Summary of Contents for Blue Line Innovations H460S Series

  • Page 1 MODELS : H460S*, H461S*, H551S*, H461M*, H551M*...

  • Page 2: Table Of Contents

    DIGITAL SIGNAGE Contents Major features ....................2 Safety Information ..................2 Be sure to understand ..................4 Check the accessories list ................5 Proper location for product installation ............5 Title and function of each part ..............6 Support timing for HDMI/DVI ..............11 Support timing for PC .................12 Adjusting OSD and explanation of its function ........13 Diagnosis .....................30 Specifications ....................32...

  • Page 3: Major Features

    DIGITAL SIGNAGE Major features This product has been designed to enable users ease of use and display information effectively and conveniently. • Anti-vandalism glass • All Weather Capable • Automatic temperature control • Auto Light Sensor function • High brightness level for readability against direct sunlight Safety Information This product is designed to ensure user's safety.
  • Page 4 DIGITAL SIGNAGE - Do not use or place sharp objects near the LCD surface because this can cause in itself damage to the product. - When cleaning the LCD screen / surface, do not use strong chemicals such as ethyl, ethyl or a Isopropyl.

  • Page 5: Be Sure To Understand

    DIGITAL SIGNAGE Be sure to understand Image quality of the product CAUSE Due to the nature of LCD's property, afterimage can occur. Afterimage appears when identical frames / images are displayed continuously. If displayed for prolonged periods of time this can become permanent. PREVENTION When you display a freeze frame for a long time, lower the brightness and contrast (Brightness, 70/ Contrast, 80).

  • Page 6: Check The Accessories List

    DIGITAL SIGNAGE Check the accessories list Please check the following components provided with the product after you open the box. Remote control User's manual Please check the following components provided with the product after you open the box and contact the dealer if any missing. The contents may vary depending on models and sometimes the contents may be attached on the product.

  • Page 7: Title And Function Of Each Part

    DIGITAL SIGNAGE Title and function of each part POWER SOURCE MENU SELECT Control panel 3 4 5 6 7 8 9 0 * The locations of OSD board and remote control receiving sensor may vary depending on models. Remote control receiving sensor. Menu button : to display menu or exit from the menu.
  • Page 8 DIGITAL SIGNAGE Terminal panel - Type A HDMI IN UPGRADE DVI OUT PC AUDIO IN D-SUB IN RS-232C OUT D-SUB OUT RS-232C IN Terminal panel - Type B 6 7 89 0 ! PIR SENSOR IN (Option) PC AUDIO IN HDMI IN UPGRADE Port : 7 0 !
  • Page 9 DIGITAL SIGNAGE • Model: H460S* - Rear • Model: H461S*, H551S* - Front Terminal Panel Terminal Panel Control Panel Control Panel...
  • Page 10 DIGITAL SIGNAGE • Model: H461M* - Front • Model: H551M* - Front Control & Control & Terminal Panel Terminal Panel...
  • Page 11 DIGITAL SIGNAGE Remote control    To turn the power on or off. Move up in OSD menu.   To move left or control the volume down in OSD menu.  To move right or control the volume up in OSD menu. ...

  • Page 12: Support Timing For Hdmi/Dvi

    DIGITAL SIGNAGE Support timing for HDMI / DVI Horizontal frequency Vertical frequency Resolution (KHz) (Hz) 480p 640 x 480p 576p 720 x 576p 720p 1280 x 720p 50 / 60 1080i 1920 x 1080i 50 / 60 640 x 480 31.47 59.94 800 x 600...

  • Page 13: Support Timing For Pc

    DIGITAL SIGNAGE Support timing for PC Horizontal frequency Vertical frequency Resolution (KHz) (Hz) 640 x 480 31.47 / 37.5 59.94 / 75 720 x 400 37.5 800 x 600 37.88 / 46.88 / 48.28 60.32 / 72.19 / 75 1024 x 768 48.36 / 60.02 60.00 / 75.03 1360 x 768...

  • Page 14: Adjusting Osd And Explanation Of Its Function

    DIGITAL SIGNAGE Adjusting OSD and 1. Press the SOURCE button. In p u t S o u rce 2. Press ▲ / ▼ button to select the desired Source. explanation of its 3. Press ↲ button to selection. function H D MI Input &...
  • Page 15 DIGITAL SIGNAGE How to Select the Picture Users can automatically adjust the picture mode according to the input mode. Mode 1. Press Menu button. Picture Menu items appear on the screen. Picture Mode Custom 2. Press ↲ button to select “Picture” Icon. “Picture mode” is Custom ...
  • Page 16 DIGITAL SIGNAGE How to Set the Desired Users can manually adjust their desired picture Picture Picture Custom Picture Mode Middle Brightness Custom  Contrast Colour Tone  Size      U Adjust Menu U Move Menu Enter Adjust 1.
  • Page 17 DIGITAL SIGNAGE Users can adjust color as users want. How to Select a Colour Tone Picture Colour Tone Picture Mode Middle Colour Tone Normal Custom  Colour Tone Green  Size Blue      U Adjust Menu U Move Menu Enter...
  • Page 18 DIGITAL SIGNAGE How to Set the Display Size Users can adjust the display scale as they want Picture Picture HDMI Picture Mode Picture Mode Custom  Custom  Colour Tone  Wide Colour Tone Wide  Size 4 : 3 Size 4 : 3 ...
  • Page 19 DIGITAL SIGNAGE How to set image adjustment 1. Press Menu button. Picture in PC mode Menu items appear on the screen. (Supported only in PC mode) 2. Press ↲ button to select "Picture" Icon. Auto Adjust  Phase "Picture Mode" is highlighted. H-Posilion 3.
  • Page 20 DIGITAL SIGNAGE How to Select the Audio Users can adjust sound mode automatically as they want. Mode (Speaker Option) 1. Press Menu button. Menu items appear on the screen. Sound 2. Press ▲ / ▼ buttons to move to “Sound” Icon. 3.
  • Page 21 DIGITAL SIGNAGE Users can adjust sound mode automatically as they want. How to adjust the Audio Mode Sound Sound Mode Standard 10KHz Volume 3KHz Balance L50 R50 Equalizer  1KHz Auto Volume 300Hz Sound Mode Stereo 100Hz HDMI Sound HDMI ...
  • Page 22 DIGITAL SIGNAGE How to Select Auto Volume This function will automatically give a similar volume size to each channel. 1. Press Menu button. Sound Menu items appear on the screen. Mode 2. Press ▲ / ▼ buttons to move to "Sound" Icon. Volume 3.
  • Page 23 DIGITAL SIGNAGE How to Select HDMI Sound 1. Press Menu button. Sound Menu items appear on the screen. Mode 2. Press ↲ button to select “Sound” Icon. Volume “Mode” is highlighted. Balance 3. Press ▲ / ▼ buttons to move to “HDMI Sound”. Equalizer ...
  • Page 24 DIGITAL SIGNAGE How to Reset 1. Press Menu button. Menu items appear on the screen. Setup 2. Press ▲ / ▼ button to move to "Setup Icon" and Press ▶ or ↲ buttons. Reset  Time  "Reset" is highlighted. Language 3.
  • Page 25 DIGITAL SIGNAGE <Go to step 6 if you need to set the "On or Off Timer"> Time 6. Press ▲ / ▼ buttons to move to "On or Off Timer". Clock 05 : 00 7. Press ▶ or ↲ buttons to select "On or Off Timer" . On Timer 00 : 00 8.
  • Page 26 DIGITAL SIGNAGE How to set OSD 1. Press Menu button. Setup Transparency Menu items appear on the screen. Reset  2. Press ↲ button to select "Setup" Icon. Time  "Reset" is highlighted. Language 3. Press ▲ / ▼ buttons to move to "OSD Tone" OSD Tone 4.
  • Page 27 DIGITAL SIGNAGE How to select DCR 1. Press Menu button. Setup Menu items appear on the screen. Reset  2. Press ▲ / ▼ button to move to “Setup” Icon. Time  3. Press ↲ button to select "Setup" Icon. Language "Reset"...
  • Page 28 DIGITAL SIGNAGE This function prevents image burn-in problem on LCD screen. How to select Pixelshift 1. Press Menu button. Setup Menu items appear on the screen. Reset  2. Press ▲ / ▼ button to move to “Setup” Icon. Time ...
  • Page 29 DIGITAL SIGNAGE How to Set the Temperature "Temperature Control" allows you set up fan operation according to interior temperture of the product. Control Multi Multi Temp Control  Fan Control Auto Light Sensor  Fan Active Temp 36 °C Hysteresis 5 °C Temprature 29 °C...
  • Page 30 DIGITAL SIGNAGE How to Set the Light Sensor “Light sensor” is a feature which the product have the ability to adjust the brightness of the screen automatically according to the external brightness. Multi Temp Control  Light Sensor  Auto High Middle ...

  • Page 31: Diagnosis

    DIGITAL SIGNAGE Diagnosis When the product is not working properly, please check before you the customer center. Symptoms How to solve the problem It happens not to show the screen noise when the power is on. Therefore it is not a Screen displays late after defect.
  • Page 32 DIGITAL SIGNAGE Symptoms How to solve the problem The screen displays Check the volume up and down with remote control and audio connection cable without the sound. No sound from either Confirm the status of the sound balance on OSD menu and check the connection of right speaker or left speaker cable.

  • Page 33: Specifications

    DIGITAL SIGNAGE Specifications H460S* : 1366 x 768 Pixel (HD) H461S*, H461M*, H551S*, H551M* : 1920 x 1080 Pixel (Full HD) H460S*, H461S*, H461M* : 1018.4 x 572.5 mm Screen size (HxV/mm) H551S*, H551M* : 1209.6 x 680.4mm H460S* : 1360 x 768 @60Hz Recommended resolution H461S*, H461M*, H551S*, H551M* : 1920 x 1080P @ 60Hz...
  • Page 34 < REMOTE CONTROL SPEC > 1. REMOTE CONTROL WAVE FORM 2. REMOTE CONTROL KEY CODE TABLE 1) Remote Control System Infrared rey system Custom Code : 7788H fosc=455KHZ fc=fosc/2=37.917KHZ DATA POWER 0x80 2) Signal code MUTE 0x81 • Transmission MENU 0x95 - One pulse EXIT...
  • Page 35 < RS232C COMMAND SPEC > 1. CONFIGURATION Example. 2 To FAN on Set ID No 2 1) SPEED : 9600 Baud/s, 8 bit, No parity, 1 Stop bit. Item HEADER SET ID COMMAND 2) Cable Connection askii did: CONTROLER(PC) hexa 0x64 0x69 0x64 0x3A 0x30 0x32 0x2D 0x70 0x6E...
