Xezo Air Commando D45-S Operation Manual

Operating manual for Air Commando chronograph watch (models D45-S, BU, B, GS)
Thank you for choosing a timepiece from our Xezo for unite4:good collection.
The Xezo Air Commando Limited Edition 500 chronograph sports 2 crowns.
Crown (A) at 3 o'clock is used to adjust local time, day and date.
Crown (B) at 10 o'clock operates the inner rotating bezel.
Your watch is fitted with Swiss-made precision quartz movement.
To unlock the screw-down crown (A) turn it 4-5 times counter-clockwise.
Important note:
Remark:
You can synchronize the seconds hand with an official time signal (radio/ TV/Internet). When the crown (A)
is pulled out in Position "3" (two "clicks" out), the seconds hand is stopped. As soon as the time setting has
been synchronized, return the screw-down crown (A) to the locked position by pressing it against the case
and turning it clockwise. Screw-down crown (A) now should be screwed down tightly to Position "1".
Using the rotating uni-directional bezel
This feature enables you to track elapsed time.
1.
Turn the bezel counter-clockwise until the zero mark is at the minute hand.
Important note: This model has unidirectional rotating bezel; the bezel only turns counter-clockwise to assure
that if moved unintentionally, the time reading will err on the side of caution when measuring elapsed time.
2.
The position of the minute hand in relation to the zero mark on the bezel will indicate the total number of minutes
elapsed.
Using dual-directional inner rotating bezel as additional time zone or to track elapsed time for models: D45-S, BU, B
This feature enables you to set the additional time zone or to track elapsed time. Hold the watch face-up with the
numeral 6 pointing toward you. Then rotate the watch 180 degrees counterclockwise.
(Numeral 12 now points toward you.)
To set the additional time zone turn the Crown (B) clockwise or counterclockwise until the hour hand points to
the desired marker on the hour scale of the inner rotating bezel. To track elapsed time turn the inner bezel in
either direction until the triangle on it points to the hour hand.
Using dual-directional inner rotating bezel as additional time zone or to track elapsed time for Air Commando D45-GS model.
This feature enables you to set the additional time zone or to track elapsed time. Hold the watch face-up with the
numeral 6 pointing toward you and the calendar on your right.
Then rotate the watch 180 degrees counterclockwise. (Numeral 12 now points toward you.)
Hold the crown (B) with the thumb and index finger of your right hand. To unlock the inner bezel, turn the
crown (B) 4 or 5 times counterclockwise. To set the additional time zone turn the crown (B) clockwise or
counterclockwise until the hour hand points to the desired marker on the hour scale of the inner rotating bezel.
To track elapsed time turn the inner bezel in either direction until the triangle on it points to the hour hand.
Once you have set the inner bezel, return the screw-down crown (B) to the locked position by pressing it
against the case and turning it clockwise. The crown (B) should now be screwed down tightly.
Important Note:
In order to insure that your watch remains water-resistant, it is important that all push-buttons and
Crown (A) are always returned to the locked position by pressing each against the case while turning
it clockwise. For model D45-GS, Crown (B) also has to returned to the locked position.

Specifications:

Case and Bracelet - 316L Stainless Steel (leather band is optional)
Glass - Swiss-made flat Sapphire Crystal with anti-reflection
Movement - Swiss-made 13 jewels precision quartz chronograph. Long-life battery.
Approximately lasting 4.5 years after activation.
Case back - 316 L Stainless Steel
Description of the display and control buttons
Water-Resistance – 200M/660FT - 300M/990FT
Servicing your Xezo watch
Display elements
Although components in your watch have been manufactured from first-rate materials, certain parts are
Second hand
subject to natural wear and tear. It is vital that all parts
Minute hand
Description of the display and control buttons
are properly inspected and the battery replaced at Weekday
Hour hand
regular intervals to avoid any problems.
Second counter
Display elements
We therefore, recommend that you have your
Minute counter
Second hand
watch serviced about once every 4-5 years.
1 ⁄ second counter
Minute hand 10
(hour counter after 30 minutes)
Contact us for after-sales service.
Description of the display and control buttons
Weekday
Date
http://www.xezo.com Description of the display and control buttons
