- Page 1 MM-01 / MM-02 Mobility Scooter Owner’s Manual...
-
Page 2: Table Of Contents
5. OPERATION ..................14 TILLER ADJUSTMENT .................14 POWER SWITCH ..................15 POWER INDICATOR ................15 SPEED DIAL ..................16 SPEED INDICATOR ................16 HEADLIGHT/TAILLIGHT BUTTON ............16 FORWARD, REVERSE AND BRAKING ..........17 BLINKER SWITCHES ................17 HAZARD BUTTON ................17 MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... - Page 3 CLEANING THE BATTERY ..............30 DISPOSAL OF BATTERY ..............31 8. INSPECTION & MAINTENANCE ............32 DAILY INSPECTION ................32 REGULAR MAINTENANCE RECORD ..........33 BATTERY, FUSES, CIRCUIT BREAKER AND TIRES ......35 MAINTENANCE ..................36 LUBRICATION ..................37 MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual...
-
Page 4: Preface
1. PREFACE The MM-01/02 scooter provides stability under normal driving conditions, which is dry, level surfaces composed of concrete, blacktop, asphalt, packed soil, grass, and gravel. Please read this owner’s manual before using the scooter. Improper use of the scooter could result in harm, injury or traffic accidents. -
Page 5: Regular Use Of Your Scooter
Please read all the labeling on the scooter before driving it. For your future Please drive slowly on roads with drops or dips. reference, do not remove them. Do not make sudden turns while driving on gravel roads or ramps. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 6: Stairways And Escalators Warning
Extra caution when using your or traverse slopes greater than 10° scooter in extremely hot or cold conditions or when exposing your scooter to direct sunlight for prolonged periods of time. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 7: Emi
It is very important that you read this information regarding the possible effects antenna (source). The EM fields from hand-held radio wave sources (transceivers) of electromagnetic interference on your electric MM-01/02 Scooter are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the powered scooter’s control system while using these... -
Page 8: Standard Parts
26. Canopy Fixation Point 27. Control Panel MM-02 Figure 3 It is the same scooter but with no Back Seat & Armrest and a shorter Back Bar. Figure 1.2 Figure 3.1 MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 9: Optional Parts
2. After charging or replacing a new battery, drive the scooter for 2-3 minutes to Figure 4.1 make sure the battery capacity is enough. Figure 4.2 MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 10: Speed Dial
The warning horn will be activated when you push the button, release the button conditions or smog. We recommend to drive always with the lights turned and the horn will stop. on to be more visible for the traffic. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 11: Usb Socket
(Fig. 6.3). Make sure that the triangle is locked in place (Fig 6.4). Figure 7 Figure 7.1 Figure 7.2 Figure 6.1 Figure 6.2 Warning! Never drive with an open drawer. Figure 6.3 Figure 6.4 MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 12: Freewheel Mode
8. Make sure that your head light, taillight, blinkers and horn is working. electromagnetic brake will not function in freewheel mode. 9. Make sure it is safe before driving on the street. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 13: Stopping
During transportation the seat of the scooter may not be used to sit or Hold the hand brake lever tightly to operate the front drum brake, and the keep objects. scooter will stop immediately. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 14: Adjusting The Scooter
4. Pull the Triangle Door backwards to remove it (Fig. 12.2). To place the Triangle Door again, perform the same steps in reverse. Figure 10.3 Figure 10.4 Figure 12.1 Figure 12.2 MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 15: Seat, Backrest & Armrest
Be sure the seat is well locked before driving the Scooter. Figure 16 Figure 16.1 PU seat, armrest, and backrest comply with EN1021-1/2 of resistance to ignition. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 16: Battery & Charger
Figure 18 Do not connect or disconnect the plug or cord when they are wet, this may lead to an electric shock. 3. Plug the power cable into your power outlet. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 17: Charger
If necessary, ask for help from your MM-01 / 02 dealer for cleaning and 4. Do not cover the scooter with any waterproof cloth or other objects while r e p l a c i n g o f th e ba t te r y . -
Page 18: Inspection & Maintenance
Is the seat on properly? Rearview Mirror Is it tight? Are there any cracks or other damage to the tires? Tires Check the tread on the tires. Other Is there any abnormal noise? MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 19: Battery, Fuses, Circuit Breaker And Tires
20.1), if the power switch does not come ON and the battery indicator does not light up, please try to push this button, it is possible an electric current overload of the scooter. S h o c k Absorber Figure 20 Figure 20.1 MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 20: Maintenance
. F o r fu r t he r The warranty is expiring immediately when maintenance is done by details, inquire with your dealer. not authorized personnel by minniemobil GmbH. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 21: Troubleshooting
Tire pressure low Check seat for loose Scooter feels hardware or damage. wobbly when Seat is loose Ensure seat in locked driven position Bearing in tiller worn Replace bearings MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... - Page 22 Lead Acid battery DC12V/75AH x2”, 22kg per battery Climbing angle (dynamic) 1 -10 Parking angle (static) 28 miles/ 45km for 150kg loading MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual...
-
Page 23: Warranty
6. B r a k e p a d s ( w ea r i te m s ar e no t w a r r a nt e d) 7. F u s e s Repairs and/or modifications made to any part of the scooter without 9. Circumstances beyond the control of Minniemobile GmbH. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 24: Service Checks And Warranty Service
This warranty is invalid if the original scooter serial number tag is removed or altered. Serial number is stamped on the frame of the scooter and also on the scooter. MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 25: Stickers
Max user weight: 150kg 330lbs www.minniemobil.com Manufacturing Date: 2015-06 Germany SN:MM-01-1506001 ELECTRICS CIRCUIT DIAGRAM SC4101 FUSE10A WHITE TO CONTROL PANEL B+ FUSE10A FUSE125A BATTERY BLACK BATTERY CIRCUIT FUSE125A BREAKER TO CONTROL PANEL B- MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual... -
Page 26: Warranty Registration
□ Scooter Warranty □ My dealer has instructed me on how to operate my Scooter. Signature _________________________ Telephone ________________________ Dealer Name ___________________ Dealer Phone ________________________ E-mail Address _____________________________________________________ Comments _________________________________________________________ ___________________________________________________________________ MM-01 / 02 Owner's Manual MM-01 / 02 Owner's Manual...
