96M5771o
Single Board Computer
User's Manual
Edition 1.0
2007
k

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 96M5771o and is the answer not in the manual?

Questions and answers

Related Manuals for DSM Computer AG 96M5771o

Summary of Contents for DSM Computer AG 96M5771o

  • Page 1 96M5771o Single Board Computer User’s Manual Edition 1.0 2007...

  • Page 2: Preface

    Any implied warranties of merchantability of fitness for any particular purpose is also disclaimed. Acknowledgements The 96M5771o is a trademark of DSM Computer AG. All other product names mentioned herein are registered trademarks of their respective owners. Regulatory Compliance Statements This section provides the FCC compliance statement for Class A devices and describes how to keep the system CE compliant.

  • Page 3: Ce Certification

    Safety Information Before installing and using the 96m5771o, note the following precautions: Read all instructions carefully. Do not place the unit on an unstable surface, cart, or stand.

  • Page 4: Table Of Contents

    Chapter 2 Jumper Setting 2.1 Before you begin 2.2 Precautions 2.3 Setting Jumpers 2.4 Location of Jumpers 2.5 Function of Jumper Chapter 3 Expansion 3.1 System Memory 3.2 Installing DIMM 3.3 Installing Compact Flash 96M5771o User's Manual / Page 4...

  • Page 5: Chapter 1 General Information

    Chapter 1 General Information 96M5771o User's Manual / Page 5...

  • Page 6: Product Overview

    CompactFlash Socket Product Overview: The 96M5771o is a 5.25” embedded board featuring Intel Core Solo, Core Duo and Core 2 Duo processor with 533/667 MHz FSB; speed up to 2.33 (2.0) GHz. The 96M5771o offers high performance and various processors and PCI Express; versatile display and I/O port selections, which is the best solution for advanced embedded applications.

  • Page 7: Specifications

    2 x RJ45 with LED connector Active, Link 100, and 1000 LAN LED LAN Status LED defined: 10: LED Off / 100: Green LED / 1000: Orange LED Extra (External) LED: 2 x 4 pin header 96M5771o User's Manual / Page 7...
  • Page 8 43.2 W in 12V, 121.2 W in 5V, and 11.5W in 5Vsb Environment Operating Temperature 0°C ~ 60°C Storage Temperature -20˚C to 85˚C Operating 10%~90%, non-condensing Relative Humidity Non-operating 5%~95%, non-condensing Certifications CE approval FCC Class A 96M5771o User's Manual / Page 8...

  • Page 9: Ordering Information

    Ordering Information: 5.25” Embedded Board supporting Intel Core Solo, Core Duo and 96M5771o Core 2 Duo CPU w/VGA/ Dual LVDS/Audio/4 COMs/6 USB2.0 /Dual Gigabit LAN 1.3 Power Consumption Measurement 96M5771o User's Manual / Page 9...
  • Page 10 The Data is based on fully possible configurations installed on 96M5771o include the Add-on Card, and peripherals such as USB devices, SCSI Card and SCSI HDD. Test Criteria: 1. Test configuration is include 96M5771o, HDD, CD-ROM, and FDD. 2. Full loading mode should utilize CPU 100% with run Burn-in test program.

  • Page 11: Board Layout

    1.4 Board Layout Figure 1.2: Overview 1.5 Board Dimensions Figure 1.3: Mechanical Drawing 96M5771o User's Manual / Page 11...

  • Page 12: Chapter 2 Jumper Setting

    Chapter 2 Jumper Setting 96M5771o User's Manual / Page 12...

  • Page 13: Before You Begin

    • Hold electronic circuit boards by the edges only. Do not touch the components on the board unless it is necessary to do so. Don’t flex or stress the circuit board. 96M5771o User's Manual / Page 13...

  • Page 14: Setting Jumpers

    OPEN. Open (Off) Short (On) These illustrations show a 3-pin jumper. Pins 1 and 2 are SHORT. Table 2-1: Setting Jumpers 96M5771o User's Manual / Page 14...

  • Page 15: Location Of Jumpers

    2.5 Functions of Jumpers and Connectors SATA1/SATA0 connector (J8, J9) A . Connector size : 7 Pin , 1.27mm ,180°, SATA Connector B . Connector location C. Connector pin definition Definition Definition SATA_RXN SATA_TXP SATA_RXP SATA_TXN 96M5771o User's Manual / Page 15...
  • Page 16 SIO Connector (CN6) A . Connector size: 2 X 20 = 40 Pin ,2.0 mm, 180° ,BOX Header B . Connector location C . Connector pin definition Definition Definition DCD1 DCD3 DSR1 DSR3 RXD1 RXD3 96M5771o User's Manual / Page 16...
  • Page 17 SYSTEM FAN1/FAN2 Connector(J1 , J5) A . Connector size : 1 X 3 = 3 Pin , 2.54mm ,180°, FAN Connector B . Connector location C . Connector pin definition Definition Definition Sense +12V 96M5771o User's Manual / Page 17...
  • Page 18 A . Connector size : 1 X 6 = 6 Pin , 15.2x16.8x17mm, 90°, FEMALE B . Connector location C . Connector pin definition Definition Definition +5VSB +5VSB Data 2- Data 3- Data 2+ Data 3+ 96M5771o User's Manual / Page 18...
  • Page 19 Interrupt Data 11 Data 3 DiskAddress 1 Data 12 DMA66 Detect Data 2 DiskAddress 0 Data 13 DiskAddress 2 Data 1 HDCCS1# Data 14 HDCCS3# Data 0 HDD Active # Data 15 DMA REQ 96M5771o User's Manual / Page 19...
  • Page 20 Data 7 Data 15 HDCCS1# HDCCS3# IOR# IOW# Interrupt CF_CSEL# Reset# IOCHRDY Disk Address 2 DMA REQ Disk Address 1 DMA ACK# Disk Address 0 HDD Active# Data 0 DMA66 Dectec Data 1 Data 8 96M5771o User's Manual / Page 20...
  • Page 21 82573L LAN1 / LAN2 LINK 100LED(JP15 /JP21) A . Connector size : 1X2 = 2 PIN , 2.54mm , 180° , PIN Header B . Connector location C . Connector pin definition Definition Definition +3VSB Speed100# 96M5771o User's Manual / Page 21...
  • Page 22 System Thermal Connector( J3 , J7 ) A . Connector size : 1X2 = 2 PIN , 2.54mm , 180°, PIN Header B . Connector location C .Connector pin definition Definition Definition Thermal Pin Thermal GND 96M5771o User's Manual / Page 22...
  • Page 23 MDI1N LINK1000# VGA Connector(VGA1) A . Connector size : VGA D-SUB 15 Pin Connector B . Connector location C .Connector pin definition Pin Definition Pin Definition Green Blue DDC Data HSYNC VSYNC DDC Clock 96M5771o User's Manual / Page 23...
  • Page 24 A . Connector size : 1 X 3 = 3 PIN , 2.54mm , 180° , PIN Header B . Connector location C . Connector pin definition *2-3 Def. +3.3V * = DEFAULT SET 96M5771o User's Manual / Page 24...
  • Page 25 A . Connector size : 1X2 = 2 PIN , 2.54mm , 180° , PIN Header B . Connector location C . Connector pin definition Pin Definition Pin Definition PULL UP TO +5V 2 96M5771o User's Manual / Page 25...
  • Page 26 Pin Definition Pin Definition PSON# POWER Connector (CON1) A . Connector size : 2X5 = 10PIN , 4.2mm , FEMALE B . Connector location C . Connector pin definition Definition Definition PSON# +5VSB +12V -12V 96M5771o User's Manual / Page 26...
  • Page 27 Pin No. Description Pin No. Description L_DDC_CLK L_DDC_DATA PANEL1_VDD LA_DATAP0 LA_DATAN0 PANEL1_VDD LA_DATAP1 LA_CLKP LA_DATAN1 LA_CLKN PANEL1_BACKLIGHT LA_DATAP2 PANEL1_BACKLIGHT LA_DATAN2 PCI SLOT (CN5) Side B Side A Side B Side A -12V TRST# +12V INTA# 96M5771o User's Manual / Page 27...
  • Page 28 58 AD1 60 RSV 62 +5V PCI Device interrupt and BUS Assignments Chipset Configuration PCI INT# REQ# /GNT# Special feature description BUS/DEVIC/FUNCTION PCI Slot1 1 / 17 / 0 A,B,C,D 1 / 18 / D,A,B,C 96M5771o User's Manual / Page 28...

  • Page 29: Chapter 3 Expansion

    Chapter 3 Expansion 96M5771o User's Manual / Page 29...

  • Page 30: System Memory

    3.1 System Memory 96M5771o incorporates Intel 945GM chipset supports up to 4GB un-buffered non-ECC DDR2 533/667 SDRAM 3.2 Installing DIMM To install DIMM 1. Make sure the two handles of the DIMM sockets are in the “open” position, i.e. the handles stay outward.
  • Page 31 Figure 3-3: How to install DIMM (3) 4. To take away the memory module, just push the both handles outward, the memory module will be ejected by the mechanism in the socket. Figure 3-4: How to install DIMM (4) 96M5771o User's Manual / Page 31...

  • Page 32: Installing Compact Flash

    3.3 Installing Compact Flash 1. To install a Compact Flash memory card into 96M5771o, align the notches on the card with the Compact Flash socket in the 96M5771o. Then firmly insert the card into the socket until it is completely seated.
