Operation Manual for MA20 Food Mixer (Version 02)
I . Preface
Welcome to select MA20 Food Mixer. Please read carefully on the instruction
before your operation, and keep it handy for your further reference in the future.
II. Characteristics
1. All mechanical gear transmissions are with high efficiency.
2. The transmission is steady and reliable, low noise.
3. Multi-level transmission can be adapted to different mixing requirements.
4. Safe to use, all machines built with overload protection device.
5. The machine operates simply and smoothly.
III. Main Technical Parameters
Name
Bucket Capacity (L)
Main
Power
Frequency
Normal Rated Power
(KW)
Average Sound Level
(Lp)
Sound Power Level
(Lw)
Motor Rated Speed
(r/min)
Weight (Kg)
Shaft Speed
(r/min)
Mechanical Dimensions (mm)
Voltage
(V)
（Hz）
GradeⅠ
GradeⅡ
GradeⅢ
MA20 Food Mixer
20
220/110
50/60
1.1
66.3dB
77.3dB
1400/1725
114
97/120
220/271
316/389
See below
1
