Page 1: Tumble Dryer
Tumble Dryer OWNER'S MANUA Applicable Models DWRCB8011 Thank you for choosing out dryers. Please read this OWNER’S MANUAL carefully prior to using, and keep it for further reference. 건조기_DWRCB8011(영).indd 1 2014-05-13 오후 5:10:16... - Page 2 PREFACE Thank you for choosing our dryers. Please read this manual carefully. It provides instru- cion, use, and maintenance. Retain it for future reference. Record the model and serial numbers of your machine. Quote this information to your dealer if you require service. The following symbols are used in this manual: Important information concerning your personal safety and information on how to avoid damaging the appliance...
-
Page 3: Table Of Contents
Contents Safety information ............1 Product description ............5 Control panel ..............6 Use .................. 7 Drying hints ..............11 Drying programme ............13 Care and cleaning ............14 Something not working ............17 Technical data ..............18 Installation ...............19 Environment concerns .............21 Guarantee/Customer Service ...........22 Electric diagram ..............24 건조기_DWRCB8011(영).indd 3 2014-05-13 오후... -
Page 4: Safety Information
Safety Information Before Use Read and understand thoroughly this safety instructions before use. The items indicated here are very important safety precautions, which must be followed. Any failure and losses caused by ignoring the above mentioned items and cautions mentioned in the operation and installation instruction are not covered by our warranty and any liability. - Page 5 Safety Information Before Use Fire accidents / short circuit or electric leakage may occur Do not install the appliance close to fire sources or heat sources. ● Do not rest any burning candles or cigarettes on the appliance. ● Do not install the appliance in places with dampness or suffering from ●...
- Page 6 Safety Information Before Use Other instructions This appliance is designed for domestic use. It must not be used for purposes other than those for ● which it was designed. Only wash fabrics which are designed to be machine dried. Follow the instructions on each ●...
- Page 7 Safety Information Before Use The lint trap has to be cleaned frequently. ● Adequate ventilation has to be provided to avoid the back flow of gases into the room from ● appliances burning other fuels, including open fires. Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, ● kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer. Remove all objects from pockets such as lighters and matches. ● Oil-affected items can ignite spontaneously, especially when exposed to heat sources such ● as in a tumble dryer. The items become warm, causing an oxidation reaction in the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot enough to catch fire. Piling, tacking or storing oil affected items can prevent heat from escaping and so create a fire hazard.
-
Page 8: Product Description
Product description Before Use 1. Control Panel 2. Drainage container 3. Fluff filter 4. Door 5. Condenser cover 6. Condenser 7. Adjustment leg 건조기_DWRCB8011(영).indd 8 2014-05-13 오후 5:10:21... -
Page 9: Control Panel
Control panel Use Process Control panel 1. Power 2. Start / Hold 3. Child Lock 4. Buzzer 5. Individual lights -Drying - Cooling - End 6. Individual lights - Fliter - Overflow - Child Lock 7. Program Selector Dial 건조기_DWRCB8011(영).indd 9 2014-05-13 오후 5:10:21... -
Page 10: Use
Use Process First Use Ensure that the electrical connections comply with the installation instructions. ● Remove the polystryrene block and any material from the drum. ● Before using your tumble dryer for the first time, we recommend that you place a few damp cloths ● inside the appliance and dry for 30 minutes. There may be dust inside a brand new tumble dryer. Daily Use Connect the appliance Open the door (see picture), by pressing as shown. -
Page 11: Time Controlled Drying
Use Process Automatic controlled drying You can choose different programme base on your different clothes materials. The ● device has the function with sensor the moisture in order to automatically adjust the drying time for optimal drying. This drying system is fit for cottons, synthetics sections and Anti-Bacterial, silk programme. Time controlled drying Select the 90 or 60 minute programme for cottons or the 30 minute programme for synthetics. ●... -
Page 12: Indicator Lights
Use Process Select the Power Press the Power button to turn on the machine. ● Indicator Lights “Drying Light” ● This light indicates the appliance is in the drying phase. “Cooling Light” ● This light indicates that the appliance is in the cooling phase. At the end of drying, there is a 10 minutes cooling phase to cool the laundry. -
Page 13: At The End Of The Programme
Use Process At the end of the programme All drying programs end with 10 minutes cooling phase. If the laundry is not removed at the end of the cycle, the dryer performs an anti-creasing phase (duration:30 minutes maximum). If you do not remove the laundry ,the machine will remain in the standby status, after the anti-creasing phase. The display shows “ End” and the buzzer sounds for 15 seconds if you have selected the buzzer. -
Page 14: Drying Hints
Drying Hints Use Process Drying Hints Before loading the laundry Never tumble dry the following: Particularly delicate items such as net curtains, woollen, silk, fabrics with metal trim, nylon tights, bulky materials such as anoraks, blankets, eiderdowns, sleeping bags, feather quilts and any items containing rubber foam or materials similar to rubber foam. Always follow the instructions on garment tables: ●... -
Page 15: Laundry Weights
Drying Hints Use Process Make sure that no metal objects are left in the laundry (e.g. hair clips, safety pins, pins) Button up pillowcases, close zip fasteners, hooks and poppers. Tie any belts or long tapes. To avoid laundry becoming tangled: Close zips, button up duvet covers and tie loose ties or ribbons (e.g.of aprons). Turn items with double-layered fabrics inside out (e.g.with cottonlined anoraks, the cotton layer should be outermost). -
Page 16: Drying Programme
Drying programmes Use Process Drying programmes Section Course Max load Description of programme Jeans, work clothes, Heavy Thick or multi-layered textiles and so on. Strong Jeans, work clothes and so on. Standard Cottons Drying shirt, T-shirt, cotton trousers. cotton Damp Drying knitted items, cotton shirt. Drying sheet, bed linen, table Iron linen, starched laundary. -
Page 17: Care And Cleaning
Care and cleaning Use Process Care and cleaning Yon must DISCONNECT the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. External cleaning Use only soap and water and then dry thoroughly. Important : do not use methylated spirit, diluents or similar products. -
Page 18: Cleaning The Condenser
Care and cleaning Use Process Water receiver emptied Water receiver collects all of the water from condenser. Water receiver need to be emptied after each use. Otherwise drying performance will be affected. If water receiver is full, 'overflow light' will be illuminated and buzzer sounds. Under this situation, water receiver must be emptied within one hour. 1. Pull out water receiver 2. Empty wasie water 3. Push the water receiver in dryer 4. -
Page 19: Humidity Sensor
Care and cleaning Use Process Humidity sensor In the movement process, this device is used for induction clothing humidity, it means that it must be cleaned periodically. Calcium oxide build up on the sensor surface should be cleaned off. Lamp replace (options) on some models 1. Open the door, put your hand into the drum of the dryer, use screw driver unscrew two pieces of screw, and take out the lamp cover. -
Page 20: Something Not Working
Something not working Use Process Something not working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily ● without calling out an engineer. Before contacting your local Service Centre, please carry out the check listed below. -
Page 21: Technical Data
If you call out and engineer to a fault listed below, or to repair a fault caused by incorrect use of installation, a charge will be made even if the appliance is under guarantee. Technical data Dryer Model DWRCB8011 Dryer Capacity (kg) (AC V/Hz) 220-230/50... -
Page 22: Installation
Installation Appendix Earth note : This appliance must be earthed. In case of failure or damage, earth can provide a minimum resistance to reduce the possibility of electric shock. The power cord has grounding wire with device and power cord with plug. Plug must be inserted into a properly installed and grounded socket (In accordance with all local rules and standards). -
Page 23: Door Reversal
Installation Appendix Check across the corner When you press the edge, the machine should not shake up and down. (please check two direction) when press on the top frame (across the corner), the dryer shakes, need to re-adjust the adjustable feet. Do not spread a carpet under the dryer or pile up the laundry near the products. This might cause heat build-up. -
Page 24: Environment Concerns
Environment concerns Appendix A cut off plug inserted into a socket is a serious safety (shock) hazard. ● Permanent connection ● In the case of permanent connection it is necessary that you install a double pole Warning switch. The switch must not break the yellow and green earth cable at any point. ● Packaging materials The materials marked with the symbol are recyclable. -
Page 25: Guarantee/Customer Service
Gurantee/Customer Service Appendix Daewoo Electronics Guarantee Conditions Daewoo Electronics products are guaranteed for 12 or 24 months from the date of original purchase as follows:- American style side by side fridge freezer 24 months* Combination frost free fridge freezer 24 months* Undercounter and tabletop fridges and freezers 12 months* Washing machines 24 months* Washer dryers 24 months* Microwave ovens... - Page 26 Gurantee/Customer Service Appendix Marking explanation Volt Alternating current Watt Hertz Tested safety CE marking risk of fire 건조기_DWRCB8011(영).indd 26 2014-05-13 오후 5:10:26...
-
Page 27: Electric Diagram
Electric diagram Appendix Heater Temperature sensor Earth Pump Guide sensor Temperature sensor optional Condenser lamp Float switch Capacitance switch Door switch Operation panel 건조기_DWRCB8011(영).indd 27 2014-05-13 오후 5:10:26... - Page 28 Store & place of purchase e.g. Dixons Manchester Daewoo Electronics Sales UK and Home Appliance Guard Limited (including their respective group and companies) may wish to contact you about product services and offers that might be of interest to you. By submitting your details you are consenting to receiving marketing communications by post, phone, email and SMS.
- Page 29 FREEPOST RSHU-HKUG-ZBRU HOME APPLIANCE GUARD 4TH FLOOR KINGSLAND HOUSE 21 HINTON ROAD BOURNEMOUTH - DORSET BH1 2DE 건조기_DWRCB8011(영).indd 29 2014-05-13 오후 5:10:26...
- Page 30 www.daewooelectronics.co.uk 건조기_DWRCB8011(영).indd 30 2014-05-13 오후 5:10:26...
