OWNER'S MANUAL
51-01 Cypress
51-03 Vesuvius
51-07 Ziggurat
51-08 Santorini
51-08C Classico
51-08CP Hammered Copper
51-08H Hacienda
51-08R Richmond
51-10 Santorini
A HIGHER STANDARD IN QUALITY AND APPEARANCE - SAFE AND BEAUTIFUL OUTDOOR
* Select link below to download French instructions.
* Sélectionnez le lien ci‐dessous pour
télécharger les instructions françaises.
http://www.owlee.com/technical-information.aspx
CODE AND SUPPLY REQUIREMENTS: When an appliance is for connection to a fixed piping system, the installation
must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA
54, International Fuel Gas Code, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and
Handling Code, B149.2, as applicable.
WARNING
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be stored within 60" of this
unit or any other appliance.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and immediately call
your gas supplier or fire department.
CARBON MONOXIDE HAZARD
DANGER
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car, or
home
51-10C Classico
51-10CP Hammered Copper
51-10H Hacienda
51-10R Richmond
51-11 Santorini
51-16 Vulsini
51-16V Viento
51-22 Vulsini
51-37 Santorini
CASUAL FIRESIDE
FIRE PIT FOR PROPANE AND *NATURAL GAS
WARNING: FOR OUTDOOR USE ONLY
Report #521-O-02-5
Tested & Certified to
ANSI Z21.97-2014/CSA 2.41-2014
CGA 2.17-M91 (R2009)
TM
* Needs Conversion Kit
WARNING
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Read
the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
This appliance is designed as an
"attended appliance". Adults must be
present when the unit is operating.
DO NOT leave this unit burning when
unattended. If this product is left burning
unattended it may cause damage or
serious injury.
INSTALLER - Owner's Manual must be left with
the consumer for future reference.
CONSUMER – Owner's Manual must be saved
for future reference.
V2-070515
Advertisement
Summary of Contents for Owlee 51-01 Cypress
- Page 1 OWNER'S MANUAL 51-01 Cypress 51-10C Classico 51-03 Vesuvius 51-10CP Hammered Copper 51-07 Ziggurat 51-10H Hacienda 51-08 Santorini 51-10R Richmond Report #521-O-02-5 51-08C Classico 51-11 Santorini Tested & Certified to 51-08CP Hammered Copper 51-16 Vulsini ANSI Z21.97-2014/CSA 2.41-2014 CGA 2.17-M91 (R2009)
- Page 2 OUTDOOR FIRE PIT - TABLE OF CONTENTS Cover - Important Safety Information Table Of Contents Important Safety Information Minimum Clearances to Combustibles Pre-Installation & Preparation Guidelines Installation Information Connecting the Gas to the Fire Pit Certified Media List Glass Media Installation Gem, Mirriored, Tumbled Glass and Ceramic Log Installation Ceramic Rock and Sphere Media Installation Operation Instructions...
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION Before installing this Outdoor Fire Pit, check “Minimum Clearance to Combustibles” on page 2. MINIMUM CLEARANCES must be maintained when you install this Outdoor Fire Pit. THERE MUST BE AT LEAST 60” (1.5 m) from the center of the burner to any combustible sidewall, ceiling, or material. The Outdoor Fire Pit is for outdoor use only. -
Page 4: Operating Instructions
IMPORTANT SAFETY INFORMATION OPERATING INSTRUCTIONS YOUNG CHILDREN SHOULD BE CAREFULLY SUPERVISED WHEN THEY ARE IN THE AREA OF THIS APPLIANCE. DO NOT sit or place any part of the body or combustible materials on the Fire Pit surround. Children and adults should be alerted to the hazard of high surface temperatures and should stay away to avoid burns or clothing ignition. - Page 5 INSTALLATION INFORMATION CONNECTING THE GAS TO THE FIRE PIT IMPORTANT BEFORE PROCEEDING, CAREFULLY READ ALL OF THE IMPORTANT SAFETY INFORMATION CONTAINED IN THIS OWNER'S MANUAL, INCLUDING: Pre‐Installation and Outdoor Fire Pit Preparation Safety Guidelines (page 3). Media Installation Guidelines (Page 6‐8). Minimum Clearance to Combustibles (page 2). LP-GAS CYLINDER INFORMATION: Cylinder Size: 20 Lbs. (9kg) Capacity: 4.7 Gallons (17.8 Liters). The LP-gas cylinder(s) to be used must be constructed and marked in accordance with the U.S.
- Page 6 LAVA GRANULES MEDIA PLACEMENT Carefully inspect the carton for shipping damage. If any parts are missing or damaged, call your dealer. Do not attempt to install the appliance unless all parts are in good condition. Correct installation is crucial to safe performance of your Outdoor Fire Pit. Due to high temperatures, the Fire Pit must be located out of traffic areas and away from combustibles. LAVA GRANULES AND GLASS MEDIA PLACEMENT REPLACEMENT PARTS AND MEDIA ARE AVAILABLE THROUGH YOUR LOCAL DEALER Stainless Steel Rectangle Burner Kit Approved Media:...
- Page 7 GEM, MIRRIORED AND TUMBLED GLASS MEDIA PLACEMENT Carefully inspect the carton for shipping damage. If any parts are missing or damaged, call your dealer. Do not attempt to install the appliance unless all parts are in good condition. Correct installation is crucial to safe performance of your Outdoor Fire Pit. Due to high temperatures, the Fire Pit must be located out of traffic areas and away from combustibles. GEM, MIRRIORED AND TUMBLED GLASS MEDIA PLACEMENT Pour the glass gem / tumbled glass media into the Outdoor Fire Pit so that the burner is completely covered.
- Page 8 CERAMIC ROCK AND SPHERE MEDIA PLACEMENT Ceramic Rock Placement (See Figure 1, 2 and 3) Figure 2. Figure 3. Figure 1. Place the larger rocks Lay the smaller stones on top Pour the lava granules into allowing gaps for proper of the larger stones allowing the burner support.
-
Page 9: Lighting Instructions
OPERTATING INSTRUCTIONS *We recommend that before you install your Fire Pit you familiarize yourself with the control valve layout. This will help you to be confident operating the Fire Pit when fully installed (see figures below for typical control positions). FOR YOUR SAFETY, READ BEFORE LIGHTING VWARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE,... - Page 10 CONVERTING YOUR FIRE PIT TO A DIFFERENT GAS TYPE MAKE SURE THAT THE GAS SUPPLY TO THE FIRE PIT (AND ANY NEARBY ELECTRICAL SOURCES/APPLIANCES) ARE SHUT OFF. Carefully detach the flex line connector hose attached to the orifice holder (Figure # 1) and unscrew the orifice holder from the burner pipe (Figures #1 and # 2).
