Introduction

These instructions show how to change the serial address and how to mount ALPHA series signs with NEMA Types 2,

4, 4X, and 12 enclosures. Type 2 enclosures are intended for indoor use primarily to provide a degree of protection against

limited amounts of falling water and dirt. Type 4 enclosures are intended for indoor use primarily to provide a degree of

protection against windblown dust and rain, splashing water, and hose-directed water. Type 4X enclosures are intended for

indoor use primarily to provide a degree of protection against corrosion, windblown dust and rain, splashing water, and hose-

directed water. Type 12 enclosures (in a gasketed, dust free, sealed, spray down resistant case) are intended for indoor use.

Changing the serial address

NOTE: Instructions for Changing the serial address on ALPHA 420 signs are on page 13.

Instructions for Changing the serial address on 2.1" NEMA 2 signs are on page 24.

Instructions for Changing the serial address on 3.2" NEMA 2 signs are on page 29.

NOTE: ALPHA Series 4000 and 7000 signs (in NEMA 2, 4, and 4x enclosures, only) use a jumper connection to select

between RS232 and RS485 serial modes. See inset box "NOTE", below right.

A serial address for an ALPHA sign is a number from 0 to 255 in hexadecimal (00 to FF). A serial address for an

ALPHA sign with Smart Alec option is a number from 000 to 255 in decimal (000 to 255.) The address is used to identify the sign

in a network of signs. All signs leave the factory with a default address of 0 or 000.

To change a sign's serial address, follow these steps:

REMOTE CONTROL

1. Point a hand-held Remote Control (shown at left) at the sign, and press PROGRAM.

ON - OFF

SOUND

PROGRAM

RUN

2. Press BACK until SET SERIAL ADDRESS appears on the sign.

APPEND CURSOR SPECIAL FONT

WIDTH

COLOR

ROLL

WIPE

SCROLL FLASH

HOLD

ROTATE

AUTO

SPEED

TIME

DOT

SELECT

3. Press ADV and SERIAL ADDRESS = 00 will appear.

4. Type in the new serial address using the numbered keys on the Remote Control.

;

SPACE

RETURN

5. Press RUN twice to set the new serial address and return the sign to normal operation.

SHIFT

CAPS

SHIFT

INSERT

BACK

ADV

DELETE

Checkout procedure

After installing a sign according to the following section on "Mounting instructions", make sure the sign is installed

properly by applying power to it. The following information should be displayed on the sign:

•

firmware part number and version letter (e.g., 1018-4403d),

•

model number of the sign (e.g., N024160C),

•

amount of RAM in the sign, (e.g., 256K), and

•

serial address of the sign (a number from 0 to FF or from 000 to 255).

Mounting precautions

NOTE: Only qualified personnel should install the ALPHA NEMA signs.

Before mounting a sign,

remove power from the sign!

NOTE: ALPHA NEMA 2, 4, 4X, and 12 signs are for indoor use only. Do not continuously expose to direct sunlight.

NOTE: Mounting hardware that is used to hang or suspend signs must be capable of supporting at least 4 times the

total weight of any/all signs mounted together.

NOTE: For integrity of the case, do not drill holes in or modify the case.

Revision date: 1/26/01

The following are trademarks of Adaptive Micro Systems: Adaptive, Alpha, AlphaNet plus, AlphaEclipse, AlphaPremiere, AlphaTicker, AlphaVision, AlphaVision InfoTracker, Automode,

The distinctive trade dress of these products is a trademark claimed by Adaptive Micro Systems, Inc.

BetaBrite, BetaBrite Director, BetaBrite Messaging Software, Big Dot, PPD, Smart Alec, Solar, TimeNet

ALPHA NEMA Series Sign

Installation Instructions

NOTE: When you set up for serial communication some ALPHA signs

require that you physically select a jumper for RS232 or RS485 serial

mode. Refer to "Select serial communication mode" on page 4 and

"Electrical instructions–serial communication" on page 18. NEMA 12

models are directly wired to a terminal block under the power supply

cover as RS485 or as RS232. There is no jumper.

WARNING

Hazardous voltage.

Contact with high voltage may

cause death or serious injury.

Always disconnect power

to sign prior to servicing.

9707-7004G
