Summary of Contents for Light Blue Optics LT1021FC
- Page 1 User Guide Light Touch Virtual Touch-Screen Computer LT1021 Series For models: LT1021FC/MG/RG Light Touch LT1021 Series – User Guide v2.1 | Page 1...
-
Page 2: Table Of Contents
Contents Package Contents ................... 3 Introducing Light Touch™ ................4 Safety Notice ....................5 The Basics ......................6 Getting Started .................... 6 Demonstration Applications ..............6 Light Touch Settings ..................7 System Information ..................8 ... -
Page 3: Package Contents
Package Contents The following items should be included in the package • 1 x Light Touch (LT1021FC) • 1 x International Power Adaptor (220/110V AC to 5V DC) • 1 x USB Cable (Full-size Type A to Micro Type B) •... -
Page 4: Introducing Light Touch
Microsoft .NET CF 3.5. Light Touch has wireless networking capability and is ideally suited to running applications that connect to the internet or cloud-based servers. Light Touch model LT1021FC is supplied in a plastic outer shell, designed for standalone operation. Figure 1 – Light Touch Light Touch LT1020 –... -
Page 5: Safety Notice
UNDER NO CIRCUMSTANCE shall attempts be made to operate this device when it is damaged or disassembled. Return it to the manufacturer for repair or replacement. All service to the product shall be performed by Light Blue Optics Ltd., their authorised agents, or personnel trained by Light Blue Optics Ltd. -
Page 6: The Basics
Figure 2 – Screenshot of carousel menu The pre-loaded applications are provided for demonstration purposes only. Please contact Light Blue Optics for further information if required, including enquiries about obtaining permission to use part or all of one of these applications in a commercial product. -
Page 7: Light Touch Settings
Light Touch Settings The user can configure Light Touch via the ‘Settings’ section of the menu carousel. Figure 3 – Screenshot of ‘Settings’ icon in menu Within the ‘Settings’ menu, the following categories are accessible: • System Information (‘About’) • Power Management •... -
Page 8: System Information
System Information The ‘About’ screen can be accessed from within the ‘Settings’ category: Figure 4 – Screenshot of ‘About’ icon within ‘Settings’ menu The ‘About’ screen contains information about the hardware and software versions. The serial number is the unique identifier for the unit. Figure 5 –... -
Page 9: Power Management
Power Management The ‘Power Management’ control panel can be accessed from within the ‘Settings’ category: Figure 6 – Screenshot of ‘Power Management’ icon within ‘Settings’ menu The ‘Power Management’ control panel allows the user to put Light Touch into a ‘display-off’ mode after a period of inactivity. To activate this mode, the ‘Display Off Time’... - Page 10 The virtual keyboard can switch between three screens by pressing the mode key (marked as *%123) in the image below Figure 8 – Screenshot of selecting a value in power management control panel When the desired value has been entered, press the enter key to return (the right-hand button on the second line up) Light Touch LT1020 –...
-
Page 11: Wireless Networking
Wireless Networking Light Touch has inbuilt wireless networking support for 802.11 b/g. The following encryption standards are supported: • • • WPA2 – TKIP • WPA2 – AES The wireless networking control panel can be accessed from within the ‘Settings’ category: Figure 9 –... - Page 12 The virtual keyboard can switch between three screens by pressing the mode key (marked as *%123) in the image below. When the code has been entered, press the green arrow button to connect. Figure 11 – Screenshot of entering network access code At the main screen of the wireless networking control panel, the status of the connection will be displayed.
- Page 13 The manual configuration screen, as shown below, allows network parameters to be set explicitly. Figure 13 – Screenshot of manual configuration within wireless networking control panel The virtual keyboard is used to enter the network name and security code. Light Touch LT1020 – User Guide v1.1 – Application Release C1.0.0 | Page 13 Light Touch LT1021 Series –...
-
Page 14: Usb Mode
USB Mode Light Touch can be connected to a host machine via a USB cable that plugs into the USB Micro-B port. The USB Mode control panel can be accessed from the ‘Settings’ menu: Figure 14 – Screenshot of ‘USB Mode’ icon within ‘Settings’ menu The default USB mode is ‘ActiveSync’... - Page 15 There are two different mass storage modes because Light Touch contains two separate memories that are accessible to the user. The ‘internal’ Flash memory has a capacity of 2GB and is present at all times. The ‘micro-SD’ Flash memory is an optional memory card that may be fitted into the device via the external micro-SD card slot.
-
Page 16: Support
Table 1 – List of potential problems and respective solutions Support Desk If you should require support with your Light Touch product, please contact the support desk at Light Blue Optics at: support@lightblueoptics.com The LBO support team will endeavour to respond to your enquiry within 2 working days Light Touch LT1020 –... -
Page 17: Appendix A - Activesync Usb Setup For Windows Xp
Appendix A – ActiveSync USB Setup for Windows XP 1) Connect Light Touch™ to mains power, turn it on and connect to a host PC via a USB cable. The PC will auto-detect the presence of the unit and launch the following dialogue window as shown in Figure 18. Figure 18 - Hardware Update Wizard (Step 1) 2) Select the option ‘No, not this time’... - Page 18 3) Select the option ‘Install from a list or specific location (Advanced). The window as shown in Figure 20 will appear. Figure 20 - Hardware Update Wizard (Step 3) 4) Insert the Start-up CD in the Light Touch™ pack. Browse and select the directory as shown in Figure 21.
- Page 19 6) Power cycle Light Touch™ and then run ActiveSync software on the host PC. The PC will automatically detect Light Touch and to the following window appear, as shown in Figure 22. Figure 22 – Opening ActiveSync Connection (Step 1) 7) Select the option ‘No’...
- Page 20 8) Browse the InternalFlash directory on Light Touch ™ as shown in Figure 24. Files can then be modified, uploaded or downloaded as required. Figure 24 - Opening ActiveSync Connection (Step 3) Light Touch LT1020 – User Guide v1.1 – Application Release C1.0.0 | Page 20 Light Touch LT1021 Series –...
-
Page 21: Appendix B - Activesync Usb Setup For Windows Vista/7
Appendix B – ActiveSync USB Setup for Windows Vista/7 To install the Light Touch on Windows 7 or Vista perform the following steps. 1. Power on the Light Touch unit. 2. Access Windows Device Manager a. Right Click on Computer -> Select Manage -> Select Device Manager 3. - Page 22 6. Select Let me pick from a list of device drivers on my computer. Click Next. 7. The Update Driver Software – Microsoft USB Sync window will appear. Unselect the Show compatible hardware check box. Light Touch LT1020 – User Guide v1.1 – Application Release C1.0.0 | Page 22 Light Touch LT1021 Series –...
- Page 23 Uncheck Show compatible hardware 8. Select Microsoft (1) in the Manufacturer column. The Model column will now populate. Select Microsoft USB Sync (Microsoft Corporation) (2). When the driver is loading a warning message will be displayed. Click Yes. The driver will now install and may take a few minutes to complete. (2) Note that the (1) Select driver is signed...
- Page 24 9. Once the driver installs it is very likely that a (code 10) error will be displayed. Click Close. Code 10 10. Once the correct driver is installed it will no longer show Light Touch 1000 Series USB Sync but Microsoft USB Sync as shown below. 11.
- Page 25 12. Select the Driver tab. The window below will appear showing the driver version of 6.1.6965.0 Driver Version 13. Power off the Light Touch. Restart your computer. Once your computer has rebooted power the Light Touch on. The Light Touch will begin to sync with Windows Mobile.
- Page 26 14. To access the files on Light Touch select File Management and click on Browse the contents of your device. 15. The following directory structure will be displayed. Light Touch LT1020 – User Guide v1.1 – Application Release C1.0.0 | Page 26 Light Touch LT1021 Series –...
- Page 27 Empty Light Touch LT1020 – User Guide v1.1 – Application Release C1.0.0 | Page 27 Light Touch LT1021 Series – User Guide v2.1 | Page 27...
-
Page 28: Appendix C - Light Touch™ Specifications
Appendix C - Light Touch™ Specifications Resolution 848 x 480 pixels (WVGA) Brightness Dependent on content type: 18 Lumens for typical video content 35 Lumens for typical user-interface content Projected Image Size 9.8” diagonal Laser Safety Classification Class 1 – eye safe under all conditions I/O Connectors USB Device (Micro Type B Connector) Micro SDHC card (Push-push socket)
