124
Thank you for purchasing this product. Accessories
Please read these instructions carefully before using
this product, and save this manual for future use.
Check the supplied accessories before using this unit.
A more detailed owner's manual is available in 1 Remote control
"Owner's Manual (PDF format)". To read it,
(N2QAYB001023)
[BDT270]
download it from the website.
(N2QAYB001024)
[BD93]
http://av.jpn.support.panasonic.com/support/
2 Batteries for remote control
global/cs/bd/oi/index.html
1 AC power supply cord
[BDT270]
(K2CB2YY00092)
1 AC adaptor (SAE0001)
[BD93]
[For_Canada]
The enclosed Canadian French label sheet corresponds to the
English display on the unit.
≥ Product numbers are provided in these Owner's Manual correct
as of December 2014. These may be subject to change.
You will need Adobe Reader to browse or print the ≥ Do not use AC power supply cord and AC adaptor with other equipment.
≥ Do not use any other AC power supply cords and AC adaptors
Owner's Manual (PDF format).
except the supplied one.
You can download and install a version of Adobe
Using the remote control
Reader that you can use with your OS from the
following website. (As of December 2014)

http://www.adobe.com/products/acrobat/
readstep2.html

R6/LR6, AA
(Alkaline or manganese
batteries)
– Insert the batteries to the terminal so that it (i and j)
matches those in the remote control.
Control reference guide
1 Turn the unit on and off
1 2 11 22
10 2 TV operation buttons
[BD93]
You can operate the Panasonic TV using this unit's remote
11
control. Some buttons may not work depending on the TV.
1
[Í TV] : Turn the TV on and off
2
12
[AV] : Change input
13
[i j VOL] : Adjust the volume
14
3 3 Select title numbers, etc./Enter numbers or
15 characters
[BDT270]
16
4 Cancel
4
5 Basic playback control buttons
5 6 Show Closed Caption setup screen
4 3 14 16 12
7 Show Pop-up menu/Top menu
8 Show Option menu
6 17
9 Colored buttons (red, green, yellow, blue)
18
Used for various purposes depending on the display.
19
7 10 Transmit the remote control signal
20 11 Open or close the disc tray
12 Show the status messages
8 21
13 Switch Secondary Video on/off (Picture-in-
[BDT270]
picture)
9
14 Change soundtrack
TM
15 Show Miracast screen
[BDT270]
16 Show the Home Screen of Network Service
17 Exit the Menu screen
18 Show Netflix screen
19 Show HOME menu
20 [3, 4, 2, 1] : Move the highlight for selection
[OK] : Confirm the selection
(;1) : Frame-by-frame
21 Return to previous screen
22 Show Setup menu
[BD93]
[BDT270]
5 6 7 8
1 2 3 4
[BD93]
5 8
1 4 3 2
1 Disc tray
5 Open or close the disc tray
2 USB port
6 Stop
[BDT270]
3 POWER LED
7 Start play
[BDT270]
The LED lights when the unit is turned on, and
8 Standby/on switch (Í/I)
flashes when error occurs.
Press to switch the unit from on to standby mode
4 Remote control signal sensor
or vice versa. In standby mode, the unit still
Distance: Within approx. 7 m (23 feet)
consumes a small amount of power.
Angle: Approx. 20e up and down, 30e left and right
until
2014/12/23
Quick Start Guide
STEP 1 : Connecting to a TV
Player
[BDT270] [BD93]
[BDT270]
HDMI cable
[BD93]
AC adaptor (supplied)
To an AC outlet
AC power supply cord (supplied)
This unit consumes a small amount of AC power ( "Specifications") even when turned off in standby mode.
For the purpose of energy conservation, the unit should be disconnected if you will not be using it for
extended period of time.
STEP 2 : Connecting to the network
∫ Wireless LAN connection
Wireless router, etc.
[BDT270]
∫ LAN cable connection
Broadband router, etc.
LAN Cable
Use category 5 or above straight LAN cables (STP) when connecting to peripheral devices.
STEP 3 : Settings
1 2 HDMI
HDMI
TV
Turn on the TV and select the appropriate video Press [Í/I].
input. Follow the on-screen instructions to continue with
the settings.
STEP 4 : Playback
1 2
Insert the media. Press [OK] or [3, 4, 2, 1] to select the item.
≥ If there are any other items, repeat this step.
Operating during playback
The following functions may not work depending on the media and contents.
The stopping point is memorized.
Resume play function
Stop Press [∫STOP].
Press [1PLAY] to restart from this point.
≥ The point is cleared if the media is removed.
Pause Press [;PAUSE]. Press [;PAUSE] again or [1PLAY] to restart play.
HDMI IN
While playing, press [SEARCH6]
Search
or [SEARCH5].
The speed increases up to 5 steps.
≥ Press [1PLAY] to revert to normal playback speed.
While paused, press
Slow-motion
[SEARCH5].
While playing or paused, press
Skip Skip to the title, chapter or track.
[:] or [9].
Playable media
BD-Video : Video
BD-RE : Video,
1
JPEG, MPO* ,
1
AAC, ALAC, DSD* , FLAC, MP3, WAV, WMA
2
BD-R : Video, MKV, Xvid* ,
1
AAC, ALAC, DSD* , FLAC, MP3, WAV, WMA
DVD-Video : Video
2
DVD-R/DVD-R DL : Video, AVCHD, MKV, Xvid* ,
1
JPEG, MPO* ,
1
AAC, ALAC, DSD* , FLAC, MP3, WAV, WMA
DVD-RW/+R/+RW/+R DL : Video, AVCHD
Music CD : Music [CD-DA]
2
CD-R/CD-RW : MKV, Xvid* ,
1
JPEG, MPO* ,
AAC, ALAC, FLAC, MP3, Music [CD-DA], WAV, WMA
2
USB devices (up to 4 TB) : MKV, MP4, MPEG2, Xvid* ,
Internet
1
JPEG, MPO* ,
1
AAC, ALAC, DSD* , FLAC, MP3, WAV, WMA
∫ Region management information
The unit can play back BD-Video/DVD-Video discs of the following regions codes, including "ALL":
Example: BD-Video DVD-Video
1
≥ The unit cannot playback discs in PAL format.
*1
[BDT270] o nly
Internet *2
Canada only
Firmware updates
Occasionally, Panasonic may release updated DO NOT DISCONNECT the unit from the AC
power or perform any operation while the update
firmware for this unit that may add or improve the
takes place.
way a feature operates. These updates are
After the firmware is installed, unit will restart and
available free of charge.
the following screen will be displayed.
This unit is capable of checking the firmware e.g.,
automatically when connected to the Internet via a
broadband connection.
When a new firmware version is available, the
following message is displayed.
Firmware Update
New Version: X.XX
Current Version: X.XX ≥ To show the firmware version on this unit;
Do you want to start firmware update? [BDT270]
For the update information, please visit the "System Information"
following website: [BD93] [SETTINGS]
http://panasonic.jp/support/global/cs/
"Firmware Version Information"
≥ Downloading will require several minutes. It may take
Yes No
longer or may not work properly depending on the
OK connection environment.
≥ If you do not want to check for the latest firmware version,
RETURN
set "Automatic Update Check" to "Off".
You can also download the latest firmware from the [BDT270]
"Firmware Update"
following website and store it to a USB device to
[BD93] [SETTINGS]
update the firmware.
http://panasonic.jp/support/global/cs/
(This site is in English only.)
Specifications
[BDT270] AC 120 V, 60 Hz
Power supply [BD93] DC 12 V, 0.8 A (DC IN Dimensions
terminal) (WkHkD)
Power [BDT270] Approx. 13 W
consumption Approx. 11 W
[BD93]
Mass (Weight)
Power
consumption in Approx. 0.5 W
≥ Specifications are subject to change without notice.
standby mode
Power consumption
[BDT270] Approx. 5 W
in quick start
[BD93] Approx. 3.5 W
standy mode
The firmware was updated.
Current Version : x.xx
RETURN
[HOME] "Setup" "Player Settings" "System"
"Firmware Version Information"
"System" "System Information"
[HOME] "Setup" "Player Settings" "System"
"System" "Firmware Update"
[BDT270] 312 mmk43 mmk180 mm
(Approx. 12 5/16 zk1 11/16 zk7 2/16 z)
[BD93] 245 mmk38.5 mmk175 mm
(Approx. 9 10/16 zk1 8/16 zk6 14/16 z)
Approx. 1.0 kg (2.2 lbs)
[BDT270]
Approx. 0.8 kg (1.7 lbs)
[BD93]
