Asotel Dynamix DW-PhoneLite User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dynamix DW-PhoneLite and is the answer not in the manual?

Questions and answers

Related Manuals for Asotel Dynamix DW-PhoneLite

Summary of Contents for Asotel Dynamix DW-PhoneLite

  • Page 2: Table Of Contents

    Chapter 1 Overview of the Dynamix DW-PhoneLite............. 4 1. Hardware Overview ................... 5 2. Software Features and Specification ..............8 Chapter 2 Configuring the Dynamix DW-PhoneLite through LCD Phone menu ....10 1. Initialize Dynamix DW-Phone Lite................10 2. LCD Menu Configuration ..................12 Chapter 3 Configuring the Dynamix DW-PhoneLite through Web Pages ......
  • Page 3 16. [tos] command ...................... 46 17. [bureau] command....................47 18. [rom] command..................... 47 19. [passwd] command....................49 Chapter 5 Upgrading Software on the Dynamix DW-PhoneLite .......... 50 1.From LCD Phone Menu................... 50 2. Web Management ....................51 3. Telnet command lines ..................... 52...

  • Page 4: Chapter 1 Overview Of The Dynamix Dw-Phonelite

    Chapter 1 Overview of the Dynamix DW-PhoneLite Dynamix DW-PhoneLite is a full-featured IP-based telephone set for home telephony via Ethernet base communication. It supports SIP RFC3261 protocol. Two 10/100BaseT embedded switch/hub RJ-45 ports allow connect to office LAN and PC on your table.

  • Page 5: Hardware Overview

    Marked with (**): May be not available yet, please contact with your distributor. 1. Hardware Overview 1.Front View and Keypad function System Indication LED: When Dynamix DW-PhoneLite didn’t register to Proxy server ♦ or having incoming call, system indication LED will be blinking.
  • Page 6 ♦ book data 1-5 (please refer to LCD configuration-Phone Book, Configuring the Dynamix DW-PhoneLite through Telnet command lines - [pbook] command, or Web Configuration-Phone Book chapter). Number 1 –10, * and #: The function is as the same as the general phone set.
  • Page 7 PC: 10/100 Base-T RJ-45 connector, connected directly to the PC through the straight ♦ CAT-5 cable 3.Specification 1. Ethernet Port： Ethernet port is for connecting Dynamix DW-PhoneLite to network, transmit rate supports 10/100 Base-T. Ethernet connector（LAN） 2. Dimension: 200mm(W) x 79mm(H) x 210mm(D) 3. Weight: 830g...

  • Page 8: Software Features And Specification

    5 configurable speed dials Network Supported Fixed IP Dynamic Host Configuration Protocol (DHCP) PPPoE connection (When PPPoE disconnect, Dynamix DW-PhoneLite can via an re-connect) Behind NAT IP Sharing Device Support QOS by setting DSCP (Differentiated Service Code Point) parameters of VoIP...
  • Page 9 Software Upgrade: TFTP/FTP download Three easy ways for system configuration LCD Front Panel Web Browser TELNET Environmental Operating and storage Humidity: 10 to 95 % (Non-condensing) Operational Temperature: 0 to +40 °C Storage Temperature: -10 to 60℃ Certification Dynamix DW-PhoneLite Administration Guide...

  • Page 10: Chapter 2 Configuring The Dynamix Dw-Phonelite Through Lcd Phone Menu

    LCD Phone menu Note: 1. After any configuration has changed for the Dynamix DW-PhoneLite, user has to do Reboot in the selection 7 “Reboot”. 2. We suggest user to set IP address via LCD menu 5→2.3.4.5 first, then go to chapter 3 to do other configurations via web browser.
  • Page 11 3. Press MENU to enter configuration mode then press OK to enter sub menus; press FLASH can jump out current menu to previous level. Call List Forward Phone Book Ringer Network Advanced Set (can be protected by password) Reboot Dynamix DW-PhoneLite Administration Guide...

  • Page 12: Lcd Menu Configuration

    There are 3 selections in Forward type, user must select under which condition to forward calls. (1) Busy When Dynamix DW-PhoneLite is in busy status, the incoming call will be forwarded to the assigned phone number. A. Activate Enter a forwarded phone number to activate busy forward function.
  • Page 13 C. Exit Return to upper level of LCD Menu (3) Uncondition (Unconditional Forward) It is included the above two types. Whether the Dynamix DW-PhoneLite is in which status, calls will be automatically forwarded to the assigned phone number. A. Activate Enter a forwarded phone number to activate Unconditional Forward function.
  • Page 14 Style There are three tone styles for Dynamix DW-PhoneLite. Move the “>” symbol by press ▼ or ▲ on the keypad to select the tone style preferred, then press OK to confirm it. Exit Return to upper level of LCD Menu 5.
  • Page 15 PPPoE disconnected, Dynamix DW-PhoneLite will automatically reboot to re-connect, and after reboot, if Dynamix DW-PhoneLite still can’t connect with server, Dynamix DW-PhoneLite will keep trying to connect. On the other hand, if user disables this function, won’t reboot and keep trying to connect.
  • Page 16 Return to upper level of LCD Menu (3) User Info A. User Name (Mandatory) Set User Name of Dynamix DW-PhoneLite to register to Proxy Server. If Proxy server doesn’t request specific User name, please enter Line number here. B. Line No.
  • Page 17 (4) Password User has to input user password for FTP server login .It is necessary for upgrading Dynamix DW-PhoneLite new application rom file via FTP method. (5) File Name User has to press the file name of new application rom file prepared for...

  • Page 18: Chapter 3 Configuring The Dynamix Dw-Phonelite Through Web Pages

    The configuration function and steps are similar with the way through command line. Please refer to the chapter 4-Configuring the Dynamix DW-PhoneLite through Telnet command lines for more detail information. Below is a guide for user to configure via web interface.

  • Page 19: Step 1. Browse The Ip Address Predefined Via Keypad

    Step 1. Browse the IP Address predefined via Keypad Please enter IP address (user have to set via LCD menu first) of Dynamix DW-PhoneLite If user failed to set IP address via LCD menu, the default IP address of DW-Phone is 10.1.1.3, user can also try to connect to SIP-Phone with this default IP via web interface.

  • Page 20: Step 2. Input The Login Name And Password

    4. Rom configuration: upgrade whole 2m software file Password (The same with TELNET): Null (just press confirm, no need to key in password in default value) Note: User can set password later in 8.PASSWORD via web interface. Dynamix DW-PhoneLite Administration Guide...

  • Page 21: Step 3. Enter The Web Interface Main Screen

    Phone Book (in Peer-to-Peer mode). Please remember to configure these commands before start to work with Dynamix DW-PhoneLite. Note: After change any settings, please remember to reboot (in Reboot System) Dynamix DW-PhoneLite so that changes can take effect. Dynamix DW-PhoneLite Administration Guide...

  • Page 22: Network Interface

    Set the Subnet Mask of Dynamix DW-PhoneLite Default routing gateway: Set Default routing gateway of Dynamix DW-PhoneLite Get IP Mode: User has to set Dynamix DW-PhoneLite to use which network mode. 1. Fixed IP: User has to assign a fixed IP to Dynamix DW-PhoneLite. 2. DHCP: When DHCP function enables, Dynamix DW-PhoneLite will automatically search DHCP server after reboot.
  • Page 23 UPnP: Enable it if IP sharing or NAT device supports UPnP function so that no need to configure IP sharing or SIP-Phone when Dynamix DW-PhoneLite is behind NAT device. IP Sharing Server Address: Set Public IP Address of IP Sharing router for Dynamix DW-PhoneLite to work behind IP sharing.

  • Page 24: Sip Information

    Proxy server, and if there is a matched data in phone book, DW-PhoneLite will make call to related IP address. Prefix String: set prefix string. If user ID contains alphabets, user can set it as prefix Dynamix DW-PhoneLite Administration Guide...
  • Page 25 DW-PhoneLite to register to the Proxy. Line Account: set user name of Dynamix DW-PhoneLite for registering. User can set user name and password for registering. If password is no need, please set user name the same as line number or DW-PhoneLite won’t register successfully.

  • Page 26: System Configuration

    Set the DTMF inter digit time (second) To set the duration (in second) of two pressed digits in dial mode as timed out. If after the duration user hasn’t pressed next number, Dynamix DW-PhoneLite will dial out all number pressed.

  • Page 27: Pppoe Configure

    DW-PhoneLite will keep trying to connect. After re-connected, DW-PhoneLite will also restart system. On the other hand, if user disables this function, DW-PhoneLite won’t reboot and keep trying to connect. Other items: for reference only, cannot allow to be configured. Dynamix DW-PhoneLite Administration Guide...

  • Page 28: Voice Setting

    User can set different packet size for each codec. G.723 Silence Suppression: Enable / Disable sound compression and comfort noise generation. It is only for codec G.723.1 Volume: Adjust the volume in “Voice” (sending out); “Input” (receiving); “ DTMF” (DTMF sending out). Dynamix DW-PhoneLite Administration Guide...

  • Page 29: Phone Book

    Name, IP Address and E.164 number of the destination device. From Telnet command line can set up to 100 sets of phone book data. Delete Date: User can delete any configured phone book data by assign index. Dynamix DW-PhoneLite Administration Guide...

  • Page 30: Dscp Configuration

    Type-of-Service (TOS) octet in IPv4. The recommended DiffServ Codepoint is defined in RFC2597 to classify the traffic into different service classes. The mapping of Codepoint value of DS-field to egress traffic priorities is shown as follows. Dynamix DW-PhoneLite Administration Guide...
  • Page 31 ====> 14 (Decimal System) 010110 ====> 22 (Decimal System) 011110 ====> 30 (Decimal System) 100110 ====> 38 (Decimal System) 000000 ====> 0 (Decimal System) Please refer to RFC standard documents for more information about what is DSCP. Dynamix DW-PhoneLite Administration Guide...

  • Page 32: Password

    “root”. If a user login with “administrator”, commands below are not functional: Password: set password of login: “root” users. Flash clean: clean all current configurations Rom configuration: upgrade boot sector Rom configuration: upgrade whole 2m software file Dynamix DW-PhoneLite Administration Guide...

  • Page 33: Rom Configuration

    Target File Type: Select which sector of DW-PhoneLite to upgrade. For now, only application can be upgraded. Note: After upgrade Application, please remember to execute Flash Clean, which will clean all configurations become factory values except Network Interface. Dynamix DW-PhoneLite Administration Guide...

  • Page 34: Flash Clean

    10. Flash Clean Please refer to chapter 4.11 [flash] command Press CLEAN will clean all configurations of Dynamix DW-PhoneLite and reset to factory default value. Please reboot after flash clean. Note: User must re-configure all commands all over again (except Network Configure)

  • Page 35: Reboot System

    12. Reboot System Please refer to chapter 4.4 [reboot] command Press reboot will reset Dynamix DW-PhoneLite. Note: To execute reboot via web browser, DW-PhoneLite will automatically save all data before reboot. To execute reboot via TELNET command, please remember to do commit before reboot.

  • Page 36: Chapter 4 Configuring The Dynamix Dw-Phonelite Through Telnetcommand Lines

    Chapter 4 Configuring the Dynamix DW-PhoneLite through Telnetcommand lines After setting the IP Address of Dynamix DW-PhoneLite and reboot, (please refer to LCD Menu: 5-3.4.5), user can enter into Telnet command lines. Note: 1. After user enter DW-PhoneLite configuration via telnet, please use login: ”root”, password: null, press enter to enter command lines.

  • Page 37: Quit] Command

    Type quit/exit/close will logout Dynamix DW-PhoneLite and Telnet Program. 3. [debug] command This command is for engineers to debug system of Dynamix DW-PhoneLite. User can add debug flag via command debug –add “debug flags”, and then start debug function via command debug –open. When Dynamix DW-PhoneLite is working on screen will display related debug messages.

  • Page 38: Commit] Command

    (pbook –modify “index” name “X” ip “xxx.xxx.xxx.xxx” e164 “X”) 6. [commit] command Save any changes after configuring the Dynamix DW-PhoneLite. 7. [ping] command Command ping can test which the IP address is reachable or not. Usage: ping “IP address”...

  • Page 39: Time] Command

    When User set IP mode to be fixed IP, please set IP, subnet Mask, default gateway as mentioned in item 2. If User set IP mode to be DHCP, Dynamix DW-PhoneLite will search for DHCP server to capture IP address after reboot.

  • Page 40: Pppoe] Command

    5. –timeformat: Set time display format as 12 or 24 hours. (ifaddr –timeformat 0/1, 0 as 24 hours, 1 as 12 houts) 6. -ipsharing: If Dynamix DW-PhoneLite is behind a IP-sharing , user must enable IP sharing function and specify public IP address.(ifaddr –ipsharing 0/1 “public IP address of IP sharing”...

  • Page 41: Flash] Command

    Note: 1. After user upgrade new software version, suggested to execute this command to make sure new software work well on Dynamix DW-PhoneLite. 2. To execute the command flash –clean, all configuration of Dynamix DW-PhoneLite stored in flash will be cleaned. It is authorized for the user whose login name is “root”...

  • Page 42: Sysconf] Command

    If after the duration user hasn’t pressed next number, Dynamix DW-PhoneLite will dial out all number pressed. 3. -keypad: set DTMF type .User can select DTMF type Dynamix DW-PhoneLite receive and transmit.(sysconf –keypad 0/1 , 0 for in band ,1 for RFC2833.) 4.
  • Page 43 DW-PhoneLite will set out as abc123@”IP address of Proxy”. This function is for special proxy server. 7. –line: identify one number for the Dynamix DW-PhoneLite to register to the Proxy (SIP –line “line number”). Note: In proxy mode please remember to set user account information under security command.

  • Page 44: Security] Command

    14. [security] command 1. –print: display all current configurations. 2. -name: set user ID of Dynamix DW-PhoneLite for registering. User can set user name and password for registering. If password is no need, please set user name the same as line number or Dynamix DW-PhoneLite won’t register successfully.
  • Page 45 5. -nscng: enable or disable sound compression and comfort noise generation. It is only for codec G.723.1. (0 for off, 1 for on) Note: It is for advanced administrator use only. Please ask your distributor before changing any settings of this command. Dynamix DW-PhoneLite Administration Guide...

  • Page 46: Tos] Command

    3. –siptype: set DSCP value of RTP packets from 0 to 63 Note: This command won’t be functional until whole network environment support DSCP function, e.g. all routers or switches in your network have enabled DSCP feature. Dynamix DW-PhoneLite Administration Guide...

  • Page 47: Bureau] Command

    1. -print: display all current configurations. 2. –hotline: set hotline IP and remote phone number. If user has enable Hotline function, once Dynamix DW-PhoneLite been off-hook, it will automatically dial out to assigned IP and phone number. (bureau –hotline “IP of destination” “Phone number of destination”)
  • Page 48 For example: User prepares to upgrade the latest app rom file – lpsip.100, the TFTP server is 192.168.1.1, User has to input command as below: rom –app –s 192.168.1.1 –f lpsip.100 Command rom –print can show current version installed in DW-PhoneLite. (**) Dynamix DW-PhoneLite Administration Guide...

  • Page 49: Passwd] Command

    2. –clean: clean up password restored before, and user can login :”root/administrator”, password: ”press enter”. User who requests authorization to execute all configuration commands needs to login with “root”. If a user login with “administrator”, commands below are not functional: Dynamix DW-PhoneLite Administration Guide...

  • Page 50: Chapter 5 Upgrading Software On The Dynamix Dw-Phonelite

    Chapter 5 Upgrading Software on the Dynamix DW-PhoneLite Dynamix DW-PhoneLite supports three methods to upgrade the new version. All methods are necessary to prepare the TFTP or FTP program on the host PC as TFTP/FTP server. After installing TFTP/FTP program on one PC and connecting to network, Dynamix DW-PhoneLite is ready to be upgraded.

  • Page 51: Web Management

    1. After 2mb file download is finished, all configurations might change to default values, user has to configure again. 2. After upgrade Application, please remember to execute Flash Clean, which will clean all configurations become factory values except IP address. Dynamix DW-PhoneLite Administration Guide...

  • Page 52: Telnet Command Lines

    7. –ftp: specify user name and password for FTP download method. For example: User prepares to upgrade the latest app rom file – lpsip.100, the TFTP server is 192.168.1.1, User has to input command as below: rom –app –s 192.168.1.1 –f lpsip.100 Dynamix DW-PhoneLite Administration Guide...
