- Page 1 INSTRUCTION MANUAL Ver 1.0 Speed Dome Camera / SE Series...
- Page 2 This lightning flash with arrowhead symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE Important Safeguard Read Instructions Read all of the safety and operating instructions before using the product. Retain Instructions Save these instructions for future reference. Attachments / Accessaries Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty.
-
Page 4: Table Of Contents
CONTENTS ○ Introduction Features Product & Accessories Parts Name & Functions ○ Installation Rear Bracket Disassembling / Assembling DIP Switch Setup Direct Installation on the Ceiling Installation using In-Ceiling Mount Bracket Installation using Ceiling Mount Bracket Installation using Wall Mount Bracket Cabling ○... -
Page 5: Introduction
INTRODUCTION Features Camera Specifications CCD Sensor : 1/4" Super HAD CCD Zoom Magnification : × 22 Optical Zoom, × 10 Digital Zoom (Max. × 220 Zoom in Total) Day & Night Function → SE-x22DC Model Powerful Pan/Tilt Functions Max. 240°/sec high speed Pan/Tilt Motion Using Vector Drive Technology, Pan/Tilt motions are accomplished in a shortest path. -
Page 6: Product & Accessories
INTRODUCTION Product & Accessories Product & Accessories Camera Body Dome Cover Screws Options In-Ceiling Mount Bracket Ceiling Mount Bracket Wall mount bracket (SBI-100) (SBC-100) (SBW-100) 6/35 Speed Dome Camera Instruction Manual... -
Page 7: Parts Name & Functions
INTRODUCTION Parts Name & Functions Rear Bracket Drop Prevention Cabling Spring Terminal Block Signal Cable Lockup Screw Drop Prevention Hook Fuse Dome Cover Main Body Rear Bracket Dome Cover Care must be taken when you clean the clear dome cover. Since scratch, finger print and dust on the dome cover will ruin quality of camera, do not remove the vinyl tape on cover before installation is completed. -
Page 8: Installation
INSTALLATION Rear Bracket Disassembling ① Remove the fixing screw as shown bellow. ② Dismantle the Rear bracket by turning main body about 15°. Rear Bracket Assembling ① After you locate the internal cable properly, place ② Tighten the fixing screw as shown bellow. the Rear Bracket on to Main body by considering the matching line of both parts as show in picture bellow. -
Page 9: Dip Switch Setup
INSTALLATION DIP Switch Setup Before you install the camera, you should set the DIP switches to configure the camera ID, communication protocol. ADDRESS (ID) OPTIONS RESERVED 16 32 64 128 N.C N.C Refer to the Manual N.O N.O NTSC Communication Protocol Camera ID Sensor Type Camera ID Setup... - Page 10 INSTALLATION Communication Protocol Setup Select the appropriate Protocol with DIP switch combination. Switch State Protocol/Baud rate Pin 1 Pin 2 Pin 3 PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps Otherwise Reserved If you want to control using DVR or P/T controller, their protocol must be identical to camera.
- Page 11 INSTALLATION Reserved for Supplier Since Pin 6 ~ Pin 8 is only for supplier, DO NOT CHANGE THESE ITS ORIGINAL STATE. If you change one of these, proper operation can not be achieved. Pin 6 Reserved for future upgrade. Pin7 PAL / NTSC system selection of Camera.
-
Page 12: Direct Installation On The Ceiling
INSTALLATION Direct Installation on the Ceiling ① To pass cables to upside of ceiling, please, make ② Attach the Rear Bracket to the Ceiling Plate. about 50~60mm hole on the ceiling panel. ③ After install the Rear Bracket, please, hang the ④... -
Page 13: Installation Using In-Ceiling Mount Bracket
INSTALLATION Installation using In-Ceiling Mount Bracket (SBI-100) ① Cut the panel of Ceiling as shown bellow. ② Assemble Rear bracket of camera to the In- Ceiling Mount Bracket as shown bellow. Hole Dimension(mm) ③ Place the In-Ceiling Mount Bracket into the hole of ④... - Page 14 INSTALLATION ⑦ To assemble Deco. Ring, please, place side cut of Deco. Ring into contact with protrusion of in-ceiling mount as shown in the figure. Then, turn the deco. Ring clock-wise. 14/35 Speed Dome Camera Instruction Manual...
-
Page 15: Installation Using Ceiling Mount Bracket
INSTALLATION Installation using Ceiling Mount Bracket (SBC-100) ① To pass cables to upside of ceiling, please, make ② Assemble the Rear Bracket of camera on to about 50~60mm hole on the ceiling panel and Ceiling mount bracket. attach the Ceiling mount bracket on it. ③... -
Page 16: Installation Using Wall Mount Bracket
INSTALLATION Installation using Wall Mount Bracket (SBW-100) ① After removing the back plate of wall mount ② Assemble the Rear Bracket of camera on to wall bracket, attach the back cover on to the wall. mount bracket. After hang the wall mount bracket on to back plate, tighten the screw in the bottom to fix. -
Page 17: Cabling
INSTALLATION Cabling Power 12V DC Monitor RS-485 Keyboard Controller / DVR IrDA Light Sensor Door Alarm Switch Buzzer Sensor Output Devices Power Connection Please, check the voltage and current capacity of power carefully. The rated electrical power to operate this camera is DC 12V / 1A. The current must be 1A or higher. Be careful with polarity of power, the polarity is molded on the connector. - Page 18 INSTALLATION Alarm I/O Connection Sensor Input Internal +5V~12V IN COM+ Sensor 1 Output IN 1- Sensor 2 Output IN 2- Before connecting sensors, check driving voltage and output signal type of the sensor. Since output signal types of the sensors are divided into Open Collector and Voltage Output type in general, the cabling must be done properly after considering these typed.
-
Page 19: Operation
OPERATION Check points before operation Before power is applied, please, check the cables carefully. The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked by reading DIP switch of the camera. If your controller supports multi-protocols, the protocol must be changed to match to that of the camera. -
Page 20: Start Osd Menu
OPERATION Starting OSD Menu Function Using the OSD menu, Preset, Swing, Group and Alarm I/O function can be configured for each application. Start Menu After type the numeric key 95, press the Preset key to start OSD menu. [95] + [Preset] Reserved Preset Description Some Preset numbers are reserved to special functions. -
Page 21: Preset
OPERATION Preset Function Max. 64 positions can be stored as Preset position. Using Preset key together with numeric keys in the controller, Preset can be stored or executed quickly. If you want to change the factory default of Preset configuration (i.e. Labe1 of preset is blank, Dwell time is 3 sec and Relay out is OFF.), those settings for each preset can be configured using the OSD menu. -
Page 22: Group
OPERATION Group Function The group function allows running sequence of Presets and/or Swings. Max 8 group can be stored. Each group can have max 20 action entities which can be preset or swing. The group can be created, modified and deleted using menu. Also, dwell time defined in the preset menu is effective when group is running. -
Page 23: Other Motion Functions
OPERATION Other Functions Power Up Action This function enables to resume the last action executed before power down. Most of actions such as Preset, Swing and Group are available for this function but Jog actions are not available to resume. Park Action This function enables to locate the camera to specific position automatically if operator doesn’t operate the controller for a while. -
Page 24: Osd Display Of Main Screen
OPERATION OSD Display of Main Screen Preset Label Action Title LABEL12345 PRESET 1 I:1- O:-2 Alarm Information Camera ID P/T/Z Information CAM 1 28/-42 x1 P/T/Z Information Current Pan/Tilt angle in degree and zoom magnification. Camera ID Current Camera ID. Action Title Followings are possible Action Titles and their meaning. -
Page 25: How To Use Osd Menu
HOW TO USE OSD MENU General Rules of Key Operation for Menu The menu items surrounded with ( ) always has its sub menu. For all menu level, to go into sub menu, press Near key, to go up to upper menu, press Far key. If you learn by heart a rule that Near key is always similar to Enter key and Far key is always Esc key, many other functions of these keys will be easy to understand. -
Page 26: Camera Module Setup
HOW TO USE OSD MENU CAMERA SETUP Setup the general functions of zoom camera module. CAMERA SETUP ------------------------------ COLOR Color [ON/OFF] FOCUS MODE AUTO BACKLIGHT Focus Mode [AUTO/MANUAL] WHITE BAL. AUTO DIGITAL ZOOM DAY/NIGHT AUTO Backlight [ON/OFF] BACK White Balance [AUTO/SPECIAL/INDOOR/OUTDOOR/ EXIT MANUAL/ PUSH AUTO]... - Page 27 HOW TO USE OSD MENU Park Action Setup This function enables to locate the camera to specific position PARK ACTION ------------------------------ automatically if operator doesn’t operate the controller for a while. The PARK ENABLE Park Time can be defined as an interval from 1 min. to 4 hours. PARK TIME 00:10:00 PARK ACTION...
-
Page 28: Preset Setup
HOW TO USE OSD MENU PRESET Setup Preset Number [1~64] PRESET SETUP ------------------------------ Select a preset number to create or modify. If the PRESET NUMBER current Preset number is predefined, camera will DWELL TIME 00:00:03 move to stored position and zoom automatically (RELAY OUT) (EDIT LABEL) to check them. - Page 29 HOW TO USE OSD MENU Edit Preset Label The blinked cursor of LABEL represents current position to be ① LABEL FOR PRESET 1 selected from the set of characters bellow. If you choose a ------------------------------ LABEL character, the cursor will move to the right. 1234567890 ABCDEFGHIJ CANCEL...
-
Page 30: Swing Setup
HOW TO USE OSD MENU Swing Setup Swing Number [1~8] SWING SETUP ------------------------------ Select Swing number to create or modify. If the SWING NUMBER current Swing number is not defined, the text 1ST POS. PRESET 1 "UNDEFINED" is displayed at the right side of 1st 2ND POS. -
Page 31: Group Setup
HOW TO USE OSD MENU Group Setup Group Number [1~8] GROUP SETUP ------------------------------ GROUP NUMBER Action [x00, P1~P64, S1~S8] P01,P02,P03,P02,X00 X00,X00,X00,X00,X00 x00 means no Action is selected. If you assign X00,X00,X00,X00,X00 Preset it will shows P1~P64. If you assign Swing, X00,X00,X00,X00,X00 CANCEL S1~S8 will be displayed. -
Page 32: Specifications
SPECIFICATIONS SE-N(P)22CC Appearance Model SE-N22CC SE-P22CC Video Signal NTSC SONY 1/4'' Super HAD CCD Max. Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Res. 480 TV Lines S/N Ratio 48 dB ×22 Optical Zoom, ×10 Digital Zoom Zoom Camera Focal length... -
Page 33: Se-N(P)22Dc
SPECIFICATIONS SE-N(P)22DC Appearance Model SE-N22DC SE-P22DC Video Signal NTSC SONY 1/4'' Super HAD CCD Max. Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Res. 480 TV Lines S/N Ratio 48 dB ×22 Optical Zoom, ×10 Digital Zoom Zoom Camera Focal length... -
Page 34: Dimension
SPECIFICATIONS Dimension Main Body & Rear Bracket In-Ceiling Mount Bracket (SBI-100) Hole Dimension Ceiling Mount Bracket (SBC-100) Wall Mount Bracket (SBW-100) 68.5 Unit (mm) 34/35 Speed Dome Camera Instruction Manual... - Page 35 MEMO 35/35 Speed Dome Camera Instruction Manual...
