AQUARIUS 70 Operating Instructions Manual

Electrolytic gas soldering / welding unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Type 70 Electrolytic Gas
Soldering / Welding Unit
AQUARIUS
Operating Instructions

Table of Contents

for the
2
2
2
5
6
7
8
9
9
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70 and is the answer not in the manual?

Questions and answers

Анатолий
June 25, 2025

Где можно купить электролит для aquarius typ 70 gmbh heiligenhaus

0

Summary of Contents for AQUARIUS 70

  • Page 1: Table Of Contents

    AQUARIUS Operating Instructions for the Type 70 Electrolytic Gas Soldering / Welding Unit Table of Contents 1. Important General Remarks 2. Safety Instructions 3. Description of the Soldering Unit and Accessories 4. Operating for the First Time 5. Daily Operation 6.

  • Page 2: Important General Remarks

    3. Description of the Soldering Unit and Accessories The AQUARIUS Type 70 is a self-contained, electrolytic gas soldering / welding unit with a gas output of 45 l/h. By splitting distilled water into hydrogen and oxygen, oxyhydrogen gas is produced, which burns in the torch flame to reach temperatures of up to 3200°C.
  • Page 3 Numbered Components: 1a) Filler opening of the electrolyte tank ( = gas generator, black) 1b) Level indicator float for electrolyte tank 1c) Screw cap of the generator tank, black 1d) Electrolyte bottle 2a) Filler opening of the flux tank ( = booster, red) 2b) Level indicator float for flux tank 2c) Screw cap of the booster tank, red 2d) Flux fluid bottle...
  • Page 4 Numbered Components: Gas generator (electrolyte tank) Booster (flux fluid tank) 16) Safety pressure limiter 17) Reset pushbuttons of the safety pressure limiter 18) Pressure switch 19) NTC resistor 20) Transformer 21) Dropping resistor 22) Mist collector 23) Cooling fan 24) Diode plate 30) Thermostat switch...

  • Page 5: Operating For The First Time

    4. Operating for the First Time Caution: When filling, always wear protective gloves and safety goggles! Keep away from open flames! 1. Filling the Electrolyte (black filler opening): Using the larger funnel (3a), pour the entire contents of the supplied bottle of electrolyte solution (1d) slowly into the filler opening of the electrolyte tank (1a).

  • Page 6: Daily Operation

    5. Daily Operation Before beginning work, you should check the fill levels of the generator and booster tanks. Depending on how often you use the unit, you may not necessarily have to do this every day. When it is in its ready state (power switch on, torch valve closed) the unit does not consume fluids.

  • Page 7: Maintenance

    6. Maintenance 1. Renewing the Electrolyte: Caution: When working with electrolyte , always wear protective gloves and safety goggles to prevent acid burns (see Section 2. Safety Instructions)! The electrolyte should be renewed about every 8 to 12 months, depending on how often the unit is used.

  • Page 8: Troubleshooting Guide

    7. Troubleshooting Guide 1. The unit does not build up pressure. a) If the LED (5) lights up, than gas is leaking at one of the screw connections or out of the torch. Solution: Check and tighten the generator tank screw cap (1c), the gas tube screw connection (7), and the torch adjusting valve (10).

  • Page 9: Technical Data

    14 kg Size Table for Torch Nozzles in mm: Nozzle No. Inside Diameter Outside Diameter 0.60 0.90 0.50 0.80 0.40 0.70 0.35 0.60 0.30 0.55 0.25 0.50 0.20 0.45 9. Schematic Diagram A schematic diagram of the unit’s circuitry is shown on the next page.
