Datatronics 3314LC User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
UNPACKING AND INSTALLATION
This chapter describes the procedures for unpacking and installing
your modem. Chapter 1 is designed to have normal PC users on-line
quickly.
1.1
Unpacking the Modem
The complete Discovery LCD Fax/Audio modem package includes:
1. Discovery LCD Faxmodem unit
2. User's manual
3. Power supply unit
4. Data and fax communication software
5. RJ-11 to RJ-11 cable
6. RJ-45 to Y terminal cable
7. 6 by 2 terminal block
Carefully inspect the contents of the package for shipping damage. If
there is damage, immediately repack the modem in the original
packing material and contact your dealer.
1.2
Modem Front Panel and LED Indicators
Located on the modem front panel are the LCD, LCD configuration
buttons, LCD Panel Lock switch, the Voice/Data switch, and the LED
indicators. The modem LCD, LCD configuration buttons, Panel Lock
switch and Voice/Data switch are described in Chapter 2. The LED
indicators display current modem operation and status, as explained
below:
MR Modem Ready
Lit when modem is turned on. Flashes when modem is in test
mode.
TR
Terminal Ready
Lit when the computer or terminal is ready.
Page: 1
Chapter 1
