L3302FHD - L3002UW USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i3Projector L3302FHD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Laser Techology i3Projector L3302FHD

  • Page 1 i3PROJECTOR L3302FHD - L3002UW USER MANUAL...

  • Page 2: Table Of Contents

    Multimedia........40 Table of Contents ......2 Usage Notice ........3 Accessing Multimedia Files ....40 How to access Multimedia mode ..40 Safety Information ......... 3 Appendices ........47 Precautions ..........4 Installing and Cleaning the Optional Introduction ........6 Dust Filter ..........47 Package Overview ........

  • Page 3: Usage Notice

    Usage notice Safety Information The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and mainte- nance (servicing) instructions in the literature accompanying the...

  • Page 4: Precautions

    Precautions Please follow all warnings, precautions and maintenance as recommended in this user�s guide. Warning- Do not look into the projector’s lens when the lamp is on. The bright light may hurt and damage your eyes. Warning- To reduce the risk of fire or electric shock, do not expose this projector to rain or moisture.
  • Page 5 Usage notice Turn off and unplug the power plug from the AC outlet  before cleaning the product. Use a soft dry cloth with mild detergent to clean the dis-  play housing. Disconnect the power plug from AC outlet if the product ...

  • Page 6: Introduction

    Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact your nearest customer service center. VGA Cable Projector Power Cord 电源 确定 菜单 退出  Due to different 放大...

  • Page 7: Product Overview

    Introduction Product Overview Main Unit  The interface is subject to model’s specifications. 1. Control Panel 6. Speaker 2. Focus Switch 7. Power Socket 3. Ventilation (inlet) 8. Input / Output 4. IR Receiver Connections 5. Ventilation (outlet) 9. Lens i3PROJECTOR manual L3302FHD - L3002UW...

  • Page 8: Control Panel

    Control Panel 1. Power LED 2. Enter 3. Temp LED 4. Lamp LED 5. Menu 6. Input 7. Four Directional Select Keys 8. Power/Standby button 9. IR Receiver www.i3-learning.com...

  • Page 9: Input/Output Connections

    Introduction Input/Output Connections 1. VGA1-In/YPbPr Connector (PC Analog Signal/Component Video Input/HDTV/YPbPr) 2. HDMI2 Input Connector 3. HDMI1 Input Connector 4. USB Connector (Connect to PC for Remote Mouse  The interface function) is subject to 5. RJ45 connector (Optional) model’s 6. USB Type A Connector (Optional) specifications.

  • Page 10: Remote Control

    Remote Control 1. Infrared transmitter 2. LED Indicator 3. Power On/Off 4. OK 5. Four Directional Select Keys 6. Menu 7. Exit 8. Zoom in 9. Reset 10. Auto 11. Source 12. Zoom out 13. Volume +/- 14. Keystone +/- 15.

  • Page 11: Installation

    Introduction Connecting the Projector Connect to Computer/Notebook Router / Network Switch MOLEX  Due to the Microphone difference in applications External Display for each country, some regions may have different Audio Output accessories.  (*) Optional accessory 1....................*RS232 Cable 2..................... VGA Cable 3....................*HDMI Cable 4....................

  • Page 12: Connect To Video Sources

    Connect to Video Sources DVD Player, Set-top Box, HDTV receiver Composite Video Output  Due to the difference in Microphone applications for each country, some regions may have different accessories.  (*) Optional Audio Output accessory 1..........*15-Pin to 3 RCA Component/HDTV Adaptor 2.

  • Page 13: Powering The Projector On / Off

    Introduction Powering the Projector On / Off Powering On the Projector 1. Securely connect the power cord and signal cable. When connected, the POWER/STANDBY LED will turn Orange. 2. Turn on the lamp by pressing “ ” button either on the projector or on the remote.

  • Page 14: Powering Off The Projector

    Powering Off the Projector 1. Press the “ ” button on the remote control or on the control panel to turn off the projector. The following message will be displayed on the screen. Press the “ ” button again to confirm otherwise the message will disappear after 10 seconds.

  • Page 15: Adjusting The Projected Image

    Introduction Adjusting the Projected Image Adjusting the Projector�s Height The projector is equipped with elevator feet for adjusting the image height. 1. Locate the adjustable foot you wish to modify on the underside of the projector. 2. Rotate the adjustable ring clockwise to raise the projec- tor or counter clockwise to lower it.

  • Page 16: Adjusting The Projector�S Focus

    Adjusting the Projector�s Focus To focus the image, slide the focus switch to left/right until the image is clear. 1080p series: The projector will focus at distances from  1.443 to 1.887 feet (0.437 to 0.572 meters). Ultra Wide series: The projector will focus at distances ...

  • Page 17: Adjusting Projection Image Size (Diagonal)

    Introduction Adjusting Projection Image Size (Diagonal) 1080p series: Projection Image Size from 80” to 100” (2.03  to 2.54 meters). Ultra Wide series: Projection Image Size from 120” to 140”  (3.05 to 3.56 meters). Top View Screen Screen (W) Projection Distance (D) Width Screen (H)
  • Page 18 L3002UW Screen Size W x H Projection Distance (D) Diagonal Offset (Hd) length (inch) (mm) (inch) (mm) (inch) size of 16:6 Screen Width Height Width Height wide tele wide tele (mm) (inch) 2853.9 1070.2 112.4 42.1 468.8 18.5 365.6 14.4 2972.8 1114.8 117.0...

  • Page 19: User Controls

    User controls Control Panel & Remote Control Control Panel Using the Control Panel Refer to the “Power On/Off the Projector” POWER section on pages 13-14. Enter Press “Enter” to confirm your item selection. INPUT Press “INPUT” to select an input signal. Press “MENU”...

  • Page 20: Remote Control

    Remote Control Using the Remote Control Infrared transmit- Sends signals to the projector. LED Indicator. Refer to the “Power On/Off the Power Projector” section on pages 15-16. Exit Press “Exit” to close the OSD menu. Zoom in Zoom in the projector display. Return the adjustments and settings Reset to the factory default values.

  • Page 21: Using The Remote Control

    User controls Using the Remote Control Press “Menu” to launch the on-screen Menu display (OSD) menu. To exit OSD, press “Menu” again. Press “VGA1” to choose VGA IN 1 VGA1 connector. Momentarily turns off/on the audio Black screen and video. Press “HDMI1”...

  • Page 22: On-Screen Display Menus

    On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. How to operate To open the OSD menu, press “Menu” on the Remote Control or Projector Keypad. When OSD is displayed, use the keys to select any item in the main menu.

  • Page 23: Picture

    User controls Picture Color Mode There are many factory presets optimized for various types of images. Use the button to select the item. Bright: For brightness optimization.  PC: For meeting presentation.  Movie: For playing video content.  Game: For game content. ...
  • Page 24 Sharpness Adjust the sharpness of the image. Press the button to decrease the sharpness.   “Sharpness”, “Saturation” and Press the button to increase the sharpness.  “Hue” functions are only sup- Saturation ported under Adjust a video image from black and white to fully saturated video mode.

  • Page 25: Screen

    User controls Screen Aspect Ratio Auto: Keep the image with original width-height ratio and  maximize the image to fit native horizontal or vertical pixels. 4:3: The image will be scaled to fit the screen and displayed  using a 4:3 ratio. 16:9: The image will be scaled to fit the width of the screen ...

  • Page 26: Digital Zoom

    V. Position Press the button to move the image down.  Press the button to move the image up.  Digital Zoom Press the button to reduce the size of an image.  Press the button to magnify an image on the projection ...

  • Page 27: Setting

    User controls Setting Language Choose the multilingual OSD menu. Press the button into the sub menu and then use the button to select your preferred language. Press on the remote control to finalize the selection. Menu Location Choose the menu location on the display screen. Closed Caption Use this function to enable close caption menu.

  • Page 28: Test Pattern

    LAN (Standby) Choose “On” to enable LAN connection. Choose “Off” to disable LAN connection. VGA B (Function) Input: Choose “Input” to let the VGA port works as a VGA input  function. Output: Choose “Output” to enable the VGA Out function once ...

  • Page 29: Volume

    User controls Volume Speaker Choose “On” to enable the speaker.  Choose “Off” to disable the speaker.  Line Out Choose “On” to enable the line out function.  Choose “Off” to disable the line out function.  Microphone Choose “On” to enable the microphone. ...

  • Page 30: Options

    Options Logo Use this function to set the desired startup screen. If changes are made they will take effect the next time the projector is powered on. Default: The default startup screen.  User: Use stored picture from “Logo Capture” function. ...
  • Page 31 User controls Auto Power Off (Min) Sets the countdown timer interval. The countdown timer will start, when there is no signal being sent to the projector. The projector will automatically power off when the countdown has finished (in minutes). Laser Settings Refer to page 32.

  • Page 32: Options | Laser Settings

    Options | Laser Settings Laser Hours Used (Normal) Display the projection time of normal mode. Laser Hours Used (ECO) Display the projection time of ECO mode. Laser Power Mode Normal: Normal mode.  ECO: Use this function to dim the projector lamp which will ...
  • Page 33 User controls  “Frame Sequen- Auto: When a HDMI 1.4a 3D timing identification signal is  tial” is supported detected, the 3D image is selected automatically. the DLP Link 3D input signals Choose “On” to enable 3D function.  from VGA / HDMI Choose “Off”...

  • Page 34: Lan

    Status Display the network connection status. DHCP Configure the DHCP settings. On: Choose “On” to let the projector to obtain an IP address  automatically from your network. Off: Choose “Off” to assign IP, Subnet Mask, Gateway, and  DNS configuration manually. IP Address Display an IP address.
  • Page 35 User controls Group Name Display the group name. Projector Name Display the projector name. Location Display the projector location. Contact Display the contact information. i3PROJECTOR manual L3302FHD - L3002UW...

  • Page 36: How To Use Web Browser To Control Your Projector

    How to use web browser to control your projector 1. Turn on DHCP to allow a DHCP server below: to automatically assign an IP, or 4. Based on network web-page for manually enter the required network the input-string in [tools] tab, the information.
  • Page 37 User controls and then, under Network Tasks Enabled (N/A) , click Change settings of this Admin Pass- New Password word connection. Confirm When making a direct connection from your computer to the projector Step 1: Find an IP Address (192.168.0.100) from LAN function of projector.

  • Page 38: Crestron Roomview Control Tool

    3) Default gateway:192.168.0.254 Step 6: To open Internet Options, click IE web browser, click Internet Options, click the Connections tab and click “LAN Settings...”. Step 7: The Local Area Network (LAN) Setting dialog box appears. In the Proxy Server area, cancel the Use a proxy server for your LAN check box, then click “OK”...
  • Page 39 User controls 250+ control systems on a single Ethernet network (more are possible, the number depends on the combination of IP ID and IP address). Crestron RoomView monitors 1. Main Screen each projector, including projector’s online 2. Edit Room status, system power, lamp life, network 3.

  • Page 40: Multimedia

    Accessing Multimedia Files This projector supports two methods to project the media files (photos, videos, music, documents) stored on following devices: a. via Wireless dongle (optional) - wirelessly access the media files stored on your mobile phone, tablet PC, notebook, or desktop. b.
  • Page 41 Mobile Display To access the media files stored on your mobile device or tablet PC, do the folllowing: 1. On Multimedia menu, select Mobile/Tablet. 2. On your mobile device or tablet PC, download “EZview” application App Store (iOS) or Play Store (Android). 3.
  • Page 42 projector. Laptop Display To access the media files stored on your laptop/notebook, do the folllowing: 1. On Multimedia menu, select Laptop. 2. Enable your laptop/notebook WiFi function, and search the AP name listed in the Wi-Fi network list. 3. On the initial connection, you will be prompted to enter a password.
  • Page 43 5. Launch “EZview” application and enter the control code shown on the right-bottom side of the screen. 6. Wait until the connection is established. The media files on your laptop/notebook can be accessed using the projector. Desktop Display To access the media files stored on your desktop, do the folllowing: 1.
  • Page 44 3. Launch “EZview” application and enter the control code shown on the right-bottom side of the screen. 4. Wait until the connection is established. The media files on your desktop can be accessed using the projector. USB Storage Display To access the media files stored on your USB flash drive, do the folllowing: Supported File Format Multimedia Cat-...
  • Page 45 3. Use the keys to select the file to view/play and press the “Enter” key to confirm. Configuring Multimedia Settings To change the settings, do the folllowing: 1. On Multimedia menu, select Settings.
  • Page 46 2. Use the keys to select the desired menu option and press the “Enter” key to enter the submenu. System: Select this option to view the firmware version  and update firmware. Video: Select this option to change the display ratio and ...

  • Page 47: Appendices

    Appendices Installing and Cleaning the Optional Dust Filter We recommend you clean the dust filter every 500 hours of operation, or more often if you are using the projector in a dusty environment. When the warning message appears on the screen, do the following to clean the air filter: The optional dust ...

  • Page 48: Compatibility Modes

    Compatibility Modes VGA Analog  a. PC signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 640x480 31.5 640x480 35.0 640x480 37.9 640x480 37.5 640x480 43.3 720x400 31.5 800x600 35.1 800x600 37.9 SVGA 800x600 48.1 800x600 46.9 800x600 53.7 Apple, MAC II 832x624 49.1 1024x768...
  • Page 49 Appendices UXGA 1600x1200 75.0 b. Extended wide timing Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 1280x720 44.8 1280x800 49.6 WXGA 1366x768 47.7 1440x900 59.9 WSXGA+ 1680x1050 65.3 c. Component signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 720x480 480i 59.94(29.97) 15.7...

  • Page 50: Hdmi Digital

    HDMI Digital  a. PC signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 640x480 31.5 640x480 35.0 640x480 37.9 640x480 37.5 640x480 43.3 720x400 31.5 800x600 35.1 800x600 37.9 SVGA 800x600 48.1 800x600 46.9 800x600 53.7 Apple, MAC II 832x624 49.1 1024x768...
  • Page 51 Appendices SXGA+ 1400x1050 65.3 UXGA 1600x1200 75.0 b. Extended wide timing Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 1280x720 44.8 1280x800 49.6 WXGA 1366x768 47.7 1440x900 59.9 WSXGA+ 1680x1050 65.3 c. Video signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 480p 640x480 59.94/60...

  • Page 52: Rs232 Commands And Protocol Function List

    RS232 Commands and Protocol Function List RS232 Port Setting  Items Method Communication Method Asynchronous Communication Bits per seconds 19200 Data bits 8 bits Parity None Stop bits Flow control None RS232 Signals Connection   RS232 shell is grounded. Computer COM Port Projector COM Port (D-Sub 9pin connector) (D-Sub 9pin connector)

  • Page 53: Commands Set List

    Appendices Commands Set List  Case sensitive, each command end by [CR](Carriage Returns) Command Item Remark POWER ON POWER OFF (Quick Power OFF) POWER OFF VGA1 VGA2 HDMI1 HDMI2 Video Multimedia POWER ON “F00”[CR] (Hex: Ox46 0x30 0x30 0x0d) Command [ACK] [CR] is the Power ON when projector is in standby mode Details...
  • Page 54 VGA1 “F05”[CR] (Hex:Ox46 0x30 0x35 0x0d) Command Change the input to “Computer1”. Details [ACK] [CR] Return “?”[CR] VGA2 “F06” [CR] (Hex:Ox46 0x30 0x36 0x0d) Command Change the input to “Computer2”. Details [ACK] [CR] Return “?”[CR] Video “F33”[CR] (Hex:Ox46 0x33 0x33 0x0d) Command Change the input to “Video”.
  • Page 55 Appendices Multimedia “A15”[CR] (Hex:Ox40 0x31 0x35 0x0d) Command Change the input to “Multimedia”. Details [ACK] [CR] is the effective return for [ACK] [CR] commands received. Return “?”[CR] i3PROJECTOR manual L3302FHD - L3002UW...

  • Page 56: Regulation & Safety Notices

    Regulation & Safety Notices This appendix lists the general notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 57: Operation Conditions

    Appendices Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 58 Appendices Safety notice CAUTION: CLASS 4 LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED AVOID EYE OR SKIN EXPOSURE TO DIRECT OR CLASS 1 LASER PRODUCT SCATTERED RADIATION . IEC 60825-1:2014. Complies with IEC 62471 Low Risk Group 1 IEC60825-1:2014. Complies with IEC 62471 Low Risk Group 1 - This projector is a Class 2 laser device that conforms with IEC 60825-1:2007 - This projector is a Class 1 laser device that conforms...

  • Page 59: Ceiling Mount Installation

    Appendices Ceiling Mount Installation 1. To prevent damage to your projector, please use the ceiling mount. 2. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: Screw type: M4*4 ...
