Autoseeker Electronics A680-1 User Manual

Watch tracker
Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

Download this manual
GPS Watch Tracker A680-1 User Manual
I
Key Definition
ON / OFF
USB Port
Call / Answer / SOS
Pre-set Call 1
Pre-set Call 2 guardian
Pre-set Call 3
II
Specification
III
Operation
1.
Turn on
Press and hold the key
the current time ,date automatically.
2.
Turn off
GPS on, positioning.
GPS on, not yet position.
Management platform turn on. The device connecting
the platform through GPRS network, the platform can
send commands to the tracking device.
Device sending position information to the platform.
Tracking record turn on.
Quiet mode turn on.
Allows only incoming preset number
Closes the GPS localization pattern
till it shows the turn on Logo, then it will enter the main interface and show
Display icon

Advertisement

loading
Need help?

Need help?

Do you have a question about the A680-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Autoseeker Electronics A680-1

Summary of Contents for Autoseeker Electronics A680-1

  • Page 1 GPS Watch Tracker A680-1 User Manual Display icon Key Definition GPS on, positioning. GPS on, not yet position. ON / OFF Management platform turn on. The device connecting USB Port the platform through GPRS network, the platform can send commands to the tracking device.
  • Page 2 When stand by, press and hold the key to turn off. The operation will be finished after displaying image shutdown. SOS signals When the tracker standby ( with SIM card): press and hold the key for 3 seconds, the tracker will shock for once indicating to enter “one press help”...
  • Page 3 Message: To check message received. Press the key once to enter the function menu interface, press to select the message.If there’s no message, the screen will be blank; if with message, it will enter the message list interface. It can be stored with 19 messages.
  • Page 4 Type Command Instruction Function Remarks Set guardian 11# mobile phone number Set guardian numbers, The initial password is 0000. numbers # password Example: You can set 2 SOS numbers : Set SOS numbers 12# sos1# sos2 12#12345678910#12345678911 Example: changed the password to 1234 13#0000#1234 13#old password # Password...
  • Page 5 save power,just turn off if platform connection no longer need. To forward the received SMS to the guardian mobile phone. SMS forward 35#0 OFF Default ( messages from the guardian excluded) settings 35#1 open This’s available for guardian in mainland China only. 23# Ask for dialing back.
