Brightex FL-11 Instructions For Use

www.Brightexlabs.com
For questions or support please contact:
support@brightexlabs.com
INSTRUCTIONs for use:
BRIGHTEX FL-11:
BATTERIES
Unscrew the end cap then place the batteries correctly
oriented inside:
Place the AAA batteries inside the AAA adaptor and
then place the adaptor inside with the arrow pointing
inwards.
Place inside the plastic tube, then insert the 18650
Lithium battery (not provided)
Use 26650 Lithium battery (not provided), for maximum
operation time. Unscrew the inner aluminum adaptor
from the top part of the battery compartment, using
round nose pliers (not provided), then place the
battery inside.
Close the end cap tightly after batteries have been inserted.
Use either 3 x AAA Alkaline batteries (do not mix old with
new) or One 18650/26650 rechargeable High Quality
Lithium battery and battery charger (not provided).
To benefit from the 600 Lumens, use a Fully Charged
Lithium battery.
Remove batteries during storage and transport, to extend
the battery life and to prevent leakage of batteries into
the battery compartment.
Dispose of the used batteries properly.
modes
Use the uniquely designed 5-mode switch for, switching
between different modes.
Power off: Fully press the switch, to turn off the flashlight.
High light: Once the flashlight is switched off for over 10
seconds, when you next switch it on, it will always switch on
to High Light mode
Operating the different modes:
To switch between the 5 modes High, Mid, Low,
Strobe, SOS. Simply press the switch half way and the
flashlight will switch to the next mode.
Switching On the flashlight, shortly after it has been
switched off (less then 3sec), will switch to the next
mode.
zoom
Utilizing the x2000 incredible powerful zoom.
Zoom In: Push the lens outwards as shown on the flashlight to
Zoom In. Due to the powerful zoom, when you fully zoom in you
will even see the actual lines of the LED.
Zoom Out: Push the lens inwards as shown on the flashlight to
Zoom Out.
5 MODES
600 LUMENS LED FLASHLIGHT
1 2
1. End Cap 2. AAA Adaptor
4 5
5. 18650 battery
4. 18650 battery
inside flashlight
inside Plastic Tube
8
7
7. Taking Out the 8. Flashlight without
Aluminum Adaptor Aluminum Adaptor
MODE LUMENS* OPERATION TIME **
High 600
Mid 330
Low 95
Strobe 600
SOS 600
*Tested values when using Quality Lithium batteries 18650/26650
** When using Quality Lithium battery 26650
LENGTH
WEIGHT
4.1oz
4.5"
(115 mm)
(115g)
PUSH LENS OUTWARDS TO ZOOM IN
NARROW BEAM
PULL LENS INWARDS TO ZOOM OUT
WIDE BEAM
3
3. AAA Adaptor
Inside Flashlight
6
6. Aluminum
Adaptor
DISTANCE*
2.5 hours 200
5 hours 100
15 hours 40
5 hours
5 hours
