- Page 1 RSF Eur ope D A P DVP- H D icro USER MANUAL...
-
Page 2: Table Of Contents
C o m m e r c i a l D i v i s i o n M a n u f a c t u r e r RSF EUROPE S.A. 45, Avenue Marcel Dassault 18 rue de l’Industrie (Parc de la Plaine) L8399 Windhof –... -
Page 3: Overview
C h a p t e r 1 I n t r o d u c t i o n Overview Compact Flash Access Input Contacts Loop Indicator Output Settings Dipswitches Compact Flash Slot Ethernet Port Power Indicator 10. RCA Analog Audio Outputs IR Receiver 11. -
Page 4: Supported Files
Basic Functionality Before switching on the device, configure the dipswitches to setup the graphical output. The MicroDVP-HD video files must be copied on the CF card in a folder named ‘Media’ placed on the root of the CF card. If no script files are copied in this ‘Media’ folder, the clips are played looped in alphabetical or- der. -
Page 5: Configuration
In Play Mode, the inputs can have different assignment, refer to the txt file linked to the script for further details. Picture Display The MicroDVP-HD accepts images in bitmap format. Max resolution is 1920x1080, 8, 24 and 32 bit accepted. Display time of the picture can be adjusted with the last character of the picture file name. -
Page 6: Configuration Mode
Press and hold the ‘Display’ button to enter the configuration mode. RS 232 Commands RS 232 script is available in the script list. Copy the files in the ‘Media’ folder to be able to send RS 232 commands to the MicroDVP-HD. Parameters are: 9600 Bds...
