Page 1 Model TV1001 User’s Manual...
Page 3: Table Of Contents
CAMERA DIAGRAM ITEMS REQUIRED FOR STARTUP BATTERY INSTALLATION MEMORY CARD INSTALLATION QUICK SETUP ADVANCED SETTINGS & FUNCTIONS QUIKSHOT MOUNTING & FIELD SETUP CAMERA CARE TROUBLE SHOOTING WARRANTY INFORMATION PRODUCT REGISTRATION CARD WARNING! Prolonged exposure from looking directly into any infrared light could cause cataracts or permanent retinal damage. Do not look directly into the camera during test mode! Failure to follow this warning may cause serious injury or blindness! WARNING! Do not expose camera interior components, batteries, or...
Page 4: Camera Diagram
Green Red Walk Camera Test Light Set-Up Light Camera Options SD Card Column Slot SDHC Clock 11:50 Date Photos Case Door Case Photo Video Mode Burst (Open) 10s 30s 1m Door Vid Lg Res. Delay 10s 30s 1m 5m Latch Power On/Off Button...
Page 5: Items Required For Startup
ITEMS REQUIRED FOR STARTUP: 6 C-Cell Alkaline Batteries • (Sold separately) 1 SDHC Storage Card • (up to 32GB) (Sold separately) NOTE: Eyecon™ Trail Camera’s can accept SD cards up to 32GB, but testing shows that maximum performance is obtained at 16GB. 1 External SD memory card reader •...
Page 6: Battery Installation
BATTERY INSTALLATION: IF USING C-CELL BATTERIES 1. Turn battery door lock to open position to release door located on the bottom of the camera. 2. Insert (3) C-cell batteries, negative (–) side inserted first into one side. 3. Close the battery door and position lock to locked position. 4.
Page 7: Memory Card Installation
MEMORY CARD INSTALLATION: TO INSTALL THE SD CARD (Sold separately) 1. Open case door. 2. Insert the SD card face up into the SD Card Slot until you hear it click into place. Press it once to remove. MEMORY CARD SIZE = NUMBER OF PHOTOS PHOTO SIZE (Resolution) 16GB...
Page 8: Quick Setup
QUICK SETUP: Your QuikShot Trail Camera will come with the following standard options already preset so that quality photos may be taken right out of the box without changing any settings. MODE: BURST: Photo 3 photo burst RESOLUTION: DELAY: 1.3mp 10 sec If you wish to customize your own settings proceed to Advanced Settings &...
Page 9: Advanced Settings & Functions
ADVANCED SETTINGS & FUNCTIONS: Press and quickly release the power button to activate the camera and view the user setup screen. Setting the functions is easy; simply use the plus or minus arrows to select the feature (blinking) you wish to change and then push the SET button.
Page 10 To set the YEAR: Press the set button again and you will see “YY” start to flash. Pressing the set button again will allow you to select the correct year. Use the + or – arrows to change the year setting. Press the set button again and this will bring you back to the camera options column and you will notice the “Date”...
Page 11 VID LG: This setting selects the length you would like each video to be. Options are: 10 seconds, 30 seconds or 1 Minute. To set the VIDEO LENGTH: Use the + or – arrows to scroll down until the “Video LG” starts to flash. Press the set button until an arrow flashes at one of the Video settings.
Page 12: Quikshot Mounting & Field Setup
QUIKSHOT MOUNTING & FIELD SETUP The QuikShot comes with a 6 ft nylon mounting strap which allows for quick and easy mounting. The camera back is unique in that it has 12 vertical large bark biters and 5 different adjustment slots. This allows for several strap placement options or another strap can be added depending on your application.
Page 13 CAMERA LIGHTS: The red walk test light on your QuikShot is used to help determine that your camera is set at the proper height and is pointed in the right direction. The red walk test light can only be activated by a combination of heat and motion. After either 20 photos or videos the red walk test light becomes inactive and will not be seen until the user wakes the camera up again.
Page 14: Camera Care
CAMERA CARE Moisture, vibration, and extreme temperature can cause severe damage to your trail camera and should be avoided. Keeping your camera free from moisture and vibration and using in the correct temperatures will assure you many years of maintenance free service and operation. MOISTURE: Although all Eyecon™...
Page 15: Trouble Shooting
TROUBLE SHOOTING If your camera at anytime does not respond CAMERA NOT RESPONDING: when the buttons are pushed or you cannot turn it off, your camera maybe locked up. The best way to resolve this problem is to open one of the battery doors for a period of 10 seconds.
Page 16: Warranty Information
4. Include a copy of your original receipt, your RA#, and a check or credit card number for $20.00 shipping/handling in the box. 5. Ship the box prepaid to: Big Game Treestands, Camera Returns, 1820 N. Redding Ave. Windom, MN 56101. Make sure to put the RA# in bold letters on the outside of the box.
Page 17: Product Registration Card
To activate your product’s warranty, please mail in this completed registration card or submit it online at www.biggametreestands.com PRODUCT REGISTRATION Product Purchased Model Number Serial Number Owner’s Name Street Address City State Zip Code Email Address Phone Owners Age (optional) Sex (optional) Date Purchased Purchased From (Dealer Name)
Page 18 Remember to activate your product’s warranty? See warranty information and registrtion instructions on page 16 and then complete and mail in the registration card on page 17 or submit it online at: www.biggametreestands.com PLEASE REGISTER TO ACTIVATE YOUR PRODUCT'S WARRANTY.
Page 19 OWNER’S RECORD Product Name __________________________________________________ Model Number _________________________________________________ Serial Number__________________________________________________ Purchased From ________________________________________________ Purchased Date _________________________________________________ YOU MUST RETURN THE COMPLETED REGISTRATION CARD ON PAGE 17 WITHIN (30) DAYS OF THE PURCHASE IN ORDER TO ACTIVATE THE LIMITED WARRANTY COVERAGE. (Make sure to include date purchased when registaring!) NOTES: Big Game...
Page 20 www.BigGameTreestands.com PO Box 382 • 1820 North Redding Ave • Windom, MN 56101 800-268-5077 • 507-831-4350 BGTTV10010112A...
