Summary of Contents for Laboratory PPS LGS - 304
- Page 1 Acoustic Noise Generator LGS - 304 Operation Manual St. Petersburg 2012...
- Page 2 CONTENTS: 1. Introduction....................2 2. Scope of Application..................2 3. Main Technical Data..................3 4. In Box......................4 5. Operation Principle ..................4 5. Safety Measures ..................4 6. Installation and Operation Procedures ............5 7. Maintenance ....................7 8. Storage and Transport ................. 7 1.
- Page 3 3. Main Technical Data 3.1 The parameters of the Product correspond to the requirements specified in Table 1. Table 1 № Parameter Parameter Value Input voltage of secondary power source 220 V, 50 Hz Voltage of the main unit: 24 V Frequency range of output acoustic signal, Hz 90 - 11200 Adjustment range of output signal voltage, dB, up to 10...
- Page 4 4. In Box The Product's In Box is specified in Table 2 Table 2 № Name LGS-304 - main unit Bracket Mounting screws of the bracket Mounting screws Gasket Power supply with output voltage 24 V Operation Manual Passport Mark of conformity Copy of FSTEK Certificate 5.
- Page 5 7. Installation and Operation Procedures 7.1 After storing the Product in a cold room or transporting in winter conditions, it can be plugged in not earlier than after 4 hours stay at room temperature. 7.2 Before installing make an external examination of the Product to make sure there is no mechanical damage and check it for completeness.
- Page 6 1 - Generator block, 2 -Mounting screws, 3 – Bracket, 4 - Jack-point screw, 5 – Wall, 6 – Gasket Figure 2 - Wall Mounting 7.8 Preparation for work is as follows: 7.8.1 Connect secondary regulated power supply to the main unit of the Product observing polarity (color coded output +24V-not marked output- body).
- Page 7 8. Maintenance 8.1 The Product is maintenance free. Maintenance procedures are carried out at least once a year involving: - Checking the integrity of the case; Items, cable connectors fixing, power wires reliability; - Dust and dirt cleaning. 8.2 Maintenance procedures are carried out without current. 9.
