Martin Audio Blackline H3T+ Specifications

Blackline H3T
Three-way bi-amp/tri-amp trapezoid Hybrid™
fully horn loaded
features
Q
All-horn three-way system
Q
'Phase-ball' loaded mid-driver
Q
Hybrid™ LF section
Q
Fitted with handles and castors
Q
Five year limited warranty
applications
Q
Larger club performance
Q
Large scale installs
+
The Blackline H3T is a very high performance, all-horn, three-way
system in a single, wide-bandwidth package. New drivers have been
developed for improved performance in all bands. The Hybrid™ low
frequency section comprises a horn-loaded 15" (380mm)/4" (100mm)
voice coil driver that is reflex loaded to extend the LF output to below
the natural cut-off point of the horn. The new LF driver features a water
resistant cone and triple roll surround for increased excursion.
+
The mid-horn of the H3T has a unique 'phase-ball' loading device which
maintains the constant directivity characteristics of the horn at the upper
end of its range. It is driven by a new 10" (250mm) midrange driver with
an aluminium demodulating ring for improved high-mid clarity and
reduced distortion when driven hard. The 70˚ x 40˚ HF section of the
+
H3T features a neodymium 1" (25mm) exit compression driver with a
Kapton diaphragm for high sensitivity and extended HF performance.
When driven in bi-amp mode, a Martin Audio M3
+
is available to provide H3T crossover and limiter facilities. A DX1 or
equivalent controller is recommended for provision of crossover and
limiter functions in tri-amp mode.
overall dimensions
+

technical specifications

TYPE
FREQUENCY RESPONSE (5)
DRIVERS
RATED POWER (2)
RECOMMENDED AMPLIFIER
+
Electronic Controller
SENSITIVITY (6)
MAXIMUM SPL (7)
NOMINAL IMPEDANCE
DISPERSION (-6dB)
CROSSOVER
ENCLOSURE
FINISH
PROTECTIVE GRILLE
CONNECTORS
PIN CONNECTIONS
FITTINGS
DIMENSIONS (inc wheels)
WEIGHT
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: info@martin-audio.com
All information is Copyright © 2007 Martin Audio Ltd.
www.martin-audio.com
Three-way bi-amp/tri-amp trapezoid Hybrid™
fully horn loaded
50Hz-18kHz ± 3dB
15" (380mm)/4" (100mm) voice coil bass driver
10" (250mm)/2.5" (63.5mm) voice coil mid driver
1" (25mm) exit HF compression driver
LF: 750W AES, 3000W peak
MF/(MF + HF): 300W AES, 1200W peak
HF: 60W AES, 240W peak
LF: 400-1500W into 4 ohms
MF/(MF + HF): 400-800W into 4 ohms
HF: 100-400W into 4 ohms
LF: 104dB, MF/(MF + HF): 104dB, HF: 106dB
131dB continuous, 137dB peak
LF: 8 ohms, MF/(MF + HF): 8 ohms, HF: 8 ohms
70˚ horizontal, 40˚ vertical
200Hz active, 2kHz active/passive
250 litre, multi-laminate birch ply
Textured black paint
Black perforated steel
2 x Neutrik NL8
LF+,- : 1+,1-, MF/(MF + HF)+,- : 2+,2-
HF+,- : 3+,3-, Link through all inc 4+,4-
12 x M10 inserts, 4 x 4" (100mm) castors
8 x pocket handles, 2 x lid clips
(W) 560mm x (H) 1066mm x (D) 780mm (911mm)
(W) 22ins x (H) 42ins x (D) 30.7ins (35.9ins)
77.5kg (170.5lbs)
