- Page 1 Electromechanical Lock LC-72.4 Assembly and operation manual...
- Page 2 Electromechanical Lock LC-72.4 Assembly and Operation Manual...
-
Page 3: Technical Specifications
Assembly and Operation Manual 1. APPLICATION The LС-72.4 electromechanical mortise door lock (hereinafter – the lock) is designed to control light and medium office doors. The lock can be installed in wooden and non-metal doors 38–50 mm thick. The lock is universal because it is compatible both with right-handed and left-handed doors using standard lock cylinders (Chapter 6). -
Page 4: Design Features
LC-72.4 Electromechanical Lock 6. DESIGN FEATURES Design and composition of the lock is shown in Fig. 1. Fig. 1 LС-72.4 electromechanical lock design. 1 - Lock; 2 - Forend; 3 - Door lever with escutcheon plates ; 4 - Screw 4×30;... -
Page 5: Operating Principle
You just need to shut the door to lock it, without turning the lever due to locking bolt moves to the skew. Position Unit Quantity Note Power supply unit 12V, 0.5A, 6W Lock controller Lock Reed switch Fig. 2 LC-72.4 electromechanical lock connection layout... -
Page 6: Installation Instructions
LC-72.4 Electromechanical Lock For regular operation an ACS controller, controlling the lock, should have possibility of connecting reed switch to it. Lock connection scheme is shown in Fig. 2. The lock is connected to controller with no order to signal polarity. Power supply unit (A1) parameters should correspond to controller (A2) parameters. - Page 7 Assembly and Operation Manual the lock connector block. After that install the lock in the locating pocket of the door and fasten it with screws from the delivery set; Mount the lock cylinder (7) inside the lock (1) and fix it with the screw through hole on the front plate of the lock (1) (lock cylinder is not included in the delivery set);...
-
Page 8: Transportation And Storage
Customer. Transportation cost to and back from the place of repair shall be borne by the Customer. Company PERCo is always ready to give you necessary technical support in case of any question arise during the Product assembly or operation. - Page 9 PERCo P.O. Box 87, Saint Petersburg, 194295, Russia Tel: +7 812 321 61 72 Fax: +7 812 516 48 76 e-mail: support@perco.ru www.percoweb.com...
