Zvork VOLT SL1 User Manual

The volt sl1 is a control voltage (cv) selector aimed at live performance and dj'ing

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

ZVORK

VOLT

SL1

User Manual

version 2.0.0

Table of Contents

Need help?

Do you have a question about the VOLT SL1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Zvork VOLT SL1

Page 1 ZVORK VOLT User Manual version 2.0.0...
Page 2: Table Of Contents
ZVORK Volt SL1 - User Manual Table of Contents Introduction............................3 Front Panel............................4 On / Off............................4 Controls............................4 Control groups..........................5 Sets..............................5 Activating a set..........................5 Copy / Paste of sets........................5 Metering............................6 Slave............................6 Transitions............................6 Metering............................6 Transition curves.........................6 Back Panel............................8 Chaining SL1's..........................8 Gate Inputs............................9 Gate Outputs............................9...
Page 3: Introduction
Volt SL1 - User Manual Introduction The Volt SL1 is a control voltage (CV) selector aimed at live performance and DJ'ing. With it you can switch or crossfade easily and in sync with the tempo between various values of control voltage signals.
Page 4: Front Panel
ZVORK Volt SL1 - User Manual Front Panel On / Off This switch is a quick way to silence all the control voltage outputs to zero value. Controls Up to 24 CV values (with version 2.0) can be controlled by a SL1 unit. For each control, the value can be set from -1 to +1.
Page 5: Control Groups
(see back panel section), simply press the corresponding button. Another mean of activating a set is through a MIDI keyboard. When a Volt SL1 has the keyboard focus, pressing a note activates a set. Here is the layout for each octave.
Page 6: Metering
ZVORK Volt SL1 - User Manual Metering To the left of each set button is a small meter which displays the weight of the set in the current output. When it is fully lit all the way up, the set is the one applied to the output.
Page 7 ZVORK Volt SL1 - User Manual To do so, start by switching to the transition curve edit page by clicking on the left or right arrow buttons at the bottom left of the control knobs panel. The transition curve edit page has two sections. To the left are displayed all the available transition curves (from left to right then top to bottom): •...
Page 8: Back Panel
ZVORK Volt SL1 - User Manual Back Panel The back panel exposes the 72 output CV signals corresponding to the 24 controls. For each control corresponds two CV outputs and one negated CV output. It also exposes both input and output sockets for the activation of the set.
Page 9: Gate Inputs
ZVORK Volt SL1 - User Manual Figure 1: One master SL1 controlling one slave. Gate Inputs You can also activate individually each set by plugging a “Gate” CV signal coming from an external source, such as a Redrum or Matrix unit, in the corresponding “Gate” input on the back panel.
Page 10: Midi Implementation Chart
ZVORK Volt SL1 - User Manual MIDI Implementation Chart MIDI Controller # Parameter Active Set Transition duration Transition sync. On / Off Set A – Control 1 12-20 Set A – Controls 2 to 10 21-30 Set B – Controls 1 to 10 Set C –...
