Summary of Contents for Lectrosonics Quadpack
- Page 1 INSTRUCTION MANUAL Quadpack Power/Audio Adapter Power & Audio Adapter for SRa Series Compact Receivers Fill in for your records: Serial Number: Purchase Date: Rio Rancho, NM, USA www.lectrosonics.com...
-
Page 2: Table Of Contents
QUADPACK Table of Contents General Technical Description ................................3 Side Panels ......................................3 Receiver Installation ...................................4 Receiver Removal ....................................4 Replacement Parts & Accessories ..............................5 Specifications .....................................6 Service and Repair .....................................7 LECTROSONICS, INC. -
Page 3: General Technical Description
The Quadpack keeps it all neatly routed and easy to access with one set of audio outputs to feed a recorder and the other to feed the mixer. -
Page 4: Receiver Installation
DB25 connector, and (–) sliding it in until it seats firmly. The front panel flange (–) should sit flush with the top panel of the Quadpack. Pin 4 Pin 1 7 to 18 VDC 400 mA max. -
Page 5: Replacement Parts & Accessories
Receiver Power & Audio Adapter Replacement Parts & Accessories 21586 6 ft. long power cable; locking LZR DCR15/1A6U Power supply. 90-240 VAC, 50/60 Hz style plug to stripped and tinned input; 15 VDC (regualted), 1.6 A max. leads. ouput, 18 W, lockihg LZR style plug 21746 Power cable with locking, right angle MCSRPT... -
Page 6: Specifications
QUADPACK Specifications Dimensions: H 4.95 in. x W 9.40 in. x D 1.40 in. Weight: Assembly only: 1 lbs., 5 ozs. (0.6614 kg) With 2-SRa5P receivers: 2 lbs., 3 ozs. (1.031 kg) With 2-SRa5P receivers: 2 lbs., 4 ozs. (1.077 kg) -
Page 7: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a mod- est flat rate plus parts and shipping. - Page 8 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
