Batch Printing
Touch Screen Calibration
To calibrate the touch screen, turn on the power while touching the screen. A red box appears, with a small black
dot in the middle. Calibrate the screen by touching in the center of each red box that appears (3 times). The
Terminal powers up normally after the calibration is completed.
CAUTION:
Be careful to not have a finger on the screen while starting the machine unless you wish to calibrate.
1.877.7ithaca
(1.877.748.4222)
Batch Printing
Batch printing is an optional feature that allows a
pre-determined list of items to be brought up at
once by selecting the item category button BATCH
PRINT. Once selected, the user can alter the
numbers of each label printed using the arrow keys.
Without administrator privileges, all that can be
done is alter the numbers and print – with a
password the name and details of a batch can be
altered on this screen. For more information, see
the main 9700 manual.
Food Safety Terminal
Quick Start Guide
PN: 100-12043 REV E
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ithaca 9700
Summary of Contents for Ithaca 9700
- Page 1 For more information, see Quick Start Guide the main 9700 manual. Touch Screen Calibration To calibrate the touch screen, turn on the power while touching the screen. A red box appears, with a small black dot in the middle.
- Page 2 Front Terminal Door If included, this is also where Menu Updates via Network This swings upward to provide access to the would be accessed. See the main 9700 manual for more label rolls as well as the printing mechanisms information.
-
Page 3: Main Screen
(above example being Grab N Go). ters in the name of the first item on each page. new ones, as well as update your 9700. Function Buttons Save and Load Data File are used to change your label data (MenuData.xml) files, and the Update and... - Page 4 Print Left / Print Right Help These buttons print labels using the two print devices included in your Ithaca 9700 printer. Your printer should be configured Pressing the help button brings up the help topics for what best serves your business needs – you can print a dissolvable label on one side, and a freezer label on the other, or menu –...
Need help?
Do you have a question about the 9700 and is the answer not in the manual?
Questions and answers
Why won't my machine load up and why is it beeping
The Ithaca 9700 machine may not be loading and is beeping due to one or more of the following reasons:
1. Label Stock Issue – Ensure that the label stock is correctly loaded in the left paper bucket with labels facing up and positioned under the sensor arm.
2. Printing Mechanism Not Closed – Check if the left printing mechanism is properly closed after loading the labels.
3. USB Drive Not Inserted Correctly – If performing a menu update, confirm that the USB drive is inserted in the correct orientation.
4. ID Requirement or Admin Settings – If ID entry is required before printing, verify that the correct credentials are entered.
5. Date and Time Not Set – Ensure the date and time settings are correctly configured in the system.
Check these factors to resolve the issue.
