Shiro SD 8511 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
• User Manual •
SD8511
Digital Enhanced Cordless Communication

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD 8511 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Shiro SD 8511

  • Page 1 • User Manual • SD8511 Digital Enhanced Cordless Communication...

  • Page 2: Table Of Contents

    Contents What the symbols mean ..................2 The Handset and Base Unit .................. 3 Setting up your telephone..................4 Installation ......................6 Important safety information................8 Warranty Information................... 9 Making and Answering Calls ................10 Conference Calling..................... 11 Phone Book ......................11 Call Information ....................

  • Page 3: What The Symbols Mean

    What the symbols mean Battery charge level Whenever this shows ‘nearly empty’ ( ), put the handset on the base unit to charge the batteries. While the battery is being charged, the level shown will keep changing. Mute Your handset's microphone is muted. Signal level Shows the strength of the signal between the handset and base unit, and flashes when you are out of range of the base unit, when the level is low, or the symbol is flashing, move closer to...

  • Page 4: The Handset And Base Unit

    The Handset and Base Unit MENU button PHONEBOOK button Press to enter menu and sub-menu In standby mode, press to enter mode; phonebook menu; Press to confirm selection; Press during programming to go With the key “*” to lock or back to the previous option, or to unlock the keypad;...

  • Page 5: Setting Up Your Telephone

    Setting up your telephone Connection and conditions for use You can connect your SD8511 to a direct exchange line (DEL), a line connected to a local exchange, with its own phone number; to an extension socket connected to a DEL; or to an extension on an approved compatible PBX.
  • Page 6 What's in this pack Please check the box contents for completeness. If any parts are missing, return complete box to your supplier. • The cordless handset • The base unit • Rechargeable battery cell • A telephone line cable (different from country to country) •...

  • Page 7: Installation

    Installation 1. Choose a suitable site for the base unit Make sure it is not near to another telephone, nor to other electrical equipment. 2. Plug the mains power lead and the telephone line cord into the rear of the base unit. 3.
  • Page 8 6. Connect the base unit to the telephone line Switch off power at the mains socket. Insert the telephone line plug into the socket. Switch mains power back on Make sure the mains socket is switched on if you want to use the phone---it will not work without electrical power.

  • Page 9: Important Safety Information

    Important safety information This equipment is not designed for making emergency calls in the event of a power failure. Alternative arrangements should be made for access to emergency services. (This means that you should also have a basic phone that does not need mains power, connected to your line so that you can make calls during a power failure) People with a heart pacemaker should consult their doctor before using the telephone.

  • Page 10: Warranty Information

    Warranty Information Your phone is covered by a 12-month warranty from the date of purchase shown on your sales receipt. The warranty does not cover the batteries, misuse or damage caused by a storm or excessive voltages. If you have any problems using the phone, check the Troubleshooting section at the back of this manual.

  • Page 11: Making And Answering Calls

    Making and Answering Calls To Make a Call 1. Key in the telephone number; 2. Press the CALL button to make a call. To Dial a Number from Call Logs 1. Select <Missed Calls>, <Received Calls> or <Dialed Calls> under CALL LISTS mode; 2.

  • Page 12: Conference Calling

    Conference Calling You need to register with your fixed line network operator for conference calling service. It is dependant on service availability and subscription. To Make Conference Call: • Connect the first party; • Press INT button, and the first party is put on hold; •...

  • Page 13: Call Information

    3. Now press MENU key to delete current number or all numbers; the display shows Delete? ; 4. Press MENU key to delete the number/numbers. To Modify (Change) a Number in Phonebook 1. Under Phonebook mode, press UP / DOWN button to scroll through the stored numbers;...

  • Page 14: Handset Setting

    To Check Call Records 1. In standby mode, press MENU key, goes to CALL LIST (Call Information) mode; 2. Press MENU key again, the display shows Missed Calls, Received Calls, Dialed calls and Clear All Calls; 3. Then press MENU key again, the display shows these calls numbers;...
  • Page 15 To Set the Baby Call Number 1. Press MENU key and UP/DOWN button to the location HANDSET; 2. Select <Baby Call> under HANDSET; 3. Then select <Set Num> under BABY CALL; 4. Press MENU key to confirm, and Key in the number (If you make a mistake, press PHONEBOOK key to delete digits from the display);...
  • Page 16 To Set External/Internal Ringer Melody (1-9 melody) 1. Select < Ringer Set> under HANDSET mode; 2. Press MENU key to confirm, then UP/DOWN button to the location ExternalRing / InternalRing; 3. Press MENU key and UP/DOWN button to choose the ring melody you want to set;...

  • Page 17: Base Setting

    4. Then press MENU key to confirm; To change Handset Name 1. Select <Handset Name> under HANDSET mode; 2. Press MENU key to confirm, the display shows the current name; 3. Press and hold the PHONEBOOK key to clear the old name, then key in the new name;...
  • Page 18 4. Press MENU key to confirm. To Set Base Volume (0-4 volume level) 1. Select < Ringer Settings> under BASE mode; 2. Select <Ringer Volume> under Ringer Settings; 3. Press MENU key and UP/DOWN button to set the volume you like; 4.
  • Page 19 2. Select <Dial Mode> under Dial Settings; 3. Press MENU key and UP/DOWN button to change dial mode as TONE or PULSE; 4. Press MENU key to confirm. Call Barring Function Call barring enables you to restrict or bar certain types of calls from your phone. To Set Call Barring Number 1.

  • Page 20: Default Settings

    Default Settings 1. Select <Default settings> under BASE mode; 2. Press MENU key, and key in the original PIN (default PIN:0000) number; 3. Press MENU key to confirm, you will hear a beep, then all features will return to their default settings. The following is default settings for you reference.
  • Page 21 1. Select <Outbox> under Messages mode, press MENU key, a list of messages sent failed are displayed. Press UP/DOWN button to scroll through the messages; 2. Then you can edit, delete, save or send the message. Draft Draft contains messages you have saved. 1.
  • Page 22 4. If sending fails, the screen will display “Send fail”, and the sent message will be saved in outbox automatically. To Save Message 1. After you type a message, press MENU key, then select Save message; 2. Press MENU key again to save this message to Draft,, the display shows “Saving…”...

  • Page 23: Extra Setting

    Extra Setting To Set Alarm Time 1. Select < Alarm Set > under EXTRA mode; 2. Press MENU key, then key in the time; 3. Press MENU key to save; To Set Clock Time 1. Select < Clock Set > under EXTRA mode; 2.

  • Page 24: Handset Registration

    Handset Registration Your SD8511 is supplied with the handset already registered to the base unit, and you shouldn't need to register it. But if you've bought extra handset, you'll need to register each one to your original base unit. Maximum 5 handsets can be registered to one base. To register a handset 1.

  • Page 25: To Transfer A Call

    On the other handset's display, your number appears, and the INT symbol flashes. Then the other handset user presses the CALL button to connect the call. For details of how to change the ringing melody and volume for intercom calls, see "INT MELODY"...

  • Page 26: Troubleshooting

    Troubleshooting If you experience difficulties with the working of your SD8511, refer to the advice given below. 1. "The handset does not ring" Check the base unit's mains power adaptor is plugged in and power is switched on. The base unit needs mains power for normal operation of the phone, not just for charging the batteries.
  • Page 27 Switch off power at the mains socket, wait for a few seconds and then switch back on. 8. "The handset’s battery are running low within an hour or two." Before you used the handset for the first time, you should have left it on the base unit for up to 15 hours to charge the battery fully.

  • Page 28: Technical Details

    Technical details Full DECT GAP Compatible system Standard 1.88 to 1.9 GHz Frequency range Channel bandwidth 1.728 MHz GMSK Modulation Up to 300 m outdoors; Operating range Up to 50 m indoors Standby time: 100 hours Operating time Talking time: 8 hours Operating 0 C to 40 Temperature range...

  • Page 29: Declaration Of Conformity

    Declaration of conformity The SD8511 complies with the essential protective requirements and objectives of: • EC R& TTE Directive 1999/5/EC • EC Low Voltage Directive 73/23/EEC • EC EMC Directive 89/336/EEC And conforms to the following relevant harmonized standards: • TBR 10:1999 •...
