Connection
1. Connect the AC power jack
Ensure the amplifier has been turned off while
connecting and disconnecting the power. First connect
the power cable to the AC power jack on the rear panel,
and then plug the power cable into an AC power outlet.
2. Connect the Drum IN Jack
Connect the digital drum source and the amplifier's
Drum IN Jack with an audio cable when the amplifier is
powered off.
3. Connect the AUX IN Jack
You could play drums along with your favorite songs
simply connect your external audio device
3/
)
MP
CD player
to the AUX IN Jack
:
Warning
Be sure to turn down the volume of the amplifier before
.
connecting audio cables
connectors can cause noises which may damage the
.
speakers
Specifications
Rated Power Output
32 W
Speakers
Coaxial, 2-way
(10" Woofer + 3" Tweeter)
Enclosure
Bass-reflex type
Controls
Volume Knob
BASS Knob
MIDDLE Knob
TREBLE Knob
POWER Switch
Troubleshooting
Problem
Possible Cause and Solution
No Sounds
1. Please check whether the Volume knob is set to minimum.
2. If the indicator could not light up, please check whether the fuse is damaged.
Distortion
1. The input sensitivity of the amplifier has been set somewhat high for compatible
Noises
1. This amplifier is equipped with a grounding type supply cord to reduce the
2. Please use shield audio cables or try another cable.
aw_AP30C(ERP)_Manual_G03_130916
2013
9
16
10:44:00
;
(
such as
.
Inserting jack into the
Indicator
POWER
Connectors
DRUMS Input Jack
AUX IN Jack
Power Supply
AC voltage shown on nameplate
Dimensions
340 (W) x 340 (D) x 345 (H) mm
devices with relatively low output levels. But if you connect a device with high
output level, distortion may occur if you turn the volume level much too high. If
distortion happens, please try to turn down the volume level.
possibility of shock hazard. Be sure to connect it to a grounded AC receptacle.
(
)
Weight
12 kg
Accessories
Owner's Manual
Power Cord
* All specifications and appearances
are subject to change without prior
notice.
AP30C(ERP)_G03
