Summary of Contents for Bandit HY-70

  • Page 1 0/42 HY-70 & HY-100 Long Range Barcode Scanner User’s Manual...

  • Page 2: Table Of Contents

    1/42 CATALOG Program procedure using scanner menus 1. System Information 1.1 Restore default…………………………………………………………………………………3 1.2 Show firmware version…………………………………………………………………………3 1.3 Show series number……………………………………………………………………………3 2. System Setup 2.1 Interface selection………………………………………………………………………………4 2.1.1 Keyboard emulation parameters setting……………………………………………………4 2.1.2 RS-232 serial communication setting ……………………………………………………7 2.2 Scanning mode selection………………………………………………………………………11 2.3 Beeper tone selection………………………………………………………………………13 2.4 Header and Trailer……………………………………………………………………………14 3.

  • Page 3: System Information

    2/42 Start: Read “SET” barcode Read the barcode in Read “RESET” Barcode the “ITEM” line When the content is“Ref. Appendix” in the “OPTION” line, the scanner read Read the barcode in the barcode in the appendix. If setting the “OPTION” line more appendix barcode, the scanner always read this barcode, until the system couldn’t setting.

  • Page 4: Restore Default

    3/42 1.1 Restore default The reading of the “RESET” label turns all the parameters back to default values. 1.2 Show firmware version The reading of the “FIRMWARE VERSION” label will be shown firmware version. 1.3 Show series number The reading of the “SERIES NUMBER” label will be show series number. RESET FIRMWARE SERIES NUMBER...

  • Page 5: Interface Selection

    4/42 2.1 Interface selection There are two kinds of different interfaces to be chosen now. The scanner remains in the last interface type when the scanner is reset. 2.1.1 Keyboard emulation parameters setting Choose the appropriate type of keyboard emulation by scanning the labels under the following labels.
  • Page 6 5/42 Keyboard type selection: ITEM OPTION USA ( Default ) Germany French LANGUAGE SELECTION Spanish Italian Swiss Swedish OFF ( Default ) FUNCTION KEY Scan Code mode ( Default ) KEYBOARD TYPE Alt mode Capital Lock ON/OFF: Ctrl mode...
  • Page 7 6/42 Select the suitable code to match your keyboard caps lock status. Num Lock ON/OFF: Inter-Character delay (for keyboard wedge): This option governs delay time among consecutive characters.

  • Page 8: Rs-232 Serial Communication Setting

    7/42 ITEM OPTION OFF ( Default ) CAPS LOCK Message terminator (for keyboard OFF ( Default ) wedge): Inter-Message delay (for keyboard NUM LOCK wedge): This option governs delay time between consecutive messages. 2.1.2 RS-232 Serial communication 0 ms setting With this option of communication protocol, you can tailor the scanner to 10 ms...
  • Page 9 8/42 ITEM OPTION None Enter ( Default ) MESSAGE TERMINATOR (for KB) Execute 0 ms ( Default ) 100 ms INTER-MESSAGE DELAY 500 ms (for KB) 1000 ms 600 bps 1200 bps Inter-Character delay (for RS-232): This option governs delay time between consecutive characters.
  • Page 10 9/42 ITEM OPTION ( Default ) STOP BIT None ( Default ) Even PARITY Mark Space ITEM OPTION 0 ms ( Default ) 10 ms INTER-CHARACTER DEL AY (for RS-232) 50 ms 100 ms 0 ms ( Default ) 100 ms...
  • Page 11 10/42 INTER-MESSAGE DELAY (for RS-232) 500 ms 1000 ms Message terminator ( For RS-232 ): Handshaking protocol: The RS-232 scanner supports four handshaking protocols. ACK/NAK response time setting: ITEM OPTION None CR/LF ( Default ) MESSAGE TERMINATOR (for RS-232) H Tab STX/ETX...

  • Page 12: Scanning Mode Selection

    11/42 ITEM OPTION None ( Default ) RTS/CTS HANDSHAKING SELECTION ACK/NAK Xon/Xoff 300 ms 800 ms ( Default ) RESPONSE TIME 2.2 Scanning mode selection Trigger mode： The scanner becomes inactive as 1500 ms soon as the data is transmitted. It must be triggered to become active again.
  • Page 13 12/42 ITEM OPTION Trigger mode ( Default ) Auto scan mode Alternate mode SCANNING MODE SELECTION Repeat mode Testing mode Turbo trigger mode...

  • Page 14: Beeper Tone Selection

    13/42 2.3 Beeper selection: ITEM OPTION Very low Low ( Default ) BEEPER TONE Medium High Disable Very short BEEPER SOUND DURATION Short Medium Long ( Default )

  • Page 15: Header And Trailer

    14/42 2.4 Header and Trailer This option allows you to append a header and/or a trailer to every message transmitted via the serial ports or the keyboard port. There is no restriction in selecting header or trailer characters as far as the sum of the lengths of header and trailer is not greater than 10 digits. 1.
  • Page 16 15/42 ITEM OPTION Disable ( Default ) FORCE UPC-A TO EAN-13 FORMAT Enable Disable TRANSMITTING CHECK DIGIT Enable ( Default ) Disable NOT TRANSMITTING LEADING CHARACTER Enable ( Default ) 0 ( Default ) CUT FRONT Ref. Appendix 0 ( Default ) CUT BACK Ref.

  • Page 17: Upc-A

    16/42 UPC- A ITEM OPTION None ( Default ) 2 bits ADDENDUM 5 bits 2 or 5 bits 3.2 UPC-E ITEM OPTION Disable READABLE Enable ( Default )
  • Page 18 17/42 Disable ( Default ) Ref: Appendix IDENTIFIER CODE Disable ( Default ) FORCE UPC-E TO UPC-A FORMAT Enable Disable TRANSMITTING CHECK DIGIT Enable ( Default ) 0 ( Default ) CUT FRONT Ref. Appendix 0 ( Default ) CUT BACK Ref.

  • Page 19: Ean 13

    18/42 UPC-E Disable TRANSMITTING LEADING Enable ( Default ) CHARACTER None ( Default ) 2 Bits ADDENDUM 5 Bits 2 or 5 Bits 3.3 EAN-13 ITEM OPTION Disable READABLE Enable ( Default ) Disable ( Default ) Ref: Appendix IDENTIFIER CODE Disable TRANSMITTING CHECK DIGIT...

  • Page 20: Isbn/Issn

    19/42 EAN- 13 EAN-13 transfer to ISBN/ISSN ITEM OPTION ( Default ) CUT BACK Ref. Appendix None ( Default ) 2 Bits ADDENDUM 5 Bits 2 or 5 Bits Disable ( Default ) TRANSFER TO ISBN/ISSN Enable...

  • Page 21: Ean 8

    20/42 3.4 EAN-8 ITEM OPTION Disable READABLE Enable ( Default ) Disable ( Default ) IDENTIFIER CODE Ref: Appendix Disable TRANSMITTING CHECK DIGIT Enable ( Default ) ( Default ) CUT FRONT Ref. Appendix ( Default ) CUT BACK Ref. Appendix None ( Default ) 2 Bits...

  • Page 22: Code 39

    21/42 3.5 Code 39 ITEM OPTION Disable READABLE Enable ( Default ) ITEM OPTION Disable ( Default ) IDENTIFIER CODE Ref: Appendix Disable ( Default ) CALCULATING Enable Disable TRANSMITTING CHECK DIGIT Enable ( Default ) Disable ( Default ) CONCATENATION Enable Ref.

  • Page 23: Codabar

    22/42 It is possible, if using Code 39's "Full ASCII Mode" to encode all 128 ASCII characters. ITEM OPTION Ref. Appendix (00~64) ( Default 32 ) Standard ( Default ) PARAMETERS Full ASCII Disable ( Default ) START/STOP CHARACTER Enable TRANSMISSION 3.6 Codabar ITEM...
  • Page 24 23/42 ITEM OPTION Disable( Default ) CALCULATING Enable Disable TRANSMITTING CHECK DIGIT Enable ( Default ) 0 ( Default ) CUT FRONT Ref: Appendix 0 ( Default ) CUT BACK Ref: Appendix ABCD/ABCD ( Default ) START/STOP CHARACTER TYPE abcd/abcd abcd/tn*e Disable ( Default ) START/STOP...

  • Page 25: Code 93

    24/42 3.7 Code 93 ITEM OPTION Disable READABLE Enable (Default ) Disable ( Default ) IDENTIFIER CODE Ref. Appendix Disable ( Default ) CALCULATING Enable Disable TRANSMITTING CHECK DIGIT Enable ( Default ) Ref. Appendix (0~64) (Default 0) Ref. Appendix (0~64) (Default 32) 0 ( Default ) CUT FRONT...

  • Page 26: Code 128

    25/42 3.8 Code 128 ITEM OPTION Disable READABLE Enable( Default ) Disable ( Default ) IDENTIFIER CODE Ref: Appendix Disable ( Default ) CALCULATING Enable Disable TRANSMITTING CHECK DIGIT Enable ( Default ) Disable ( Default ) FNC2 CONCATENATION Enable Disable (Default ) UCC/EAN 128 Enable...
  • Page 27 26/42 Code 128 ITEM OPTION ( Default ) CUT FRONT Ref. Appendix ( Default ) CUT BACK Ref. Appendix Ref. Appendix (0~64) ( Default 0 ) Ref. Appendix (0~64) ( Default 32 )

  • Page 28: Interleaved 2 Of 5

    27/42 3.9 Interleaved 2 of 5 ITEM OPTION Disable READABLE Enable ( Default ) Disable ( Default ) Ref. Appendix IDENTIFIER CODE Disable ( Default ) CALCULATING Enable Disable TRANSMITTING CHECK DIGIT Enable ( Default ) 0 ( Default ) CUT FRONT Ref.

  • Page 29: Industrial 2 Of 5

    28/42 3.10 Industrial 2 of 5 ITEM OPTION Disable READABLE Enable ( Default ) Disable ( Default ) IDENTIFIER CODE Ref. Appendix Ref. Appendix (0~64) ( Default 0 ) Ref. Appendix (0~64) ( Default 32 ) 0 ( Default ) CUT FRONT Ref.

  • Page 30: Standard 2 Of 5

    29/42 3.11 Standard 2 of 5 ITEM OPTION Disable (Default) READABLE Enable Disable ( Default ) Ref. Appendix IDENTIFIER CODE 0 ( Default ) Ref. Appendix CUT FRONT 0 ( Default ) CUT BACK Ref. Appendix Ref. Appendix (0~64) ( Default 0 ) Ref.

  • Page 31: Matrix 2 Of 5

    30/42 3.12 Matrix 2 of 5 ITEM OPTION Disable ( Default ) READABLE Enable Disable ( Default ) Ref. Appendix IDENTIFIER CODE Disable ( Default ) CALCULATING Enable Disable TRANSMITTING Enable ( Default ) 0 ( Default ) Ref. Appendix CUT FRONT 0 ( Default ) Ref.

  • Page 32: Msi/Plessey

    31/42 3.13 MSI/Plessey ITEM OPTION Disable ( Default ) READABLE Enable Disable ( Default ) IDENTIFIER CODE Ref. Appendix Calculate 2 bits But not transmit CHECK DIGIT Not calculate ( Default ) Calculate 2 bits Transmit 1 bit Calculate 2 bits Transmit 2 bits Calculate 1 bit But not transmit...
  • Page 33 32/42 MSI/Plessey ITEM OPTION 0 ( Default ) Ref. Appendix CUT FRONT 0 ( Default ) Ref. Appendix CUT BACK Ref. Appendix (0~64) ( Default 0 ) Ref. Appendix (0~64) ( Default 32 )

  • Page 34: Appendix

    33/42 APPENDIX CODE 39 FULL ASCII BAR CODE TABLE...
  • Page 35 34/42...
  • Page 36 35/42 “...
  • Page 37 36/42 & ′...
  • Page 38 37/42 < >...
  • Page 39 38/42...
  • Page 40 39/42...
  • Page 41 40/42...
  • Page 42 41/42...
  • Page 43 42/42...

This manual is also suitable for:

Hy-100
