AllwinTech OneInGate 111 Quick Install Manual

Voip router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OneInGate 111 VoIP Router
Quick Install Guide
Version: 0.9.6
(draft)
Document number: QIG-OneIn120-0.96
Date Issued by 09/21/2004
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OneInGate 111 and is the answer not in the manual?

Questions and answers

Related Manuals for AllwinTech OneInGate 111

Summary of Contents for AllwinTech OneInGate 111

  • Page 1 OneInGate 111 VoIP Router Quick Install Guide Version: 0.9.6 (draft) Document number: QIG-OneIn120-0.96 Date Issued by 09/21/2004...

  • Page 2: Table Of Contents

    Table of contents Chapter 1 Introducing OneInGate 120 VoIP Router ............... 3 1.1 Key Features ........................3 1.2 Specifications ........................3 Chapter 2 Getting Started........................ 5 2.1 Identifying External Components................... 5 2.2 Installation......................... 6 Chapter 3 Configuration ......................7 3.1 Connection ......................... 8 3.2 System status........................

  • Page 3: Chapter 1 Introducing Oneingate 120 Voip Router

    Chapter 1 Introducing OneInGate 120 VoIP Router 1.1 Key Features VoIP Support 2 simultaneous VoIP calls Support T.38 FAX relay Support QoS for VoIP Compliant with H.323 standard Build in Web call Server function Extensible by external IVR/CDR/Billing servers for value- added application Support Alternate gatekeepers Support worldwide off net call by ITSP service Support Multiple dialing plan / Call hunting group...
  • Page 4 LED Indicators : Power, Status, WAN linking , 4X LAN linking, Phone 1, phone 2 Supported Protocol: UDP, TCP, Standard H.323, NAT,BOOTP, TFTP, FTP, HTTP, TELNET, IEEE 802.3/ IEEE 802.3u Selectable Coders: G.711, G.723.1, G.726, G.729A DTMF / Call progress tone detection and generation G.168 echo cancellation 1 Reset button for load factory default IP parameters setting User friendly Web configure interface...

  • Page 5: Chapter 2 Getting Started

    Chapter 2 Getting Started 2.1 Identifying External Components Front Panel Message: Flash light means GW booting OK Ready: Constant light means VOIP service OK Line: The PSTN line is in use. VOIP: The VoIP line is in use Status: The server registers status Rear Panel (Figure2-2) 12V: For the included power adapter.

  • Page 6: Installation

    2.2 Installation Do not place heavy objects on the Router. Placing the Router in a well ventilated area is very important. Not doing so may cause damage to the unit. (Figure2-3)

  • Page 7: Chapter 3 Configuration

    Chapter 3 Configuration The default setting of DHCP Server inside OneInGate120 VoIP Router is turn ON, So please set up your PC TCP/IP network as “Get IP Automatically” from DHCP to get internal IP from OneInGate120. By default, The OneInGate120 will become the network gateway and default IP is 192.168.1.1 and will assign your PC IP as 192.168.1.X.

  • Page 8: Connection

    3.1 Connection Click “Connection” option below “System Setup” item: ( Figure3-2) Please select the type of Internet connection you have and set up the router to use the IP Address Automatically, Static-IP or PPPoE ADSL connection. If your ISP has not given you an IP address, select Obtain an IP Address Automatically (default).
  • Page 9 (Figure3-4) To use PPPoE ADSL connection, please select Yes in use “PPPoE” ADSL service and enter the “username” and “password” in the PPPoE setup section. Most of ADSL ISPs assign dynamic-IP settings to the router when using PPPoE. Please select Obtain IP Address Automatically(default setting).

  • Page 10: System Status

    3.2 System status “System Setup” → ”System status” to check system status. (Figure3-6)

  • Page 11: Voip Call Out

    3.3 VoIP Call Out User key in the phone number through phone set dial pad, then Gateway translate the phone number by the routing table setting here to destination IP & dial out number then Call out via network protocol (Figure3-7) Remark: For Notify remark for this rule.
  • Page 12 number is 886285123390 and the STRIPE field is setting to 4, the first 4 digits 8862 will be truncated and actually call out number will be 85123390. Prefix: The numbers will be added on the prefix of user key in number. For examples, if user key in the number is 85123390 and the PREFIX field is setting to 0028862, the actually call out number will be 002886285123390.

  • Page 13: Chapter 4 Voip Router Setting

    Chapter 4 VoIP Router Setting 4.1 VPN point-to-point VoIP phone environment setting This chapter will illustrate the enterprise uses the internal network or the VPN environment to establishes VoIP Router construction in details. Achieves the enterprise interior telecommunication to disburse the goal of “zero” cost. 4.2 Installation plan First at all, in order to GW makes effective communication to each other, collect all the following information that GW can work fine.

  • Page 14: Vpn Point-To-Point Voip Phone Construction

    4.3 VPN Point-to-point VoIP phone construction On net call: John (America) want to make a phone call to Mary (China) : He has to dial the number of “80252”, “802521” or “802522”. Lee (Taiwan) want to make a phone call to Mary (China): He has to dial the number of “80252”, “802521”...

  • Page 15: Setting Procedure

    4.4 Setting Procedure Step 1. Launch your browser and open the OneInGate120 Internal UI WAP page as http://192.168.22.1/admin Step 2. The default User name is voip in lower case, and the default Password is 1234. Step 3. The VoIP Router Web UI management will show as follow: Step 4.
  • Page 16 Step 5. VoIP Router Phone port Setting: Go to /Line Configure/Line Setting/ , input name and line number into the field that user had planned. For Example, the company A has an GW, and the GW phone number is 80236 which is in Taiwan: Name: Enter “Taipei1”...
  • Page 17 Step 6. VoIP Call Out configuration: To enter the item of ⁄Routing Setup⁄VoIP Call Out⁄, and in order to input dialing rule to each field. For example: the company A’s dialing rule is 5 + 1 digits, following the GW setting for Taiwan: Remark: input each Call-out location, example to fill “America”...
  • Page 18 Step 7. VoIP Call In setting: Users can setup call in dialup rule at /VoIP Setup/Routing Setup/VoIP Call In/. In the “Area Code”, enter phone number that others can call in, or add “1” or “2” in the end of phone number, that can make a difference between different phone port.
  • Page 19 Step 8. Save Modification: Click /System Maintenance/Save Modification/ to Save the modifications. Step 9. Reboot System: Click /System Maintenance/Upgrade , Reboot/Reboot system/ to reboot the system. *Please remember to press the Save Modification link every time after you modify the parameters.
