R I D E R ' S H A N D B O O K
M o d e l H C X T S u p p l e m e n t
E X C E L S I O R - H E N D E R S O N
M O T O R C Y C L E
M A N U F A C T U R I N G
C O M P A N Y

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCXT and is the answer not in the manual?

Questions and answers

Summary of Contents for Super X HCXT

  • Page 1 R I D E R ' S H A N D B O O K M o d e l H C X T S u p p l e m e n t E X C E L S I O R - H E N D E R S O N M O T O R C Y C L E M A N U F A C T U R I N G C O M P A N Y...
  • Page 2 805 HANLON DRIVE • BELLE PLAINE, MINNESOTA 56011 • TELE: 612.873.7000/FAX: 612.873.7030 Copyright©1999 Excelsior-Henderson Motorcycle Manufacturing Company. All rights reserved. Super X and X-Twin are registered trademarks, and Excelsior-Henderson, the X & Bar logo, the Super X Logo, Rider’s Handbook, and Road Crew are trademarks of Excelsior-Henderson Motorcycle Manufacturing Company.

  • Page 3: Table Of Contents

    Contents Introduction..............1 Read the Model HCXT Supplement ........1 Hazard Symbol and Terms in the Supplement .....2 Safety Information ............3 Gross Vehicle Weight Rating ..........4 Loading................5 Highway Bar..............6 Safety and Vehicle Information Labels.........7 Product Description ............11 Vehicle Components ............11 Instruments and Controls ..........13 Location .................13...
  • Page 4 Contents Electrical Equipment............17 Driving Lamps ............17 Maintenance ..............19 Saddle ................20 Electrical Equipment............20 Check Driving Lamps..........20 Adjust Driving Lamps ..........21 Replace Driving Lamp Bulb ........22 Windshield ..............22 Adjust Windshield Height and Tilt........ 22 Adjust Windshield Air Gap ..........

  • Page 5: Introduction

    Introduction Read the Model HCXT Supplement The Model HCXT Supplement is designed to be used in conjunction with the Super X Riders Handbook. The HCXT Supplement contains information that is specific to the Super X Model HCXT motorcycle. Read the Rider’s Handbook and the Model HCXT Supplement thoroughly before you ride.

  • Page 6: Hazard Symbol And Terms In The Supplement

    Pay special attention to information in the Model HXCT Supplement that begins with this symbol. The following terms have special meaning in the Model HCXT Supplement. Be certain you understand the meaning of each term, as the terms communicate important information about the motorcycle and its operation and maintenance.

  • Page 7: Safety Information

    Safety Information This section contains information to help you operate your Super X Model HCXT motorcycle safely and enjoyably while minimizing risk to you, your passenger, and others. Your ability to safely operate the motorcycle depends on your judgment and use of safe riding techniques. Motorcycling has inherent risks.

  • Page 8: Gross Vehicle Weight Rating

    The gross vehicle weight rating of the Super X Model HCXT is 1140 lb. The total weight of the Super X Model HXCT is approximately 780 lb with a full capacity of all fluids, and without any cargo.

  • Page 9: Loading

    Safety Information Super X Model HCXT with cargo Item Weight Super X with full capacity of all fluids 780 lb Attached cargo 30 lb Rider - dressed and ready to ride 205 lb Passenger - dressed and ready to ride...

  • Page 10: Highway Bar

    Safety Information weight distribution, or cargo that shifts suddenly while you are riding, can make the motorcycle hard to handle and cause you to lose control of the motorcycle. • Do not attach large or heavy cargo such as sleeping bags, duffle bags, or tents to the handlebars, front fork area, or front fender.

  • Page 11: Safety And Vehicle Information Labels

    Safety Information Safety and Vehicle Information Labels 10771 Super X Model HCXT — left side view WARNING WARNING To maintain stability and balance: USE ONLY DOT5 BRAKE FLUID FROM A SEALED CONTAINER. • Do not exceed 15 lbs. in each CLEAN FILLER CAP BEFORE saddlebag.
  • Page 12 Safety Information 10772 Super X Model HXCT — right side view MOTORCYCLE NOISE EMISSION WARNING CONTROL INFORMATION To maintain stability and balance: This 2000 Excelsior-Henderson EMC42X1386 motorcycle, • Do not exceed 15 lbs. in each 4599-0029, meets USEPA noise emission requirements of 80 dBA at 2750 RPM by the Federal test procedure.
  • Page 13 Safety Information 10773 Super X Model HCXT — left side view (California model only) (Under seat)

  • Page 15: Product Description

    Product Description This section identifies the additional components found on the Super X Model HCXT motorcycle and shows their locations. Vehicle Components 10774 Super X Model HCXT 1. Windshield 4. Sissy Bar 6. Luggage Carrier 2. Driving Lamp 5. Backrest Pad 7.

  • Page 17: Instruments And Controls

    Instruments and Controls This section shows you where to find additional controls on the Super X Model HXCT motorcycle and explains their function and use. Location 10775 1. Windshield height and tilt adjustment 3. Driving Lamp Switch 2. Windshield air gap adjustment...

  • Page 18: Windshield

    Instruments and Controls Windshield The windshield can be adjusted to one of four different heights. It may also be tilted slightly forward or rearward to remove any reflections or glare caused by highly polished or plated components. The air gap between the bottom of the windshield and the top of the headlamp can also be adjusted.

  • Page 19: Pre-Operation Check

    Pre-Operation Check To keep your Super X Model HCXT motorcycle in good working order, make the checks described in this section before each ride. This is especially important before you make a longer trip or when you remove the motorcycle from storage.

  • Page 20: Tires

    CruiseMax 140/90-16 WW TL 36 psi (cold) Tire Condition Inspect the tire sidewalls, road contact surface, and tread base for cuts, punctures, and cracking. Replace damaged tires immediately (see your Super X Service Handbook or an authorized Excelsior-Henderson Dealer).

  • Page 21: Tread Depth

    (usually near the center of the tire surface). Replace a tire with a tread depth less than 1/16” (see your Super X Service Handbook or an authorized Excelsior- Henderson Dealer).

  • Page 23: Maintenance

    Choose a flat, firm surface for servicing the motorcycle. Make sure you have the time, tools, and expertise to complete a procedure properly. For information on major repairs, see the Super X Service Handbook. Major repairs typically require the technical skills and specially designed tools available from your authorized Excelsior-Henderson Dealer.

  • Page 24: Saddle

    Maintenance Saddle To remove the saddle: 1. Remove the saddle screw. 2. Lift the back of the saddle slightly and pull it to the rear, out from the saddle post. To install the saddle: 1. Slide the front of the saddle into the saddle post at the rear of the fuel 10731 tank.

  • Page 25: Adjust Driving Lamps

    Maintenance Adjust Driving Lamps Each lamp should shine straight ahead or slightly to the right of the motorcycle. The top of each lamp beam should be just below the center of the lamp at a distance of 25 feet. 1. Stand the motorcycle in an upright position. 2.

  • Page 26: Replace Driving Lamp Bulb

    Maintenance Replace Driving Lamp Bulb Make sure the driving lamps are cool to the touch, and that the main switch and the driving lamp switch are in the Off position. 1. Loosen the driving lamp bezel screw. While supporting the bulb, gently spread the bezel and remove it from the lamp body.
  • Page 27 Maintenance 1. Support the windshield and remove the 4 mounting screws. Notice When adjusting the windshield downward, loosen the windshield pinch screws and slide the windshield insert all the way up. 2. Select the appropriate windshield height and install the 4 mounting screws finger tight.

  • Page 28: Adjust Windshield Air Gap

    Maintenance Adjust Windshield Air Gap Adjust the amount of air gap between the top of the headlamp and the bottom of the windshield to approximately 1/4”. 1. Loosen the windshield pinch screws. 2. Move the windshield insert to the desired position.

  • Page 29: Check Tire Surface Condition

    Maintenance Check Tire Surface Condition Inspect the tire sidewalls, road contact surface, and tread base for cuts, punctures, and cracking. Replace damaged tires immediately (see your Super X Service Handbook or an authorized Excelsior-Henderson Dealer). Tread Depth Raised areas at the base of the tread, known as wear bars, act as easily-visible tread depth indicators.

  • Page 31: Cleaning And Storage

    Cleaning and Storage This section explains how to properly clean the various parts of the motorcycle that are unique to the Super X Model HCXT. Cleaning Clean your motorcycle regularly to protect it from corrosion and to keep it looking new.

  • Page 32: Windshield Care

    Cleaning and Storage Windshield Care Wash the windshield using a soft cloth or sponge soaked in a solution of mild detergent and warm water, applying minimal pressure as you wash. Let the detergent do the cleaning, not the pressure you apply. Excessive washing pressure may cause dirt, sand, or other foreign materials on the windshield to scratch it.
  • Page 33 Cleaning and Storage Caring for natural leather is similar to caring for your own skin. To prevent leather from becoming hard and dry, occasionally apply a leather conditioner. A good quality leather conditioner replaces the natural oils lost by repeated exposure to sun, wind, and rain.

  • Page 35: Specifications

    Specifications Dimensions Fuel system ..port sequential, closed Overall length ....92.5" loop fuel injection Overall width .
  • Page 36 Specifications Chassis Wheels Frame type ... . . tubular steel, Type: double cradle Front ... . stainless steel 40 spoke Front suspension .
  • Page 37 Specifications Electrical Low oil pressure ..ANSI #74 Ignition system: Low battery voltage . . . LED Type....inductive coil Low fuel .
