Read this user manual carefully before using this product. Pictures shown in this manual are for reference only. Safety Precaution Please read all instructions carefully before using the device. Save this manual for further reference. Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
Compact design for easy operation Package List Accessories CT-HDVD-HDSTR-KIT: 1 x Transmitter, 1 x Receiver, 2 x Mounting ears 4 x Screws, 8 x Plastic cushions, 1 x User manual Power Adapter: 2 x Power Adapter (DC 5V 1A)
Page 4
The figure below illustrates a typical connection that can be utilized with the CT-HDVD-HDSTR-KIT1 and more than 1 CT-HDVD-HDSTR-RX with an Ethernet switch. One or more CT-HDVD-HDSTR-RX may be utilized in this case to broadcast signal from 1 CT-HDVD-HDSTR-KIT to 1 or more CT-HDVD-HDSTR-KIT2.
Power 4.2W Distance Ethernet switch: Consumption CT-HDVD-HDSTR-KIT2: 200m/656ft (CAT6) 3.5W 175m/574ft (CAT5e) Power Supply DC 5V 1A Resolution 1080P@60Hz(Max) Temperature 0 ~ 50℃/32 122F Humidity 10% ~ 90% 121x21x60mm Weight 80g/2.82oz Dimension 4.7x.9x 2.3in (W*H*D) CABLETRONIX 1-Year Limited Warranty...
Page 6
CABLETRONIX. (the "Company") warrants to the Original Purchaser that the item purchased is free from defects in workmanship or material under normal use. This warranty starts on the date of shipment of the hardware to the Original Purchaser.
