- Page 1 MIDI Solutions Pedal Controller OPERATING INSTRUCTIONS...
- Page 2 MIDI Solutions Pedal Controller Operating Instructions M416-100 2012 MIDI Solutions Inc. All rights reserved. MIDI Solutions Inc. PO Box 3010 Vancouver, BC Canada V6B 3X5 www.midisolutions.com...
- Page 3 MIDI Solutions products powered by a single MIDI Out or Thru be limited to four. It is possible to connect a volume pedal to the Pedal Controller rather than an expression pedal, but a y-adapter that breaks out the Pedal Controller's stereo jack to two mono jacks is required.
- Page 4 Echo: When Echo is ON, all incoming MIDI messages received by the Pedal Controller are echoed to its MIDI output. When Echo is OFF, only the messages generated by the Pedal Controller are sent to its MIDI output.
- Page 5 Example To program the Pedal Controller to generate the System Exclusive message F0 22 33 44 55 F7, varying the fourth byte, with a minimum value of 9, and a maximum value of 127 (=7F Hex), send it the following System Exclusive...
- Page 6 MIDI CHANNEL TABLE The value in the programming commands is assigned according to the following table: MIDI Channel MIDI CONTROL CHANGE TABLE Decimal Hexadecimal Control Function Bank Select Modulation wheel or lever Breath Controller Undefined Foot controller Portamento time Data entry MSB Channel Volume Balance Undefined...
- Page 7 WARRANTY MIDI Solutions Inc. warrants this product to be free from defects in material and workmanship for a period of one (1) year from date of purchase. This warranty is void if the product has been damaged by accident, misuse, alteration, unauthorized repairs or other causes not arising out of defects in material or workmanship.
