RM-55N-R Natural Gas/RM-55P-R Propane Gas
RM-50N-R Natural Gas/RM-50P-R Propane Gas
Automatic Gas Rice Cooker
OWNER'S MANUAL
SECTION I: Installation Instructions
WARNING
TO THE PURCHASER
Contact your local gas supplier and
ask instructions in the event the user
smells gas. This information should
be posted in a prominent location.
THE INSTALLER MUST
LEAVE THIS MANUAL
WITH THE UNIT AFTER
INSTALLATION.
THE CONSUMER IS TO
RETAIN THIS MANUAL
FOR FUTURE REFERENCE.
1
Advertisement
Table of Contents
Summary of Contents for RiceMaker RM-55N-R
- Page 1 NSF & ETL Listed: RM-55N-R Natural Gas/RM-55P-R Propane Gas Non-Certified: RM-50N-R Natural Gas/RM-50P-R Propane Gas Automatic Gas Rice Cooker OWNER’S MANUAL SECTION I: Installation Instructions FOR YOUR SAFETY TO THE PURCHASER Do not store or use gasoline or other Contact your local gas supplier and flammable vapors and liquids in the ask instructions in the event the user vicinity of this or any other smells gas. This information should appliance.
-
Page 2: Component Identification
Congratulations on your purchase of your RiceMaster Automatic Gas Rice Cooker. With proper installa- tion, care and use, it should provide years of reliable service. IMPORTANT NOTE: The RM-50 is not NSF or ETL listed. However, its function and most specifica- tions are identical to the RM-55. RM-55 parts are interchangeable with RM-50. Except for listings and certification, information in this manual for the RM-55 is the same as the RM-50. COMPONENT IdENTIFICATION jacket Window SPECIFICATIONS Specifications: RM-55N-R RM-55P-R Type of gas Natural Propane Btu 34,600 27,300 Gas connection 3/4” NPT 3/4” NPT Liquid capacity 24 qts. 24 qts. Unit size 17”h x 19”d x 23” 17”h x 19”d x 23” Net weight 47 lbs 47 lbs Carton size 21” x 21” x 17” 21” x 21” x 17” Master Carton 1 unit (4.4 cu. ft.) 1 unit (4.4 cu. ft.) Shipping weight 50 lbs 50 lbs Color... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS INSTALLATION: 1. The gas supply line must be of adequate size to insure maximum efficiency of the unit. 2. The installation must conform with the National Fuel Gas Code, ANSI Z223.1, Natural Gas Installation Code, CAN/CGA-B149.1 or the Propane Installation Code, CAN/CGA-B149.2, as applicable including: a. The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressure in excess of 1/2 NPT (3.45 kPa). b. The appliance must be isolated from the gas supply piping system by closing its individual manual valve during any pressure testing of the gas supply piping system at test pressures equal or less than 1/2 psig (3.45 kPa). 3. Local regulations governing gas appliance installations must be complied with. 4. Equipment should be in an area with adequate ventilation. 5. Minimum spacing of 6” to combustible construction is required along back and side walls. Clearance for non combustible construction are the same as combustible clearances. For use only on noncombustible floors. 6. Materials such as wood, compressed paper and plant fibers that will ignite and burn, must not be exposed near this unit. Local safety codes should be complied with in respect to fire hazard avoidance. 7. Use of the supplied pressure regulator is mandatory. Note: use of two regulators may cause insufficient gas flow. Consult with your installer but always comply with above codes. 8. Keep the appliance area free and clear from combustible materials, gasoline and other flammable vapors and liquids. 9. Locate this appliance in a well ventilated place. do not block or cover the opening between the shroud and pot. -
Page 4: Lighting And Shutdown Instructions
LIGHTING ANd SHUT dOWN INSTRUCTIONS Always follow these lighting and shut down instructions when lighting your rice cooker. A five minute complete shutoff period is required before lighting or relighting pilot. Check for gas leaks before relighting unit. Use soapy water or other suitable leak detector. Rinse off the soapy water after testing. Notice to Installer: The following must be performed to insure proper operation. 1. Remove Pot, Outer Jacket, and Drip Tray. 2. Turn gas valve to “ON” position as in figure 2 below. 3. Gently push on the #2 COOK button. It should stop half way down and not engage. This is a safety feature that does not allow accidental start of the main burner unless the pilot button has already been pushed. 4. Push the left button marked #1 START down until you hear a click, then release it. This is the ignition lever and the pilot should light. The red button marked WARM controls the pilot and is hidden by the #1 START button when off. Pushing the #1 START button also depressed the WARM button, exposing it. It will stay down until pushed up to extinguish the pilot. If the pilot has not lit, repeat until pilot lights. 5. If pilot fails to remain lit, see Trouble Shooting. 6. Replace the Pot, Outer Jacket, and Drip Tray in their proper order. With the pilot lit, push the #2 COOK button down to its position without water in the pot. The rice cooker should shut off within 3 to 4 minutes. If it fails to shut off, push the #2 COOK button up to its off position and see Trouble Shooting. If it shuts off normally, add a gallon of water and wait for the “click” sound indicating that the sensor has reset. With the pilot lit, again press the #2 COOK button. The rice cooker should boil the pot dry and then shut off. If it fails to shut off normally, push the #2 COOK button up to its off position and see Trouble Shooting. SHUT DOWN: When removing the pot, make sure to push the red button WARM until it clicks and is hid- den by the start button. It is then in the “OFF” position. A five minute complete shutoff period is required before lighting or relighting pilot. WARNING: When igniting the pilot, position the Jacket Window directly over #1 START and #2 COOK buttons. Do not be too close to the viewing hole when igniting. START Start Button Main Burner Butto COOK WARM Pilot/Warmer Button Gas Valve OFF Position... -
Page 5: Rear Connection
REAR CONNECTION PRESSURE REGULATOR RM-55 REAR CONNECTION INSTALLATION INSTRUCTIONS To install the provided pressure regulator: a. Locate gas supply for the rice cooker. Installation must comply with the National codes so there should be a shut off valve on the gas supply line to the rice cooker. b. Install the supplied pressure regulator at the end of the rear connection manifold. An arrow on the body of the pressure regulator indicates the direction of the gas flow. The arrow must be pointing in the direction to the rice cooker. The rice cooker will not operate if the regulator is improperly installed. c. If required, install the supply side of the quick disconnect hose (provided by others) to the regulator per the manufacturer’s instructions. d. Check your installation for leaks with an approved leak detector. Be sure to use approved materials on the pipe threads to prevent gas leaks. When appropriate, light the rice cooker and check for proper operation. (718) 388-5650 (800) 221-5032 except NY fax: (718) 388-5860 townfood.com... - Page 6 NSF & ETL Listed: RM-55N-R Natural Gas/RM-55P-R Propane Gas Non-Certified: RM-50N-R Natural Gas/RM-50P-R Propane Gas Automatic Gas Rice Cooker OWNER’S MANUAL SECTION II: Operating Instructions FOR YOUR SAFETY TO THE PURCHASER Do not store or use gasoline or other Contact your local gas supplier and flammable vapors and liquids in the ask instructions in the event the user vicinity of this or any other smells gas. This information should appliance.
-
Page 7: Troubleshooting
TROUbLE SHOOTING DIFFICULTY CAUSE REMEDY Main burner shuts off Overloaded pot Remove washer below tip on while cooking shut off stem (picture on pg. 10) Cook lever bent Return to factory for service. Request RGA (page 15) Insufficient gas pressure Check gas pressure. Install all gas valves are open. Sensing element is worn out Replace Sensing Element per instructions on page 10. Insufficient Pilot Burner Insufficient gas pressure Check gas pressure. flame Install all gas valves are open. Contact your gas supplier if problem persists. Pilot orifice is blocked Clean or replace pilot orifice. Main Burner flame is Unit connected to incorrect Check Rating Plate. Confirm yellow. Black soot type of gas unit is connected to correct collects on bottom of type of gas. rice pot Air shutter closed Adjust/open air shutter Spillage on Main Burner or Clean or replace Main Burner blockage inside Main Burner Flame lifts off Main... - Page 8 PARTS dIAGRAM: RM-55/50 NATURAL & PROPANE GAS TOWN FOOD SERVICE EQUIPMENT CO., INC. • 72 Beadel St. • BKLYN • NY 11222...
- Page 9 PARTS dIAGRAM: RM-55/50 NATURAL & PROPANE GAS (718) 388-5650 (800) 221-5032 except NY fax: (718) 388-5860 townfood.com...
- Page 10 PARTS LIST: RM-55/50 NATURAL & PROPANE GAS Dwg. No. Parts No. Descripton 56881 Cover Handle, Heat Resistant 56882 Stainless Steel Rice Pot Cover w/handle 56881-S Cover Handle Screw 56853 Cast Iron Aluminum Rice Pot 56855 Encased Sensing Element, Bimetalic 56856 Sensing Element Retaining Spring 5/6 56854 Sensing Element Kit 56884 Outer Jacket for RM50 56884A Outer Jacket for RM55 “RiceMaster” 56885A RM-55 Stainless Steel Base Cover (56885 for RM50) 56852-1 Lower Body for RM50 (RED) 56852-1A Lower Body for RM55 (GREY) 56866 Control Panel Frame 56863 Non-Mar Feet 56852-2 Cast Iron Burner 56878 Pilot with Retaining Plate...
-
Page 11: Limited Warranty
LIMITEd WARRANTY Town Food Service Equipment Co., Inc. (Town) warrants the equipment to be free of defects in materi- als and workmanship, subject to the terms specified below. This warranty is limited to parts replacement and does not include any labor allowance. Any service charges or charges for parts replacement are your responsibility. Town warrants the RM-55 and RM-50 to be free of defects in materials or workmanship for a period of six months. The warranty period shall commence at time of shipment from Town. The warranty period may be extended, at Town’s option, if proof of installation (specifying model and serial number) at a later date, but in no case shall warranty be extended beyond nine months after date of shipment from Town. Parts and labor are covered for the warranty period for properly packed units returned to Town prepaid. Town cannot be responsible for shipping damages to any unit returned with improper packaging. Parts that have failed due to defective materials or workmanship will be replaced at no charge. Units repaired under warranty will be returned freight prepaid. Warranty for the new parts will be for the remainder of the origi- nal warranty period. This warranty does not cover any failures or operating difficulties due to accident, abuse, misuse, alteration, misapplication, improper installation or improper maintenance or service. Town does not authorize any person or company to assume on its behalf any obligation or liability in con- nection with this unit in any matter whatsoever. If warranty service becomes necessary, bring the unit to the dealer who sold you the unit. Request them to carefully pack the unit. Be sure to insulate the enamel jacket from the rice pot. If the pot is allowed to con- tact the enamel jacket during shipment, it will become chipped. If the base is not properly packed it may become dented. Town will charge for repairs to units returned due to abuse for any reason. The returning agency is entitled to request from the purchaser the costs of shipping and handling charges to return the unit. Before any unit is returned, call Town at (718)388-5650 and request a Return Goods Au- thorization (RGA) number. Be advised this RGA is only authorization to return your unit for evaluation. No credit of any kind may be taken arising from an RGA. Your unit will be inspected to verify the dif- ficulty for which it was returned. Once the difficulty is verified, it will be repaired and the unit returned at no charge if due to faulty materials and/or workmanship. If defective for any other reason, the unit will be repaired and the customer charged for the cost of the labor and materials for the repair plus return delivery costs. For your records, you may wish to record the following information as it will be required in the event ser- vice is required: Dealer unit purchased from__________________________________ date_____________________ Unit Model No.___________________ Serial No.__________________ type of gas _________ (718) 388-5650 (800) 221-5032 except NY fax: (718) 388-5860 townfood.com... - Page 12 MExICAN RICE Try Maria’s Mexican Rice*, an authentic recipe from Veracruz. We brought this back from a customer of a Mexican distributor. It is simple to do and yields excellent flavors. 8 oz. vegetable or peanut oil 4 quarts cooled chicken stock 3 lbs washed rice 3 boneless chicken breasts, precooked & cubed juice of one lemon 2-3 sprigs finely chopped cilantro two cloves garlic, smashed, finely chopped 3 tablespoons salt one 28 oz. can crushed tomatoes 2 finely chopped jalapeños Push the #1 Start button to light the pilot. Verify ignition of the pilot through the jacket window. Push the #2 Cook but- ton and light the main burner. Verify ignition of the main burner through the jacket window. Add the oil. There should be sufficient oil to cover the bottom of the rice pot. Allow the oil to heat. The sensor in the bottom of the pot is designed to turn the rice cooker off when it senses the water in the pot is gone. The oil in the bottom of the pot is being heated by the burner and will surpass the temperature of boiling water. At this point the sensor will make a “click” sound and “pop” into its expanded position as the temperature of boiling water has been exceeded. This causes the #2 Cook button to jump to the off position and the burner will shut off. Mexican Rice is fried before liquids are added. The oil must be at frying temperature, about 375ºF. To do this, push the #2 Cook button once again to continue heating the oil. BEWARE: the automatic shut off feature of the sensor is now disabled and the unit will not shut off automatically. To turn off the main burner one must lift the #2 cook button. Heat the oil to frying temperature. Add grains of rice to test the temperature of the oil. When the test grains of rice sizzle and turn white, add the balance of the rice. Fry the rice by allowing it to cook for 30 seconds, then mix thorough- ly. Let it fry for an additional 30 seconds, then mix again. Repeat this process until the rice begins to ‘cashew’ or have a light brown color, about 7-10 minutes. After the rice is started to change color, add the garlic and stir for one more minute. At this point make sure to wear a heat resistant mitt as the pot is very hot and the liquids about to be added will vaporize quickly and one can be scalded. Stir in crushed tomatoes and fry for one more minute. Turn off the burner by raising the #2 Cook button to its off posi- tion. Add the balance of the ingredients and stir to mix. About 4-5 minutes after you shut off the main burner, listen for a “click” sound indicating the sensor has reset to its original shape restoring its automatic capabilities. Relight the main burner by pushing down the #2 Cook button. Verify ignition through the jacket window. The unit will now cook the rice and automatically shut off when the rice is done, about 15 minutes. When the unit shuts off, allow the rice to “cure” undisturbed in the rice cooker for 10 minutes. Then mix and serve the rice. Tip: use the rice cooker to braise the chicken. The braised chicken adds flavor to the rice when fried in the same pot. NOTE: Consistency of rice will vary depending on amount of chicken stock used. For very spicy rice add additional jalapeños to taste. Be creative... you may add peas, corn, or finely chopped bell peppers. Bueno provecho! * Recipe compliments of Maria Asuncion Aquirre de King, Dim Sum King, Veracruz, Mexico Rev. 03/07 TOWN FOOD SERVICE EQUIPMENT CO., INC.
