Summary of Contents for ICOP Technology ICOP-0070
- Page 1 ICOP-0070/0071/0072 Power Supply AC/DC PC/104 Module Power Supply DC/DC PC/104 Module Power Supply DC/DC + DIO PC/104 Module User’s Manual (Version 3.1) www.MicrocomputerSystems.com...
- Page 2 Copyright Notice This document is copyrighted, 2000 by ICOP Technology Inc. All rights are reserved. The information in the manual is subject to change without notice in order to improving products. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the manufacturer.
-
Page 3: Table Of Contents
T a b l e o f C o n t e n t s Chapter 0 Packing List Chapter 1 Specifications Chapter 2 Jumper Settings Chapter 3 Connectors Chapter 4 Digital I/O Warranty... -
Page 5: Packing List
C h a p t e r 0 Packing List Function Function Package l ICOP-0070 Power Supply Module l 3 Pin extend cable x 1 ICOP-0070 Power Supply AC/DC Module l ICOP-0071 Power Supply Module ICOP-0071 Power Supply DC/DC Module... -
Page 6: Chapter 1 Specifications
C h a p t e r 1 Specifications Features ICOP-0070 Power Input voltage range : 90 ~ 264 VAC Output voltage : +5 VDC @ 2A, -5 VDC @ 0.2 A, +12 VDC @ 1 A, -12 VDC @ 0.3 A... - Page 7 Features ICOP-0071 Power Input Voltage: +8V ~ +48V DC Output Voltage: 5V DC / 3A Over load protection Over heat protection Converted frequency: 52 KHz Converted effect: Over 80% Suitable for auto / truck system Bus Interface PC/104 standard compliant Dimensions 90 (L) x 96 (W) mm.
-
Page 8: Chapter 4 Digital I/O
Features ICOP-0072 Digital I/O 24 bit digital I/O lines (1 group) Group emulates a 8225 PPI mode 0 Buffered circuits for higher driving capacity than 8255 Output status read back Pin -compatible with OPTO-22 I/O module racks Transfer rate: 300 KB/sec. (typical) Digital output:Logic level 0: 0.5 V max. - Page 9 Component Location ICOP-0070 C N 1 Input DC Output -5 v / -12v / +12v / GND / GND / +5v ICOP-0071 CONT4 DC Input +8v~+48v CONT5 DC Output +5v @ 3A ICOP PC/104 Power Supply User's Manual...
- Page 10 Component Location ICOP-0072 CONT4 DC Input +8v~+48 Cont CONT5 DC Output +5v @ 3A ICOP PC/104 Power Supply User's Manual...
-
Page 11: Jumper Settings
C h a p t e r 2 Jumper Setting The ICOP-0072 occupies 8 consecutive I/O locations. Dip -switch SW1 sets the base address for the ICOP-0072. Be careful when selecting the base address as some settings can conflict with existing PC ports. The following table shows common examples that usually will not cause a conflict. -
Page 12: Chapter 3 Connectors
C h a p t e r 3 Connectors Connector ICOP - 0070 ICOP - 0071 ICOP - 0072 CONT1 AC Input CONT2 CONT3 Digital I/O Group 1 CONT4 DC Output 8-48VDC Input 8-48VDC Input CONT5 5VDC Output 5VDC Output ICOP PC/104 Power Supply User's Manual... - Page 13 C h a p t e r 4 Digital I/O (ICOP-0072) Mode 0 Operation Mode 0 operation provides simple input and output operation for each of the three ports. No handshaking is required, data is simply written to or read from a specific port.
- Page 14 Base+1 Port B0 (read/write) Value PB07 PB06 PB05 PB04 PB03 PB02 PB01 PB00 Base+2 Port C0 (read/write) Value PC07 PC06 PC05 PC04 PC03 PC02 PC01 PC00 Base+3 Port A0,B0,C0 (write) Value PA0 = 0 => Port A0 is output PA0 = 1 => Port A0 is input PB0 = 0 =>...
-
Page 15: Warranty
Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. S hould this product fail to be in good working orderat any time during this period, we will, at our option, replace or repair it at noadditional charge except as set forth in the following terms.
