Basler ace acA645-100 User Manual

Usb 3.0 cameras
Table of Contents

Advertisement

Basler ace
USER'S MANUAL FOR USB 3.0 CAMERAS
Document Number: AW001234
Version: 04 Language: 000 (English)
Release Date: 17 June 2015
The manual includes information about the following
prototype cameras: acA645-100, acA1920-155.
