CRITTER & GUITARI - Kaleidoloop Manual
The Critter & Guitari KALEIDOLOOP is a social, portable sound collector. It's designed to be taken
anywhere and everywhere to gather and manipulate all kinds of sounds. Record sounds from your
kitchen, the recording studio, and campfire jam. The KALEIDOLOOP lets you sample and tweak!
This is the layout for the control surface of the KALEIDOLOOP:
SPEAKER
The reference sticker on the bottom of the Kaleidoloop looks like this:
www.critterandguitari.com
ZERO ONE - No Worries!
POWER 9VDC LINE OUT LINE IN/MIC IN
SWITCH (MONO) (MONO)
SPEED &
DIRECTION VOLUME
RECORD/PLAY
STEPPED/CONTINUOUS
MODES TOGGLER
⥋
( )
BACK
FWD
STATUS LED
SD CARD
™
Updated May 1 2012
POWER 9VDC LINE OUT
SWITCH (MONO)
SPEED &
DIRECTION
BACK
STATUS LED
STEPPED/CONTINUOUS
MODES TOGGLER
⥋
( )
SD CARD
KALEIDOLOOP
TM
CRITTER & GUITARI
TM
The SPEED & DIRECTION knob controls tuning. In STEPPED
MODE ( ), playback steps along the following divisions.
As the playback speed increases, so will brightness of LED.
��
��
BACKWARDS FORWARDS
1
™
LINE IN/MIC IN
(MONO)
VOLUME
RECORD/PLAY
FWD
On power up, the STATUS LED flashes up to four times
to indicate how full memory card is:
If there is a problem, the STATUS LED will repeatedly
flash one of these patterns:
No SD card or error: Try inserting new card.
Problem with SD card. Try reformatting it.
Erase SD Card
��
To ERASE/FORMAT card, turn off device, hold down
Record/SkipFWD/SkipBKWD buttons while turning
device on. LED will flash 3 times, pause, and flash 3
��
times again. It is now ready for recording.
For more information on KALEIDOLOOP, please visit:
www.critterandguitari.com/kaleidoloop
0 - 25% full
25 - 50% full
50 - 75% full
75 - 100% full
© 2012. All Rights Reserved. Philadelphia, USA.
