Events
You can also modify the behavior of zones of this type for certain events, like Connection to
camera lost or Motion detected.
The event View selected in Observer Client works this way: If there is an LNT zone with the
same name as the view in Observer then the corresponding action is triggered.
3. Click OK to save changes.
14.5.4 Adding a new zone control
1. Switch to customizing mode by choosing Project > Editing mode or by pushing the customize
button at the right side of the tool bar.
2. In the control icon list click the right mouse button and choose Add zone... from the pop-up
menu. This opens the New zone dialog which is essentially the same as the Modify Zone dialog
(see 14.5.3 Modifying zone control appearance and behavior on page 133).
3. Click OK to create the new zone control.
14.5.5 Modifying I/O contact control appearance and behavior
1. Switch to editing mode by choosing Project > Switch to editing mode or by pushing the
editing button
2. In the control icon list click on an I/O control icon with the right mouse button and choose
Modify... from the pop-up menu. This opens the Modify control dialog for the corresponding
I/O control type:
In this dialog you can define the name of the control and the two images for activated and
deactivated states. For the Impulse Button you can also set the Impulse Duration (ms) and
whether 0 or 1 should be set. The control type (Input, Output, Impulse Button) cannot be
modified.
3. Click OK to save changes.
14.5.6 Adding a new I/O contact control
1. Switch to customizing mode by choosing Project > Switch to editing mode or by pushing the
customize button
at the right side of the tool bar.
at the right side of the tool bar.
