Summary of Contents for RayTalk RB-120
-
Page 2: Table Of Contents
5.2 How to change the IP Address....................... 19 5.3 Managing Security ......................... 20 5.4 Advanced setting..........................21 5.5 Access Control (Authorized MAC Address) ................... 23 5.6 Change community string ......................24 6. Reset device ......................25 7 Technical specifications of RAYTALK RB-120............26 User’s Guide... -
Page 3: Introduction
1. Introduction Thank you for purchasing our RB-120 Wireless LAN Access Point. This manual will assist you with the installation procedure. The package you have received should contain the following items: - User manual - RB-120 Access Point - Power adapter... -
Page 4: Features
2. Features You can make use of WEB or SNMP utility software for connect RB-120 which you want to manage. Supported features: Restrict the authority of user to access WLAN and this unit. Support IEEE 802.11 WEP encryption. Optimizing the radio configuration via assign the independent spectrum. -
Page 5: Hardware Installation
3. Hardware Installation 1. Mount the Access Point firmly to the wall or proper location that is determined during the site survey. 2. Make sure the antennas are in a vertical position (if not, rotate over 90 degrees). 3. Insert the power connector. 4. -
Page 6: Web Management Settings
Address box and press Enter. The Main Page will appear. In order to configure the RB-120, you must input the user name and password into the User Name box and the Password box. The default user name and password is “admin”. -
Page 7: Assign Basic Settings
4.1 Assign Basic Settings This screen contains all of the AP basic setup functions. AP Name: The device name. SSID: The service set identifier (SSID) or network name. It is case sensitive and must not exceed 32 characters, which may be any keyboard character. You shall have selected the same SSID for all the AP’s that will be communicating with mobile wireless stations. - Page 8 Click Apply to save your settings. LAN IP Address: This is the AP’s IP Address and Subnet Mask as seen on the internal LAN. The default value is 192.168.5.100 for IP Address and 255.255.255.0 for Subnet Mask. AP Mode: Working mode, there are four mode you can chose: Access Point, Access Point Client, Wireless Bridge point to point, Wireless Bridge point to multipoint.
- Page 9 Click Restore to upload your setting into AP, as following screen: User’s Guide...
-
Page 10: Advanced Setting
4.2 Advanced Setting Advanced have two settings: Wireless and MAC filtering. Wireless setting contains the following setup functions: Beacon Interval: The Beacon Interval value indicates the frequency interval of the beacon. Enter a value between 20 and 1000. A beacon is a packet broadcast by the Router to synchronize the wireless network. - Page 11 Basic Rates: Select the Basic speed of transmission, there are “1-2”Mbps and “1 -2 -5.5 – 11”Mbps you can chose. Transmission Rates: The rate of data transmission should be set depending on the speed of your wireless network. You can select from a range of transmission speeds, or you can select AUTO to have the Router automatically use the fastest possible data rate and enable the Auto-Fallback feature.
- Page 12 MAC filtering setting: If you want to enable MAC filter, please click “Enabled” button. Then you need to choose Deny or Allow PC’s whit MAC listed. And fill the MAC Address in the box which you want to control. Click “Apply” to save your setting.
-
Page 13: Log
4.3 Log You can Enable or Disable Log function. You also can setup a computer to save the log file, click “View Log” to check the log message. User’s Guide... -
Page 14: Status
4.4 STATUS The status page shows the information all about System and network status. User’s Guide... -
Page 15: Help
4.5 Help In this page you will get some information about how to use RAYTALK RB-120. User’s Guide... -
Page 16: Password Setting And Restore Factory Defaults
4.6 Password setting and Restore Factory Defaults Go to the Home page, click “password” to enter the setting page as the following: Enter the new password and click “Apply” to save your setting. Also, it provdes restore factory defaults setting 0n this tab. To perform this action, you can select “Yes”... -
Page 17: How To Install And Launch The Snmp Manager
RB-120 configuration. The default IP of RAYTALK RB-120 is 192.168.5.100. To make sure your pc and RB-120 whether in a same subnet and the connection is well, you can do a test via “ping” command. For example, you can employ the following command “ping 192.168.5.100”... -
Page 18: Login
5.1 Login When you got the available AP and press the connect button, there is a pop out window will come out. You should import the community string and assign a role for administration. The default community string is “public” and the Authority need to be an “Administrator”. Please refer to the Figure 2. Notice: The capital letters and lowercase letters need to be differentiated. -
Page 19: How To Change The Ip Address
5.2 How to change the IP Address If you wish to change the default IP address of RB-120, please click the tab “ Setup” “ Bridge” “ IP configuration” as Figure3. With this table, please change the IP address what you expected. -
Page 20: Managing Security
5.3 Managing Security Maintaining security in a wireless LAN environment is somewhat different from a wired network, because the radio waves do not stop at your office walls. Eavesdropping or unauthorized access from outside and your building can be a serious threat. If you wish to enable the Privacy Options function, please click the “Setup”... -
Page 21: Advanced Setting
5.4 Advanced setting You can change the settings such as ESSID, channel, operational mode and so on via the advanced setting. To click the “Setup” ” Wireless LAN” “Operational Settings”. Regarding the detail setting and parameters, it will show on the following table. You can assign the proper parameters to this unit for good performance. - Page 22 Regulatory Domain: There is a specification of Regulatory Domain in this field. Auto Rate Fall Back: The data rate will be changed automatically once the link distance with change from AP to client. The adequate rate is going to fit via system while this setting is enabled. Rates: There are four kinds of rates can be selected.
-
Page 23: Access Control (Authorized Mac Address)
The IEEE 802.11 standard allows for Access Control rules based on the client station’s hardware address, and is fully implemented by the RB-120. The Mac address table can be specified with a text file format. Then using the “ Authorized Mac Address “... -
Page 24: Change Community String
5.6 Change community string The default community string is “public”. All of the setting can be changed only the import string is fit with system. There are two kinds of authorities can connect to this unit. One is Administrator the other is general user. -
Page 25: Reset Device
6. Reset device This unit can be reset to factory defaults by reset hole and the procedure can be done with the following steps. Step1: You can reset the Access Point’s settings to factory defaults by pushing a paperclip in the little hole next to the UTP port while the Access Point is on and do not release it right away. -
Page 26: Technical Specifications Of Raytalk Rb-120
7 Technical specifications of RAYTALK RB-120 7.1 Standards supported IEEE 802.11 standard for Wireless LAN All major networking standards (including TCP/IP, NetBEUI, IPX) 7.2 Environmental Operating temperature (ambient): 0 ~ 55°C Humidity: Max. 95% Non-condensing 7.3 Power Specifications Input: AC 100-240 50-60 Hz 1A Output: DC5V 0.5A...
