Lumenpulse DMXrdm Reference Manual

RDM Reference Guide
Client
Order#
DESCRIPTION
Remote Device Management (RDM) is an enhancement of
DMX that allows bi-directional control and feedback from
lighting fixtures and devices.
DMX
DMX/RDM
FEATURES AND BENEFITS
DMX/RDM provides a number of benefits for stakeholders
throughout the construction, commissioning and property
management stages.
• Simplify fixture discovery: RDM controllers can discover
any RDM-enabled devices on the network.
• Improve error reporting: An alert system reports back
potential issues, including "Over Temperature" and "Over
Voltage".
• Enable remote DMX addressing: With RDM,
technicians can remotely query and update the DMX
address and other parameters of the fixture profile.
• Update firmware: Allows for easy discovery and
updating of the fixture firmware via the new fixture
firmware bootloader.
DMX/RDM PROTOCOL LIMITS
Data length: 1000' between boosted devices
Number of devices connected to a CBX: 32 per output
Cascading CBX limit: 4
1/3
© Copyright Lumenpulse 2015
1751 Richardson, Suite 1505
23/OC/2015
Montreal (Quebec) Canada
E. Martin - Rev.1
H3K 1G6
Type
5-year limited warranty.
1.877.937.3003
P.514.937.3003
F. 514.937.6289
Consult www.lumenpulse.com
info@lumenpulse.com
for our complete Standard Terms
www.lumenpulse.com and Conditions of Sales.
Project name
Qty
Lumenpulse reserves the right to make changes to this product at any time
without prior notice and such modi cation shall be effective immediately.
Your fixture
has a lot to say.
› Hello my name is Lumenbeam ™ Small
› My DMX address is 125
› My temperature is 32° C
› My personality is 16-bit
› Remaining hours till L70: 102,567
› My serial number is 06500005
