Page 1: User Manual
USER MANUAL 825c UNDERWATER VIEWING SYSTEM MA-030-MK Rev A, Date: 8/18/08... -
Page 2: Table Of Contents
Nature Vision, Inc. www.marcumtech.com Table of Contents Introduction...3 Features ...3 Getting Started ...5 Adjusting the Monitor Settings...6 Lighting ...7 Ice Fishing Application ...8 Open Water Application ...8 Battery Charging...8 Product Performance Specifications ...10 One Year Warranty...10 How to Obtain Service...11 MarCum User Manuals are available for download from www.marcumtech.com. -
Page 3: Introduction
Technologies Inc., the most technologically advanced color underwater viewing system available. Welcome to the world of underwater viewing, in full living color. MarCum Technologies has incorporated the latest technology in producing the most compact, technologically advanced and versatile color underwater viewing system available. Your new VS825c can be used to hunt for underwater treasures, locate the “spot on the spot”, observe... - Page 4 Nature Vision, Inc. www.marcumtech.com The 600v x 800h super high resolution LCD monitor on the VS825c viewing system provides for an extraordinarily sharp and clear picture under most viewing conditions. The daylight viewable monitor requires no sunshield while viewing outdoors. This makes it more versatile for summer use or while viewing outside on the open ice.
-
Page 5: Getting Started
Remove the VS825c from the packaging and place on a level surface with the MarCum Technologies logo facing towards you and right side up. Open the top cover of the soft pack by lifting up on the Velcro closers on each side and front of the soft pack. -
Page 6: Adjusting The Monitor Settings
Nature Vision, Inc. www.marcumtech.com base of the monitor) by turning each one counter-clockwise. Make sure to loosen the knobs a considerable distance. Than depress both knobs by pushing inwards and hold in place. This releases the lock on the monitor angle. While depressing the knobs with the base of your palms, use the index fingers of each hand and gently lift the monitor up to the desired viewing position and release tension on the gimbal knobs. -
Page 7: Lighting
Nature Vision, Inc. www.marcumtech.com the numbers of the selected adjustment increase or decrease depending on the arrow direction you are depressing. To accept the changes, release the UP / DOWN arrow and settings will be saved. Once the settings are adjusted properly, the on-screen menu will shut off automatically. -
Page 8: Ice Fishing Application
Nature Vision, Inc. www.marcumtech.com amount of LED light required will depend on the clarity and amount of particulates in the water. Darker, stained water will require more light while clear water will have sufficient light penetration therefore decreasing the need for LED intensity. Ice Fishing Application The VS825c can be used to entertain the kids or as the perfect tool to enhance your ice fishing experience. - Page 9 Nature Vision, Inc. www.marcumtech.com the charger will be red when the charger is in a charging mode. The LED indicator light on the charger will turn green when the charger switches to a trickle charge. The 7.2 amp hour, 12-volt battery that was supplied with the VS825c system should take about 8 to 10 hours to charge from a completely discharged state.
-
Page 10: Product Performance Specifications
Nature Vision, Inc. www.marcumtech.com Product Performance Specifications Battery ... 12 volt DC, 7.2 Amp hr Charger... 12 volt DC, 1 Amp Camera Image Sensor ... 1/3” Sony SUPER HAD CCD (color) Resolution... 400 horizontal lines Light Sensitivity... 0 lux with lights on Field of View ... -
Page 11: How To Obtain Service
Nature Vision, Inc. How to Obtain Service We want our products to provide you with a pleasant on-the-water experience. That means maximum customer satisfaction. If you have a problem with your unit please contact Nature Vision's toll free number at (866) 777-0733 for a Return Authorization Number (RA#) or e-mail us at service@naturevisioninc.com.
