  • Page 1 ® Model PV6111W User Guide HD-Ready Rear Projection Television ® ® As an Partner, Marantz has determined that this product meets the guidelines for NERGY NERGY energy efficiency. is a U.S. registered mark. NERGY...

  • Page 2: Table Of Contents

    Contents GENERAL INFORMATION IMPORTANT INFORMATION ... 3 IMPORTANT SAFEGUARDS ... 4 Main Features ... 6 Supplied Accessories ... 7 Before Operating Your Rear Projection TV ... 7 Antenna Connections ... 9 Main Unit ... 13 Basic Remote Control Functions ... 14 EZ SETUP on First Power On ...

  • Page 3: Important Information

    All mentions of “Rear Projection TV” in this OPERATION MANUAL refer to the Marantz HD-Ready Rear Projection Television. IMPORTANT To aid reporting in case of loss or theft, please record the Rear Projection TV model and serial numbers in the space provided. The numbers are located at the rear of the Rear Projection TV.

  • Page 4: Important Safety Instructions

    (non-moving) patterns can cause permanent damage to projection television receivers. Such “PATTERN BURNS” constitute misuse and are NOT COVERED by your Marantz Factory Warranty. When using TWIN PICTURE/Multi-Picture function, the sub-picture should not be left permanently in one corner of the screen or a “PATTERN BURN”...
  • Page 5 16. Power Lines—An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

  • Page 6: Main Features

    Main Features • SDTV and HDTV compatible SDTV and HDTV broadcasts can be displayed by connecting a commercially available DTV decoder. • DUAL TUNER (TWIN PICTURE screen and SEARCH screen function) Two TV tuners are provided, making it possible to split the screen vertically in two and display moving images simultaneously on them.

  • Page 7: Supplied Accessories

    Supplied Accessories Infrared Remote Control Part Number : RRMCG1704CESA Before Operating Your Rear Projection TV Location • For normal operation, your Rear Projection TV should be set up in the room where cool, adequate ventilation is provided. Do not position the back of the Rear Projection TV in a place where free airflow is restricted.
  • Page 8 Before Operating Your Rear Projection TV (Continued) Viewing The main feature of the Rear Projection TV is its large viewing screen. To be able to enjoy this large screen at its best, test the Rear Projection TV by placing it in various different parts of the room, in which it will be set, to find the ideal spot for viewing.

  • Page 9: Antenna Connections

    Antenna Connections • To fully utilize the various features provided, such as the 2-Tuner POP System, UNIVERSAL PLUS, and some connectors for high-quality VCR/DVD playback, set up this unit properly by following the procedures below. Universal Remote Control • The UNIVERSAL REMOTE CONTROL can be compatible with various VCR/DVD player and CATV converter brands by setting the correct control code.
  • Page 10 Antenna Connections (Continued) A-2. Connection recommendation if your cable TV converter has AUX terminals. (If your cable TV converter has both RF OUTPUT and AUX terminals, it is recommended to connect them as shown in example A-1.) Back of Rear Projection TV Coaxial Cable (Supplied) IN 4...
  • Page 11 Antenna Connections (Continued) C. Connection with Antenna Cable and VCR Back of Rear Projection TV Coaxial Cable (Supplied) HD INPUT IN 3 (USE FOR HDTV SIGNAL ONLY) CENTER IN • Shown here is the preferred method of connecting a VCR to your Rear Projection TV if you are in an area with good signal reception.
  • Page 12 Antenna Connections (Continued) E. Connection with Antenna Cable 1. Cable without a CATV Converter 2. VHF/UHF Combination Antenna Cable TV lead-in VHF, UHF or VHF/UHF combination antenna 75 ohm coaxial cable (round) 300 ohm twin-lead (flat) 3. Separate VHF/UHF Antenna VHF ANTENNA UHF ANTENNA 300 ohm twin-lead...

  • Page 13: Main Unit

    Main Unit Front control section POWER Press Press again POWER POWER VIEW SENSOR AREA FOR REMOTE CONTROL To open the cover BEHIND THE COVER MENU button Press MENU button to access the MAIN MENU screen • If the Rear Projection TV is not used for a long period or during a blackout, turn OFF the POWER of the main unit to Note prevent the Rear Projection TV from malfunctioning.

  • Page 14: Basic Remote Control Functions

    Basic Remote Control Functions This remote control can be used to operate the Rear Projection TV, a VCR, a DTV STB Decoder, a DVD Video Player and a Cable TV converter. The buttons that can be used differ according to the device connected. Please refer to the next page for details. INFRARED TRANSMITTER WINDOW POWER Press...
  • Page 15 Basic Remote Control Functions (Continued) • Buttons which can be used with the Rear Projection TV, VCR, CATV, DVD player and DTV STB. Name of button POWER Power ON/OFF VOLUME-UP Vol - UP VOLUME-DOWN Vol - DOWN MUTE Muting Selects Channel 100/ENT.

  • Page 16: Ez Setup On First Power On

    EZ SETUP on First Power On When you turn on the Rear Projection TV for the first time, it automatically memorizes the broadcasting channels in your area. Please perform the following steps before you press the POWER button. (1) Insert the batteries into the remote control. (See page 8.) (2) Connect the antenna cable to the Rear Projection TV.

  • Page 17: Menu Functions

    Menu Functions When you master these basic operations, the rest is simple. POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER...
  • Page 18 Menu Functions (Continued) MENU SUMMARY 1. TIMER/CLOCK Using the TIMER/CLOCK mode, you can set the current time and the times for automatically switching on and off the power of the Rear Projection TV. See pages 19 ~ 23. 2. VIDEO You can adjust the settings of VIDEO ADJ.

  • Page 19: Timer/Clock

    TIMER/CLOCK Using the TIMER/CLOCK mode, you can set the current time and the times for automatically switching on and off the power of the Rear Projection TV. The TIMER/CLOCK mode features the following three types: • CLOCK SET mode ... Sets the current time. •...

  • Page 20: Auto Clock Setting

    TIMER/CLOCK (Continued) POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN Q-SOUND PICTURE VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER Note XDS is information provided by television programs which contains program rating data, program Start and End times, and Time of Day...

  • Page 21: Sleep Time

    TIMER/CLOCK (Continued) SLEEP TIME POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER • To turn off the SLEEP TIME, repeat the above steps and select “– – – REMAIN” during step 4. •...

  • Page 22: Tv-On Time

    TIMER/CLOCK (Continued) TV-ON TIME This function cannot be used if the current time has not been set. (See page 19.) POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE...
  • Page 23 TIMER/CLOCK (Continued) Press “ON” or “OFF”. • ON: Activates the TV-ON • OFF: Deactivates the TV-ON Press Note to select TIMER. TIMER. to exit. MENU Be aware that if the time is not set, the TV-ON TIME function cannot be used. Prior •...

  • Page 24: Closed Caption

    Closed Caption How to set Closed Caption • Your Rear Projection TV is equipped with an internal Closed Caption decoder. “Closed Caption” is a system which allows you to view conversations, narration, and sound effects in TV programs and home videos as subtitles on your Rear Projection TV screen.

  • Page 25: Video Adjust

    Video Adjust Description of Adjustment Items Selected item button PICTURE To decrease contrast TINT To make skin tones purplish COLOR To decrease color intensity BRIGHT To decrease brightness SHARP To decrease sharpness Allows hue adjustment of the entire screen (Low produces the reddest hue while High produces the bluest COLOR TEMP.

  • Page 26: Pro Adjust

    Video Adjust (Continued) PRO Adjust Description of Adjustment Items Selected item Adjustment VMS (Velocity This circuit modifies the frequency or speed of scanning. Modulation Scanning) Switching this on enhances the detail of video and color. EVC (Enhanced Video Circuit) BLACK Allows adjustment of the degree of dark portions of the picture to change the sense of depth.

  • Page 27: Video Nr

    Video Adjust (Continued) VIDEO NR This produces a sharper picture when video images input from the S-VIDEO or VIDEO input terminal appear gritty. This function is only available when using VIDEO IN 1, 2, 3 or 4/S-VIDEO IN 1, 2 or 3. You can choose a setting from “OFF”, “SOFT”...

  • Page 28: Audio Adjust

    Audio Adjust Description of Adjustment Items Selected item button BASS To decrease bass response. TREBLE To decrease treble response. BALANCE To emphasize the left speaker’s volume. RESET To return all adjustments to the factory preset levels. POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU...

  • Page 29: Other Audio Settings

    Audio Adjust (Continued) Other Audio Settings Q SOUND This function simulates surround sound. EQUISOUND This function keeps the volume level constant during program changes and commercial breaks. INTERNAL SPEAKER SWITCH (SPEAKER) This function turns the Rear Projection TV’s internal speakers “ON” or “OFF” when listening to sound from external speakers and using the AUDIO OUTPUT JACKS.

  • Page 30: Mts/Sap Select Mode

    Audio Adjust (Continued) MTS/SAP Select mode POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER An on-screen graphic appears when receiving STEREO broadcasts. You can enjoy Hi-Fi stereo sound or SAP broadcasts where available.

  • Page 31: Screen Adjust

    Screen Adjust You can adjust the vertical or horizontal screen size and screen position in this mode. (This mode can be used only when the picture is in LETTERBOX, PANORAMIC, or ANAMORPHIC (vertical only) view mode. (See page 57.) You can adjust the items by following the tables below. Screen adjustment items vary depending on Screen size mode.
  • Page 32 Screen Adjust (Continued) POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER Press to access MAIN MENU MENU screen. Press to move the cursor to “SCREEN”.

  • Page 33: Parent Control (V-Chip Operation)

    Parent Control (V-CHIP operation) • This function allows you to restrict TV programs and also allows you to control TV usage based on FCC data. This function is for preventing your children from watching programs of mature nature. • Restriction of TV programs is based on information about the program’s MPAA rating and the TV Parental Guidelines.
  • Page 34 Parent Control (V-CHIP operation) (Continued) TV PARENTAL GUIDELINES (example) Example 1.1 : Age-Based setting Go through all select ratings and select unblocked. This will automatically unblock everything. Example 1.2 : Age-Based setting For “TV-G” select “Block”. This will automatically block the higher age ratings “TV-PG”, “TV-14”, “TV-MA”...

  • Page 35: How To Set V-Chip

    How to Set V-CHIP Parent Control First Setting POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER • The V-CHIP and VIEW TIMER mode can be adjusted when the steps 1 ~ 5 are finished.

  • Page 36: Mpaa Rating

    How to Set V-CHIP (Continued) MPAA Rating POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER • If you set “PG” to BLOCK, “PG-13”, “R”, “NC-17” and “X” are automatically blocked. Note •...

  • Page 37: Tv Rating

    How to Set V-CHIP (Continued) TV Rating POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER • If you set “TV-Y7” to BLOCK, “TV-G”, “TV-PG”, “TV-14” and “TV-MA” are automatically blocked “D”, “L”, “S”, “V” and “FV”.

  • Page 38: Additional Mode

    How to Set V-CHIP (Continued) Additional mode There may be new or additional rating systems in the future. In that case, please set up as follows and the new rating system will be set up automatically. POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU...
  • Page 39 How to Set V-CHIP (Continued) Additional mode (Example) Before performing the precedure below, download V-CHIP data correctly. (See page 38.) POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE...

  • Page 40: Turn On V-Chip Block

    How to Set V-CHIP (Continued) Turn on V-CHIP Block POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER To operate V-CHIP BLOCK Repeat steps 1 to 4 of MPAA Rating on page 36.
  • Page 41 How to Set V-CHIP (Continued) To cancel the V-CHIP BLOCK screen while V-CHIP BLOCK is activated POWER VCR/ DVD/ CATV PERSONAL PREFERENCE Note ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE Note PLAY FF CH/SKIP...
  • Page 42 How to Set V-CHIP (Continued) POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER BEHIND THE COVER L-AUDIO-R MENU MENU ENTER...

  • Page 43: Parent Control (View Timer)

    Parent Control (VIEW TIMER) VIEW TIMER This function allows you to restrict Rear Projection TV viewing times and also to control Rear Projection TV usage. This function is for preventing your children from watching too much Rear Projection TV. • It is recommended that the “OFF TIME” function and the “VIEWING TIME” function are both set under the “VIEW TIMER”...
  • Page 44 Parent Control (VIEW TIMER) (Continued) POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER Press to move the “...

  • Page 45: Channel Setup

    Channel Setup If EZ SETUP does not memorize all the channels in your region, follow the instructions below to manually memorize the channels. AIR/CABLE Setting POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE...

  • Page 46: Saving Broadcast Tv Channels To Memory (Channel Search)

    Channel setup (Continued) Saving Broadcast TV channels to memory (Channel Search) POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER Repeat steps 1 to 3 of AIR/...

  • Page 47: Adding Weak Or Additional Channels Or Erasing Unwanted Channels From Tv Memory

    Channel setup (Continued) Adding Weak or Additional Channels or Erasing Unwanted Channels from TV Memory POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP...

  • Page 48: Favorites

    Channel setup (Continued) FAVORITES FAVORITES allows you to program four favorite channels, in four different categories. (A total of 16 channels) By setting the FAVORITES channels in advance, you can select your favorite channels easily. Press POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU...

  • Page 49: Universal Plus Function

    Channel setup (Continued) UNIVERSAL PLUS Function VCR/DVD input mode will be selected automatically when pressing VCR/DVD player PLAY button on the UNIVERSAL REMOTE CONTROL. (For VCR/DVD player connections, see pages 9 ~ 11) POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE...

  • Page 50: Setup

    Setup LANGUAGE The language for the ON SCREEN DISPLAY can be set to ENGLISH, SPANISH or FRENCH. POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE...

  • Page 51: Gray Screen

    Setup (continued) GRAY SCREEN Automatically turns the screen gray if a broadcast signal is not received. POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP...

  • Page 52: Energy Save

    Setup (Continued) ENERGY SAVE This feature lets you lower the power consumption of your Rear Projection TV which in turn saves electricity and minimizes the impact on the environment. When this feature is turned on, it reduces the brightness of the Rear Projection TV to a level that consumes approximately 20 percent less energy than when the feature is turned off.

  • Page 53: Convergence Adjust

    Setup (Continued) CONVERGENCE ADJUST Your Rear Projection TV has three color projection tubes: one for red, one for green, one for blue. When mixed together in the proper proportion, the output of these three color tubes can produce any color. To produce these colors, however, the beams must be precisely aligned over each other so that the colors can be mixed.
  • Page 54 Setup (Continued) POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER IMPORTANT Specify the crosshatch which stands out with a comparatively uneven color by using .

  • Page 55: Input Mode

    Setup (Continued) INPUT MODE You can select the input signal in INPUT 3 and INPUT 4. The setting items vary in INPUT 3 and INPUT 4. POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT.

  • Page 56: Ch/Input Id

    Setup (Continued) CH/INPUT ID With the “CH ID” of the CH/INPUT ID function, it is possible to input the names (up to four letters) of channels, for example CNN, NBC. With the “INPUT ID”, it is possible to input names (up to four letters) for each of the input terminals on the Rear Projection TV (for example, VCR, DVD, STB).

  • Page 57: Changing Screen Size

    • Continuous operation for extended periods in 4:3 mode may burn the screen. Marantz thus recommends that use of this mode should be limited. PANORAMIC LETTERBOX...

  • Page 58: Selecting Ddfc Mode Or Av Mode

    Selecting DDFC Mode or AV Mode Selecting DDFC Mode POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD DDFC POWER Note DDFC Mode change only operates with 480I, 480P,...

  • Page 59: Multi-Screen Function

    Multi-screen Function View two Screens (TWIN PICTURE Screen) The screen can be split vertically, making it possible to view different images on the left and right. POWER VCR/ DVD/ CATV • Press DIRECT ACCESS ( PERSONAL PREFERENCE • Press ENTER MENU AV MODE MUTE...

  • Page 60: Making Notes From The Program Content (Freeze Screen)

    Multi-screen Function (Continued) Making Notes From the Program Content (Freeze Screen) The screen can be frozen, such as for taking down a recipe from a cooking program or address for entering a contest. POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE...

  • Page 61: Searching For A Program On A Different Channel (Search Screen)

    Note screen. Marantz thus recommends that use of the Search function should be limited. • The 3-SEARCH screen function is disabled when “STATUS” of the V-CHIP is “ON”. • The Closed Caption function does not work when using the 3-Search function.

  • Page 62: Interchanging The Left And Right Screens You Are Currently Watching (Swap Screen)

    Multi-screen Function (Continued) Interchanging the Left and Right Screens you are Currently Watching (Swap Screen) SWAP to interchange the left and right screens you are currently watching. POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT.

  • Page 63: Operation Of The Remote Control For Other Devices

    Operation of the Remote Control for Other Devices ENTER VCR/DVD POWER MENU CH/SKIP AV MODE MUTE INPUT ANT-A/B DISPLAY PLAY ENT. FLASHBACK TWIN PICTURE SEARCH Q-SOUND VIEW FREEZE SELECT MODE INPUT SWAP CM SKIP TITLE PAUSE PLAY FF CH/SKIP PAUSE STOP VCR/DVD STOP...

  • Page 64: How To Identify A Vcr

    Operation of the Remote Control for Other Devices (Continued) How to Identify a VCR POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP VCR/DVD...
  • Page 65 Hitachi Instant Replay JC Penney 04, 06, 24, 30 15, 41, 42 Kenwood Lloyds Magnavox 04, 05, 08 Magnin Marantz Memorex 04, 10, 24, 29 Minolta Mitsubishi 17, 18, 39, 40 Montgomery Ward 02, 43 VCR BRAND CODE NUMBER Multitech...

  • Page 66: How To Identify A Dvd Player

    Operation of the Remote Control for Other Devices (Continued) How to Identify a DVD Player POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP...

  • Page 67: How To Identify A Dtv Stb (Digital Tv Set-Top Box)

    Operation of the Remote Control for Other Devices (Continued) How to Identify a DTV STB (Digital TV Set-Top Box) Use the following steps and the list below to quickly find the remote control code for your DTV STB. POWER VCR/ DVD/ CATV •...

  • Page 68: How To Identify A Cable Converter

    Operation of the Remote Control for Other Devices (Continued) How to Identify a Cable Converter POWER VCR/ DVD/ CATV PERSONAL PREFERENCE ENTER MENU AV MODE MUTE INPUT ANT-A/B DISPLAY ENT. FLASHBACK TWIN PICTURE Q-SOUND VIEW MODE INPUT TITLE PLAY FF CH/SKIP PAUSE STOP...

  • Page 69: Specifications

    07, 08, 19, 25, 28, 29, 32, 33, 40, 41 01, 16, 38 Oak Sigma Panasonic 27, 39 Specifications Model PV6111W Signal System NTSC Channel AIR 2ch – 69ch CATV 1ch – 125ch Antenna input ANT A/B 75 Video input...

  • Page 70: Using The Video And Audio Input Jacks

    Using the Video and Audio Input Jacks Connecting video equipment for video playback • When the television is connected to video equipment as shown below, the material being played back on the video equipment can be seen on the television screen. Connecting a video device equipped with a video output terminal (Front terminals of Rear Projection TV) When noise or distortion appears on TV...
  • Page 71 VIDEO terminal, unplug equipment connected to the corresponding S-VIDEO terminal. • It is the intent of Marantz that this product be used in full compliance with the copyright laws of the United States and that prior permission be obtained from copyright owners whenever necessary.

  • Page 72: Using The Audio Output Jacks

    Using the Audio Output Jacks These jacks are used for connecting a standard studio amplifier. Control of STEREO/MONO/SAP, BASS, TREBLE, BALANCE, VOLUME and MUTE is retained at the Rear Projection TV. These jacks relay the audio signals of all programs being displayed on the Rear Projection TV screen. (EXCEPT FOR HD AND COMPONENT SIGNALS) COMPONENT...

  • Page 73: Before Calling For Service

    Before Calling for Service Check these items and see if you can correct a problem with a slight adjustment of the controls. QUICK SERVICE CHECK LIST POSSIBLE REMEDY Try a new channel, if OK, then possible station trouble. Is Rear Projection TV plugged in? Power at outlet? Is Rear Projection TV’s POWER button on? Is antenna connected to terminal on the back of the set? If outside antenna is being used, check for broken wire.

  • Page 74: Unidad Principal

    Unidad Principal Sección de control delantera POWER (potencia) Pulsar Pulsar de nuevo POWER POWER VIEW Área sensor para el control remoto Para abrir la cubierta DETRÁS DE LA CUBIERTA Botón MENU (Menú) Pulse el botón MENU (Menú) para acceder a la pantalla del MAIN MENU (Menú...

  • Page 75: Funciones Básicas Del Control Remoto

    Funciones Básicas del Control Remoto Este control remoto puede usarse para operar el televisor de retroproyección, una videograbadora, un decodificador DTV STB, un reproductor de video DVD y un convertidor de cable TV. Los botones que pueden usarse varian de acuerdo al dispositivo conectado. Para los detalles, refiérase a la página siguiente. Ventana del transmisor infrarrojo POWER (alimentación) Pulsar...

  • Page 76: Antes De Llamar Al Servicio De Reparaciones

    Antes de llamar al Servicio de Reparaciones Verifique los siguientes puntos para ver si puede solucionar el problema. LISTA DE COMPROBACIONES DE SERVICIO RAPIDO POSIBLE SOLUCIÓN Pruebe con otro canal y si todo está bien, el problema puede ser de la emisora. ¿Está...

  • Page 77: Unité Principale

    Unité Principale Commandes avant POWER (Alimentation) Appuyez une fois sur cette touche Appuyez à nouveau sur cette touche POWER POWER VIEW ZONE DU CAPTEUR DE TELECOMMANDE Pour ouvrir le couvercle Derrière le couvercle Touche MENU Appuyez sur cette touche pour accéder à la page de menu principal (MAIN MENU).

  • Page 78: Fonctions De Base De La Télécommande

    Fonctions de Base de la Télécommande Cette télécommande peut être utilisée pour faire fonctionner le téléviseur à rétroprojection, un magnétoscope, un décodeur DTV STB, un lecteur vidéo DVD et un convertisseur de télévision par câble. Les touches utilisables varient selon l’appareil utilisé. Consultez la page suivante pour les détails. POWER (Alimentation) Une pression sur cette touche Marche.

  • Page 79: Avant De Faire Appel Au Service Après-Vente

    Avant de faire appel au Service Après-vente Vérifiez les points suivants pour voir s’il n’est pas possible de résoudre le problème par un simple ajustement des commandes. LISTE DE VÉRIFICATION RAPIDE CORRECTION POSSIBLE Essayer une autre chaîne. Si normal, panne possible de station. Le téléviseur à...

  • Page 80: Dimensions For Installation

    DIMENSIONS FOR INSTALLATION 53.62" (1362) 56.00" (1422) 48.07" (1221) 44.88" (1140) 56.1" (1425) 52.32" (1329) PV6111W DIMENSIONS SHOWN AS INCHES (MM) 28.89" (734) 13.86" (352) 1.89" (48) 0.75" (19) 25.47" (647)
  • Page 81 NOTES...
  • Page 82 NOTES...
  • Page 83 NOTES...
  • Page 84 2) Marantz America will incur all labor charges for repairs during the warranty period. 3) Marantz America will incur all freight charges for warranty repairs, both to Marantz and the return to the customer.
