MODEL NRS-12/40 BATTERY CHARGER
PLEASE SAVE THESE IMPORTANT SAFETY AND OPERATING INSTRUCTIONS
For correct operation of the equipment, it is important to read and be familiar
with this entire manual before installing and operating the charger.
LOOK FOR THIS SYMBOL TO POINT OUT SAFETY PRECAUTIONS.
BECOME ALERT—YOUR SAFETY IS INVOLVED. IF YOU DO NOT FOLLOW THESE
SAFETY INSTRUCTIONS, INJURY OR PROPERTY DAMAGE CAN OCCUR.

1. IMPORTANT SAFETY INSTRUCTIONS

a. Before using the battery charger, read all the
instructions and caution markings on the
battery charger, the battery, and all of the
products using the battery.
b. Do not touch the uninsulated parts of the AC
input or the DC wires, the charger's binding
posts, or the battery terminals as there is a
possibility of electric shock.
c. Batteries
produce
operating, which can explode if ignited.
Never smoke, use an open flame, or create
sparks in the vicinity of the battery. Ventilate
the area well when the battery is charging in
an enclosed area.
d. Batteries contain caustic material which may
cause burns. Do not get in eyes, on skin, or
clothing. If the gelled or liquid content of the
batteries contacts the skin or clothing, wash
the area thoroughly with water. In the case
of contact with the eyes, flush immediately
with clean water for 15 minutes and obtain
medical attention.
e. Connect or disconnect the battery plug only
when the charger output is off to prevent
arcing or burning.
f.
Only qualified personnel should program or
service this equipment.
www.nationalrailwaysupply.com
NATIONAL
RAILWAY
SUPPLY
DO NOT DISCARD THIS MANUAL AFTER READING.
hydrogen
gas
while
g. De-energize
connections before servicing this unit.
injury does occur, apply standard treatment
for electric shock and, if necessary, consult
with a physician.
h. The charger is not for outdoor use. Do not
expose the charger to rain or snow.
i.
Do not operate the charger if it has received
a sharp blow, been dropped, or otherwise
damaged.
j.
Do not disassemble the charger. Have the
charger
RAILWAY SUPPLY service agent or a local
qualified service center.
reassembled incorrectly, damage to the
charger and the batteries or an electric shock
may result.

2. DESCRIPTION

The NATIONAL RAILWAY SUPPLY charger, model
12/40, is a convection-cooled, solid state, SCR
regulated charger that provides either a constant
current or constant voltage output. The charger can
be set to charge batteries within a voltage range of
10.00 to 19.99 volts for gel-cell, liquid lead-acid,
nickel cadmium, nickel iron, and starved electrolytic
batteries.
1
*01545*
Installing, Operating and
Service Instructions for the
NRS-12/40 Solid State Charger
IT MEANS:
all
AC
and
DC
examined
by
a
NATIONAL
If the charger is
power
If
01545J

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NRS-12 and is the answer not in the manual?

Questions and answers

Summary of Contents for NRS NRS-12

  • Page 1 RAILWAY Installing, Operating and Service Instructions for the SUPPLY NRS-12/40 Solid State Charger MODEL NRS-12/40 BATTERY CHARGER PLEASE SAVE THESE IMPORTANT SAFETY AND OPERATING INSTRUCTIONS For correct operation of the equipment, it is important to read and be familiar with this entire manual before installing and operating the charger.
  • Page 2 3. THEORY OF OPERATION The control module has a temperature compensation range between 32°F and 95°F (0°C and 35°C) that When the charger is connected to the desired AC does not allow charger voltage to increase or voltage source (115 or 230), the transformer creates decrease beyond the calculated values.
  • Page 3 THE AC IS DISCONNECTED BECAUSE OF THE WARNING: IMPROPER JUMPER ENERGY STORED IN THE CAPACITOR. CONNECTION MAY CAUSE SEVERE DAMAGE TO THE CHARGER AND THE BATTERY. 7. TEMPERATURE PROBE Configure the jumpers for your AC voltage source (refer to the jumper diagram above). Place the AC The external temperature probe is an optional way of ring terminals on the binding posts and tighten the extending...
  • Page 4 BE SURE THE CHASSIS IS strength. SECURELY GROUNDED. If any problem cannot be Remove the adhesive's protective strip and press the resolved, consult the nearest NRS service agent. probe firmly against the battery to ensure good adhesion. 10. SERVICING...
  • Page 5 3 + .25mV per °F per cell 12. PARTS LIST The following is a list of parts found in the NRS Model 12/40. When replacing a part, use only original factory replacement parts of the correct size and rating. PART NO.
  • Page 6 13. WIRING DIAGRAM SHUNT AC FUSE LINE +BATTERY -BATTERY CIRCUIT BREAKER LINE J1-1 J1-7 AC FUSE J1-9 115V ELECTRONIC JUMPER CONTROL J1-8 SETTING MODULE SHOWN J1-10 J1-11 J1-3 REMOTE J1-6 J1-12 TEMPERATURE J1-4 PROBE J1-5 J1-1 -BATTERY BLACK J1-2 NOT USED CONNECTOR J1-3 TMP PROBE (-)
