Summary of Contents for RICH INVERTEK U SERIES DAI-600U-12xx
-
Page 1: User Manual
利 佳 興 業 股 份 有 限 公 司 RICH ELECTRIC CO.,LTD. INVERTEK ® U Series Pure Sine Wave Inverter with UPS Mode USER MANUAL MANUAL VER. 2, 0808... -
Page 2: Table Of Contents
Content SAFETY INSTRUCTIONS ............1 A. G ......... 1 ENERAL AFETY RECAUTIONS B. E ..........1 XPLOSIVE RECAUTIONS C. P ....1 RECAUTIONS ORKING ATTERIES FEATURES................2 D. I ..............3 NTRODUCTION E. N ..........4 AME AND MAIN FUNCTION F. -
Page 3: Safety Instructions
Safety Instructions WARNING! Before installing and using your Inverter, read the safety instructions. A. General Safety Precautions A-1. Do not expose the Inverter to rain, snow, spray, bilge or dust. To Reduce risk of hazard, do not cover or obstruct the ventilation openings. -
Page 4: Features
C-2. Do not drop a metal tool on the battery. The resulting spark or short-circuit on the battery or other electrical part may cause an explosion. C-3. Remove personal metal items such as rings, bracelets, necklaces, and watches when working with a lead-acid battery. -
Page 5: Introduction
D. Introduction: The power inverter series are the member of the most advanced line of mobile AC power systems available. To get the most out of the power inverter, it must be installed and used properly. Please read the instructions in this manual before installing and using this model. -
Page 6: Name And Main Function
E. Name and main function： E-1. Front view： AC OUTPUT 220/230/240 50/60HZ E-1-1. ON/OFF switch： Power ON/OFF switch, leave in the OFF position during installation. E-1-2. POWER SAVING: Power energy saving enable. OVP：Over voltage protection. UVP：Under voltage protection. OVER TEMP：Over Temperature Protection. OVER LOAD：Over Load Protection. -
Page 7: Rear View
F. Rear View: F-1. Ventilation window: Do not obstruct, allow at least 2 inch for air flow. F-2. Battery terminals: Connect to 12V/ 24V/ 48V battery or other 12V/ 24V / 48V power source. 【＋】is positive,【－】is negative. Reverse polarity connection will blow internal fuse and may damage inverter permanently. -
Page 8: Connection And Testing
G. Connection And Testing: For a quick connection and performance check, please follow these guidelines. G-1. Unpack and inspect the power inverter, check to see that the power switch in the OFF position. G-2. Connect the DC NEGATIVE cable to the Negative (NEG-) terminal on the battery. -
Page 9: Installation
WARNING! Reverse polarity connection will blow a fuse in Inverter and may permanently damage the inverter. Damage caused by reverse polarity connection is not covered by our warranty. G-5. Set the power switch to the ON position, the indicator lights may blink and the internal alarm may sound momentarily. - Page 10 H-1-2. Cold Ambient air temperature should be between 0℃ and 40℃, the cooler the better. H-1-3. Safe Do not install in battery compartment or other areas where flammable fumes may exist, such as fuel storage are as or engine compartments. H-1-4.
-
Page 11: Ground Fault Circuit Interrupters (Gfci's)
H-2-1. Neutral Grounding: H-2-1-1. 120V model： The neutral conductor of the AC output circuit of the Inverter is automatically connected to the safety ground during inverter operation. This conforms to National Electrical Code requirements that separately derived AC sources (such as inverter and generators) have their neutral conductors tied to ground in the same way that the neutral conductor from the utility is tied to ground at... -
Page 12: Operation
certain receptacles in residential installations. While the true sine wave output of the Inverter is equivalent to the waveform provided by utilities, compliance with UL standards requires us to test and recommend specific GFCI’s. State power has tested the following GFCI-protected 15A receptacles and found that they functioned properly when connected to the output of the Inverter. - Page 13 I-1. Controls and indicators: The ON/ OFF switch turns the control circuit in the power inverter on and off. It does not disconnect power from the power inverter. The inverter operates from an input voltage ranging from: 10 to 16 VDC for 12V models. 20 to 32 VDC for 24V models.
-
Page 14: Operating Limits
I-4. Over voltage indicator: The over voltage indicator indicates that the power inverter has shut itself down because its input voltage has exceeded over detected voltage 12/ 24V version. I-5. Under voltage indicator: The under voltage indicator indicates that the power inverter has shut itself down because its input voltage has been lower than detect voltage 12/ 24V version. -
Page 15: Trouble Shooting
microwave over will consume 40% to 100% more than its advertised cooking power. Check the rating sticker on the back of the over to determine its actual power draw. The Power inverter may not be able to start some motors even though their rated current draw is within the power inverter. - Page 16 inverter as possible. ◆ Keep the cables between the battery and the power inverter as short as possible and twist them together with about 2 to 3 twists per foot. This minimizes radiated interference from the cables. K-2. Troubleshooting guide: WARNING! Do not open or disassemble Inverter, attempting to service the unit yourself may result in a risk of...
-
Page 17: Maintenance
L. Maintenance: Very little maintenance is required to keep your inverter operating properly. You should clean the exterior of the unit periodically with a damp cloth to remove accumulation of dust and dirt. At the same time, tighten the screws on the DC input terminals. -
Page 18: A-1. Dip Switch
Appendix A A-1. DIP Switch 120V Model Output Output Function Voltage Frequency. DC/AC OUT OFF OFF OFF OFF 120V 60Hz MODE. DC/AC + POWER OFF ON ON OFF 115V 50Hz SAVING MODE. ON OFF UPS MODE. OFF ON 110V UPS MODE +DELAY MODE ON ON 100V... -
Page 19: A-2. Circuit Configuration And Code Explanation
A-2. 1.DC-AC Structure schema: AC OUTPUT AC OUTPUT AC Transfer Switch 2. Code explanation (a) DC/AC OUT MODE No matter shore power has/ hasn’t the power, the AC output is supply by DC/AC, (so the AC Transfer Switch is ON). (No Power Saving Function) (b) DC-AC OUT MODE+POWER SAVING MODE: AC output power supply by DC/AC (AC Transfer Switch ON) When AC output load off, DC/AC will truning to... - Page 20 When AC input back to normal, the AC Transfer Switch from ON OFF, at this time the AC output power is again supply via AC input. ※ About AC input power at stander voltage ± 15% change will also treat as power unusually, so it will automatically Transfer to DC/AC output, this ±...
-
Page 21: Specification
SPECIFICATION DAI-600U-12xx DAI-1000U-12xx DAI-1500U-12xx DAI-2000U-12xx DAI-3000U-12xx Invertek Model No. DAI-600U-24xx DAI-1000U-24xx DAI-1500U-24xx DAI-2000U-24xx DAI-3000U-24xx Continuous Output power 600W 1000W 1500W 2000W 3000W Output power surge 800W 1400W 2000W 2800W 4200W 100/110/120V ± 2% ; 220V/ 230/ 240V ± 2% DIP switch select AC Output voltage Output voltage Regulation -8% / + 3%...
