Summary of Contents for AGM A-19
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRECAUTIONS ......................2 INFORMATION FOR USERS APPLICABLE IN EUROPEAN UNION COUNTRIES INFORMATION FOR USERS APPLICABLE IN UNITED STATES OF AMERICA INSTALLATION POWER CONNECTION MAINTENANCE TRANSPORTING THE MONITOR GETTING STARTED PACKAGE CONTENTS INSTALLATION OF FIRST USE IDENTIFYING PARTS AND CONTROLS FUNCTIONS OF THE BUTTONS AND INDICATOR: SETUP CUSTOMIZING YOUR MONITOR... -
Page 3: Precautions
Precauciones Information for users applicable in European Union countries The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources. -
Page 4: Getting Started
Getting Started Package contents Before beginning, ensure that the carton contains the following items: 1. LCD Monitor 2. Power cord (The plug may vary according to the electrical standard for your area) 3. Video Signal Cable (Analog, D-S U B Cable) 4. -
Page 5: Installation Of First Use
Installation of First Use 1. The installation of the monitor is very simple. Take the monitor from the packing box and remove all the packing materials. And then put the monitor on the desk carefully; fold the monitor base, so that the monitor can stand on the desk properly. Next, adjust the monitor t o the desired position according to the seat and other factors. -
Page 6: Setup
Setup 1. Connecting video (Note: Before connecting computer, ensure the resolution and refresh rate of the computer do not exceed the following settings - resolution: 1280*1024, refresh rate: 75Hz.) 1.1 Turn off your computer 1.2 Connect the video signal cable to the VGA port of your PC, tighten the screws on the connector onto the computer 1.3 Connect the other end of the video signal cable to the VGA-IN port at the back of the monitor, tighten the screws on the connector to the monitor... -
Page 7: Customizing Your Monitor
Customizing your Monitor The On Screen Display (OSD) system provides a full range of customizable tools to optimize your display. While full customization is available, we strongly recommend using the Auto Adjustment function, which is preset to fully optimize your monitor’s Important: performance. -
Page 8: Osd Icon List
OSD Icon List Icon Functions Detail Optimize the picture performance automatically (you also press buttons Auto Adjustment simultaneously , while the OSD menu is not shown, to activate the function) Brightness Adjust the luminance level of the screen Adjust the contrast level (black to white ratio) of the Contrast screen Sharpness... - Page 9 OSD Menu Position Adjust the position of OSD menu on the screen. Select between Standard and Advanced power Power Saving Mode saving modes. See addendum for details Fulfill EP A Energy Star power management Standard requirement Advanced Activate monitor Life-Extension function Reset monitor parameters back to factory preset Recall Factory Preset values.
-
Page 10: Troubleshooting
Troubleshooting Symptom Check Items 1.Check if the monitor is turned on (press the button again). 1. No picture 2.Check if the power cord is properly connected to the monitor and 2. LED indicator (at the right side of the power outlet. monitor) is not lit 3.Check if there is electricity coming from the power outlet (use another device to check for power). -
Page 11: Technical Features And Specifications
VESA DDC2B, DPMS AC 100 - 240 V, 50 / 60 Hz Power Consumption Active: < 35 W / Standby: < 1 W Item (A-19) Description Display Size 376.3 (H) x 301.1(V) mm Panel Pixel Pitch 0.294(H) x 0.294(V) mm... -
Page 12: Interface Frequency
Interface Frequency 1. The following frequency range is the working period. If the entered mode is between the below period but does not match the frequency of supported timing, display optimization will not be assured. If the entered mode is out of the working period, the display will be blank (just show “Input Signal Out Of Range”) then go to power saving. -
Page 13: Addendum
Addendum Advanced Power Saving M ode 1. Background The traditional monitors have the function of electricity-saving dormancy. Bu t the interv al of dormancy is difficult to decide. If the interv al is long, the purpose of saving electrici ty can not be achieved. - Page 14 The side effect of the Monitor Life-Extension function (why not preset Advanced Power Saving Mode as default?) According to the request of EP A (US Environmental Protection Agency) to power management of monitors, the power consumption of the monitor must go down to below 3 watts within 3 seconds after the monitor s goes into power s aving mode.
-
Page 15: Regulations
Regulations FCC compliance 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2. -
Page 16: Tco'99
TCO’99 Congratulations! You have just purchased a TCO’99 approved and labeled product! Your choice has provided you wit h a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. - Page 17 Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs.
