INFINOVA CCTV VARI-FOCAL LENS MANUAL
Thank you very much for purchasing this Infinova CCTV lens.
In order to understand the lens specifications and performances, please read this manual thoroughly. Please handle the lens with care.

MOUNT TYPE

CS mount is equipped with Infinova CCTV lens as follow. Before you use the lens, please make sure that the mount type matches that on your camera.
CS MOUNT
V1121-308, V1122-308, V1123-308, V1121-2812, V1122-2812, V1123-2812, V1121-550, V1122-550, V1123-550, V1121-20100, V1122-20100

INSTALLATION ON CAMERA

The lens can be installed by screwing it clockwise into CS-mount on the CCTV camera. Once the lens is screwed in completely to its mechanical stop position,
you will then be able to rotate lens chassis back to suit the set-up position of the camera.

WIRING DIAGRAM

Please read the user's manual for the devices such as the camera and controller before wiring. Then please follow the chart below to insure the right connection.
V1123-308, V1123-2812, V1123-550
Cable
Red--------Power Supply
White-----VS or V signal
*Connecting Red (Power Supply) and Black (GND)
Cables in the other way to the camera by mistake may
Cause the failure of the lens internal circuit.

IRIS

V1122-308, V1122-2812, V1122-550, V1122-20100 if the camera has a selection switch between Video and DC. Please set it to DC.
V1123-308, V1123-2812, V1123-550 if the camera has a selection switch between Video and DC. Please set it Video.(LEVEL ADJUSTMENT)
MONITOR SCREEN
To Make Brighter
To Make Dimmer
*C/W = clockwise
The video signal level is continuously adjustable from Low to High. If the brightness of the monitor screen dose not appears natural, please adjust the level as
instructed.
Automatic Light Compensation (ALC) and level adjustment (LEVEL) can be accomplished by rotating the respective screws a couple of times until the optimal
image is obtained. (ALC ADJUSTMENT)

LIGHT MEASUREMENT

Setting exposure to "Peak" light
Setting exposure to "Average" light
*If any hunting is observed on the screen, set ALC to average exposure image.
*C/W=clock wise

TO INSURE LONG TERM USE

*Please remove dust on the lens by using a blower or soft brush. Avoid touching the lens surface.
*In order to remove fingerprints or oil stains on the lens surface, use lens cleaning paper or clean cotton cloth with a little cleaning liquid. Then, wipe off the
stains lightly starting from the center of the lens surface. Please wipe the lens body with a silicon cloth. Avoid usin
g any organic solvents such as thinner or benzene.
Specification
MODEL
Imager Size
Focal Length
MANUAL IRIS
Aperture
Range
AUTO IRIS
Horizontal
Angle of
View
Vertical
Mount-Type
Dimension
Infinova
Tel: 1-888-685-2002 (USA only)
V1121-308, V1122-308, V1123-308, V1121-2812, V1122-2812, V1123-2812,
V1121-550, V1122-550, V1123-550, V1121-20100, V1122-20100
Black-----GND
Shield-----GND
V1123-308
Rotate C/W
Rotate counter C/W
V1121-308, V1122-308
V1123-308
3.0-8mm
F 1.0~CLOSE
F 1.0~360
(TELT) 36.0°, (WIDE) 91.0°
(TELT) 27.0°, (WIDE) 67.0°
40.2mm
51 Stouts Lane, Monmouth Junction, NJ 08852 U.S.A.
Tel: 1-732-355-9100
V1122-2812, V1122-550, V1122-308, V1122-20100
Cable
Orange------Control (-)
Red----------Drive (+)
*When adding plus Voltage to Drive (+). Will move to the opening
direction.

LEVEL ADJUSTMENT

ALC ADJUSTMENT

V1123-2812, V1123-550
Rotate counter C/W
Rotate C/W
V1121-2812, V1122-2812
V1123-2812
1/3"
2.8-12mm
F 1.4~CLOSE
F 1.4~360
(TELE) 24.1°, (WIDE) 97.4°
(TELE) 18.1°, (WIDE) 72.5°
CS
54.6mm
Fax: 1-732-355-9101
Yellow------Control (+)
Black--------Drive (-)
V1123-2812, V1123-550
Rotate counter C/W
Rotate C/W
V1123-308
Rotate C/W
Rotate counter C/W
V1121-550, V1122-550
V1123-550
5-50mm
F 1.4~CLOSE
F 1.4~ CLOSE
(TELE) 5.6°, (WIDE) 53.6°
(TELE) 4.2°, (WIDE) 40.3°
59.2mm
V2.0 1002
V1121-20100
V1122-20100
20-100mm
F 1.6~CLOSE
F 1.6~360
(TELE) 2.8°, (WIDE) 13.6°
(TELE) 2.1°, (WIDE) 10.2°
110mm
