Summary of Contents for HiTi Digital WFT510

  • Page 1: Table Of Contents

    5-2. Transmitting Image from Camera to p510Si and printing out image………..9 6. How to Transmit Image from WFT 510 to PC 6-1.Installing WFT PC Kit…………………………………………………………..11 6-2. Building up a network setting for WFT510 via WFT PC Kit……………….. 13 Infrastructure……………………………………………………………14 Ad-hoc……………………………………………………………………16 6-3.

  • Page 2: Checking Package Contents

    1. Checking package contents HiTi Wireless Foto Transmitter WFT510 WFT510 Carry Bag WFT PC Kit CD USB Cable User Manual Warranty Card Hook Note: 1. If something missed from the package, please contact your local dealer or HiTi service center nearest to you.

  • Page 3: Getting The Latest Update

    2. Getting the latest update HiTi Digital Inc. website provides the latest driver, application, user’s manual, printer firmware, and so on for users to download. Please visit our website at www.hiti.com for more information. Any questions toward HiTi product(s), please contact your local service center for...

  • Page 4: Introduction Of Wft510

    X(off) X(off) X(off) Under PictBridge Mode O(on) X(off) X(off) O(on) USB connected error O(on) O(on) X(off) X(off) Camera transmit data to WFT510 O(on) X(off) X(off) Q(blink) WFT510 transmit data to host O(on) X(off) Q(blink) X(off) Transmit error O(on) O(on) X(off)

  • Page 5: Making Wft510 Ready To Work

    4. Making WFT510 Ready to Work 4-1 Inserting Batteries Pushing up the battery chamber cover of WFT510 Inserting 4 rechargeable (Recommend) or alkaline AA batteries. WARNING: DO NOT MIX rechargeable and alkaline batteries. This can cause leakage or rupture, resulting in personal injury or property damage.

  • Page 6: Putting Wft510 Into Wft510 Carry Bag

    In order to maximize WFT510 performance, HiTi strongly recommend using rechargeable battery. The following measurement s are performed at a temperature 20℃ (68℉) and humidity 40%. HiTi WFT510 works with test device. Actual battery life could be varied by different cameras and different batteries. Type of rechargeable battery...

  • Page 7: How To Transmit Image From Wft 510 To Hiti P510Si Printer

    5. How to Transmit Image from WFT 510 to HiTi P510Si Printer 5-1. Configuring WFT510 with HiTi P510Si Printer Step1 Turn on P510Si Select [Settings] and press ( ) button Step 2 Select [Advanced Setting] Select [Wireless for Camera] and Press (...
  • Page 8 Step 5 Select SSID and press ( ) button WARNING: Tow or above P510Si printers at one place MUST select different SSID. Otherwise, WFT510 could transmit image to wrong printer due to same SSID Step 6 Press ( ) button...

  • Page 9: Transmitting Image From Camera To P510Si And Printing Out Image

    Step 10 P510Si will automatically configure with WFT510 Step 11 Press (×) button to exit and WFT510 will reboot Please wait until ONLY Green LDE is on WFT510 is ready to work with P510Si 5-2. Transmitting Image from Camera to P510Si and Printing out Image...
  • Page 10 Step 5 Switch LED (blue) blinking means WFT510 is receiving image from camera Step 6 Transfer LED (orange) blinking means WFT510 is transmitting image to P510Si Step 7 After receiving the image from WFT510, P510Si will print out the photo immediately...

  • Page 11: How To Transmit Image From Wft 510 To Pc

    6. How to Transmit Image from WFT 510 to PC via WFT510 6-1. Installing WFT PC Kit Step 1 Insert the CD into CD/DVD ROM, and then the computer will automatically star the installation. If the installation does not star automatically, please double...
  • Page 12 Step 5 Click [Next] to start installation procedure Step 6 Wait the installation process complete Step 7 Select [Setup WFT Driver] (default) and click [Finish] Complete WFT PC Kit installation...

  • Page 13: Building Up A Network Setting For Wft510 Via Wft Pc Kit

    6-2. building up a network setting for WFT510 via WFT PC Kit Step 1 Double click WFT PC Kit icon on the desktop The first page of WFT PC Kit will show up Icon Item Description Import Import profile from other device...

  • Page 14: Infrastructure

    Step 2 Click [Create a new profile] Select wireless structure: Infrastructure or Ad-hoc Infrastructure: An infrastructure configuration is a WLAN and wired LAN communication to each other through an access point. Ad-hoc: An Ad-hoc configuration is a group of wireless devices communication directly to each other (peer-to-peer) without the use of an access point.
  • Page 15 Step 2 Select Security method: [None], [WEP] Enter password and confirm password Click [Next] Open ASCII Type 5 ASCII character or, 13 ASCII character for System and example”Abe2Q” Shared Key Type 10 Hexadecimal digits or 26 Hexadecimal digits, for example “abc1234567…” None Do not need password Step 3.a...

  • Page 16: Ad-Hoc

    Step 4 Check Network setting Click [Save] to reserve this profile Step 5 Turn on WFT510 Use USB cable to connect PC and WFT510 Step 6 Select the profile you just created and click 。Ad-hoc Step 1 WFT PC Kit will automatically assign one set of SSID...
  • Page 17 Step 2 Select Security method: [None], [WEP] Enter password and confirm Click [Next] Step 3.a Select [HiTi File Server] (recommend) Click “ ”, you can select or create a receiving folder Click [Complete] IMPORTANT: Please Write down Server IP Step 3.b Select [Connect to my FTP server] Enter your FTP IP address, Port, ID, and Password Click [Complete]...

  • Page 18: Setting Up A Network On Pc To Connect Wft510 (For Ad-Hoc Mode)

    Turn on WFT510 Use USB cable to connect PC and WFT510 Step 6 Select the profile you just created and click 6-3. Setting up a network on PC to connect WFT510 (For Ad-hoc Mode) Windows XP Step 1 Turn on WFT510...
  • Page 19 Step3 Click [Network Communication] Step 4 Select [Wireless Network Connection] and click right bottom of mouse Select [Properties] Step 5 Select [Internet Protocol (TCP/IP)] and click [Properties] Step 6 Select [Use the following IP address] Enter the Server IP, Subnet Mask, and Default Gateway that you write down on page 16 and 17 Click [OK]...
  • Page 20 Select [View Available Wireless Networks] Step 8 Choose the SSID that you created and press [Connect] Wait until “Connected” Important: If you reboot WFT510, Please repeat step 7 and 8 Windows Vista Step 1 Turn on WFT510 Click [Network] Step 2...
  • Page 21 Step 3 Click [Manage network connections] Step 4 Select [Wireless Network Connection] and click right bottom of mouse Click [Properties] Step 5 Select [Internet Protocol Version 4 (TCP/IPv4)] and click [Properties] Step 6 Select [Use the following IP address] Enter the Server IP, Subnet Mask, and Default Gateway that you write down on page 14 Click [OK]...

  • Page 22: Transmitting Image From Camera To Pc

    Step 8 Choose the SSID that you created and press [Connect] Wait until “Connected” Important: If you reboot WFT510, Please repeat step 7 and 8 6-4. Transmitting images from Camera to PC Step1 Use USB cable* to connect WFT510 and camera...
  • Page 23 Canon 40D MUST be at Preview mode and then can switch to PictBridge Mode. Please check camera user manual “PictBridge Mode” part. Step 5 Switch LED (blue) blinking means WFT510 is receiving image from camera Step 6 Transfer LED (orange) blinking means WFT510 is...

  • Page 24: Test Network Setting

    6-5. Test network setting If you cannot connect WFT510 and PC/P510Si, WFT PC Kit provides [Test function] to help you test network setting and show the result. Step 1 Turn on WFT510 Use USB cable to connect PC and WFT510...

  • Page 25: Sub-Folder Function

    6-6. sub-folder function WFT510 provides sub-folder function to assist you managing your pictures. Step1 Make sure that WFT510 is on ready status and Switch LED is off. Step2 Consecutively press Switch button at least 5 seconds Switch LED (blue light) will blink and then you can loose the Switch button.

  • Page 26: Specification

    7. Specification Please notice that specification of WFT 510 is subject to change without notice. Item Description Hardware Wireless Standards IEEE 802.11b/g Compatible Transmission Method IEEE 802.11b: DQPSK, DBPSK IEEE 802.11g: OFDM Transmission Frequency 2,412MHz-2,472 MHz Antenna Gain 2 dBi Transmission Range Approximately 100m (With no obstructions between the transmitter and receiving...
