Red Hawk 32” Commercial Belt-Drive Mower Parts & Owner's Manual
  1. Manuals
  2. Brands
  3. Red Hawk Manuals
  4. Lawn Mower
  5. 32" Commercial Belt-Drive Mower
  6. Parts & owner's manual

Red Hawk 32” Commercial Belt-Drive Mower Parts & Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Havener Enterprises, Inc. • 368 S. Michigan Avnue • Bradley, IL • 60915
815.935.8383 • www.havenerenterprises.com
32", 36" & 48" Commercial Belt-Drive Mowers
Congratulations on the purchase of your new
Red Hawk mower.
Before any warranty service can be authorized you
must register this product with the manufacturer.
© Havener Enterprises, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 32” Commercial Belt-Drive Mower and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Red Hawk 32” Commercial Belt-Drive Mower

  • Page 1 Havener Enterprises, Inc. • 368 S. Michigan Avnue • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com 32”, 36” & 48” Commercial Belt-Drive Mowers Congratulations on the purchase of your new Red Hawk mower. Before any warranty service can be authorized you must register this product with the manufacturer. © Havener Enterprises, Inc.
  • Page 2 32” & 36” Frame Assembly Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 3 32”& 36” Frame Assembly Ite m N o. P a rt N umbe r D e scription 100-001 Tank Handle Mount Bracket 100-002 Shift Console 100-003 Plain Washer 2*10.5 id *26 od 100-004 Pivot Tube 200-001 Nut M10 GB923-88 100-005 Fender 200-002 Double end bolt m10*120 GB 901-88...
  • Page 4 48” Frame Assembly Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 5 48” Frame Assembly Ite m N o. P a rt N umbe r D e scription 100-001 Tank Handle Mount Bracket 100-002 Shift Console 100-003 Plain Washer 2*10.5 id *26 od 100-004 Pivot Tube 200-001 Nut M10 GB923-88 100-005 Fender 200-002 Double End Bolt M10*120 GB901-88 200-003...
  • Page 6 32” & 36” Front Deck Assembly Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 7 32” & 36” Front Deck Assembly Ite m N o. P a rt N umbe r D e scription 100-013 Idler Pulley I with Flange 132-004 Belt 32" Engine to Blade 200-006 Nylon Nut M10 GB889-86 200-016 Nut Flange M10 GB6187-86 100-014 Key 6.35*6*50 200-017...
  • Page 8 48” Front Deck Assembly Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 9 48” Front Deck Assembly Ite m N o. P a rt N umbe r D e scription 100-013 Idler Pulley with Flange 100-025 Pulley, Single 148-004 Pulley , Double 100-026 H-Bushing 100-024 Pivot Hub 100-021 Cutting Housing Assembly 100-022 Spacer 6 148-005 Blade 48"...
  • Page 10 32”, 36” & 48” Brake Assembly Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 11 32”, 36” & 48” Brake Assembly Ite m N o. P a rt N umbe r D e scription 200-001 Nut M10 GB923-88 100-005 Fender 100-034 Idler Arm RH 100-035 Idler Arm LH 200-021 Plain Washer 8 GB95-85 100-036 Brake Rod 100-037 Brake Lever RH 100-038...
  • Page 12 32”, 36” & 48” Transmission Drive Assembly Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 13 32”, 36” & 48” Transmission Drive Assembly Ite m N o. P a rt N umbe r D e scription 100-045 Flat Grip 100-046 Transmission Shift Lever Upper 100-047 Output Pulley 200-034 Nut 3/8-24 200-035 Screws M8*10 GB71-85 Peerless Part 200-011 Bolt M6*16GB/T794-93 100-049...
  • Page 14 32”, 36” & 48” Rear Deck Assembly Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 15 32”, 36” & 48” Rear Deck Assembly Ite m N o. P a rt N umbe r D e scription 200-045 Bolt M6*20 GB/T794-93 100-055 Neutral Switch Transmission 200-046 Bolt M10*45 GB/T794-93 200-038 Hexagon Bolt M10*60 GB5782-86 (for 48") 100-063 Pulley, Transmission 100-117 Woodruff Key, Transmission...
  • Page 16 32”, 36” & 48” Handle Control Assembly Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 17 32”, 36” & 48” Handle Control Assembly Ite m N o. P a rt N umbe r D e scription 100-072 Handle Grip 200-051 Nut M6 GB923-88 100-073 Traction Control Lever 100-074 Traction Rod 100-075 Clevis Pin Traction Control Lever 100-076 Roll Pin 100-077...
  • Page 18 32”, 36” & 48” Front Caster Assembly Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 19 32”, 36” & 48” Front Caster Assembly Ite m N o. P a rt N umbe r D e scription 200-026 Grease Fitting M6 GB1152-89 200-003 Hexagon Bolt M10*25 GB 5783-86 200-006 Nylon Nut M10 GB889-86 200-010 Plain Washer 10 GB95-85 200-031 Lock Washer 10 GB93-87 (For 32"...
  • Page 20 32”, 36” & 48” Fuel Tank Assembly Ite m N o. P a rt N umbe r D e scription Ite m N o. P a rt N umbe r D e scription 100-105 Fuel Shut Off Valve 100-102 Fuel Tank Cap 100-106 Fuel Line 100-103...
  • Page 21 32”, 36” & 48” Traction Wheel Assembly Ite m N o. P a rt N umbe r D e scription 132-006 Tire 13X5.00-6 (For 32") 100-110 Pulley, Traction 100-111 Spacer 11.5 100-112 Brake Hub 200-024 Lock Washer 8 GB93-87 200-060 Bolt M8*40 GB787-86 200-061 Bearing 6005 2RS...
  • Page 22 32”, 36” & 48” Electrical Components Ite m N o. P a rt N umbe r D e scription 100-060 Switch 200-062 Wire Tie 3 & 4 100-114 Key Switch & Key 100-115 Wiring Harness 100-055 Neutral Switch Transmission Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 •...

  • Page 23: Table Of Contents

    Bradley, IL • 60915 • 815.935.8383 www.havenerenterprises.com Owner’s Manual For Red Hawk 32”, 36” & 48” Commercial Belt-Drive Mowers TABLE OF CONTENTS About This Manual ...............4 Warranty .
  • Page 24 NOTES _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...
  • Page 25 NOTES _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...

  • Page 26: About This Manual

    Red Hawk mower dealer who has been specially trained on operation and service of Red Hawk mower. A space has been provided below to record information about your new Red Hawk mower. Please take time to record such information for future reference, especially when you contact an authorized Red Hawk mower dealer with questions.

  • Page 27: Warranty

    Red Hawk Owner’s Manual. This warranty does not cover any mower that has been altered or modified changing performance or durability. In addition, the warranty is not extended to repairs made necessary by the use of parts or accessories which, in the reasonable judgement of Havener Enterprises, Inc.

  • Page 28: Safety Information

    SAFETY INFORMATION Read This Manual Carefully And Thoroughly Before Operating The Mower! Training 1. Carefully and thoroughly read the owner’s manual. Allow adequate time to fully understand the controls and operation of the equipment. 2. Never allow anyone to operate the mower that has not read and fully understood the owner’s manual. 3.

  • Page 29: Operation Of The Equipment

    Operation of Equipment DANGER: GASOLINE IS HIGHLY FLAMMABLE AND EXPLOSIVE. DO NOT ADD FUEL WHILE THE ENGINE IS RUNNING OR IS HOT. KEEP OPEN FLAMES, SPARKS, AND HEAT AWAY FROM THE FUEL AND STORE FUEL IN CONTAINERS SPECIFICALLY DESIGNED FOR THAT PURPOSE. ADD FUEL OUTDOORS ONLY AND IF THE FUEL IS SPILLED, DO NOT START THE ENGINE.

  • Page 30: Safety Information Decals

    The following labels are intended to alert you to potential hazards and to provide you with important safety information. Should these decals become difficult to read or are missing from the mower, contact your Red Hawk Mower dealer for a replacement. Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915...

  • Page 31: Operating The Mower

    OPERATING THE MOWER It is recommended that before you operate the mower, you allow adequate time to fully understand the controls and operation of the equipment. When reading this manual, it is recommended that you do so with the equipment nearby for quick orientation, reference of controls and maintenance adjustments.

  • Page 32: Starting The Engine

    Starting The Engine: DANGER: DO NOT OPERATE THE ENGINE IN A CONFINED SPACE WHERE DANGEROUS CARBON MONOXIDE FUMES CAN COLLECT. CARBON DIOXIDE IS ODORLESS, TASTELESS, AND CAN BE FATAL. After going through the steps as discussed on pages (6) and (7), you are now ready to start the engine.

  • Page 33: Turning The Mower

    Turning The Mower To turn the mower in the direction you want to go, gently squeeze the side’s traction control lever (i.e. to go right, squeeze the right traction control lever; to go left, squeeze the left traction control lever). The more a particular traction control lever is squeezed, the sharper a turn the mower will make.

  • Page 34: Measuring

    CONTACT. When your Red Hawk mower is shipped from the factory, the mowing height is set at 2-1/2”. The mowing height may be raised or lowered using a combination of front wheel spacers and blade bolt assembly spacers. It is recommended that you first set your height of cut to the highest level using the blade spacers and then lower the height of cut using the front wheel spacers.
  • Page 35 Figure 6 Figure 7 Figure 8 Havener Enterprises, Inc. • 368 S. Michigan Ave. • Bradley, IL • 60915 815.935.8383 • www.havenerenterprises.com...

  • Page 36: Maintenance Schedule

    GENERAL MAINTENANCE Proper maintenance and adjustment of your Red Hawk mower is necessary to keep the mower in good and safe condition. The maintenance of the mower is the responsibility of the owner/operator and must be performed at regular intervals. When replacing any parts of servicing your mower, be sure to use only genuine Red Hawk mower replacement parts to assure quality and performance of your mower.

  • Page 37: Fuel

    Blades should be inspected on a daily basis for nicks, bends, and or excessive wear. If the blades is worn, cracked, bent, or damaged, replace with a new blade immediately before using the mower. Use only genuine Red Hawk Mower replacement blades since substitute blades may not meet Red Hawk Mower specifications and may be dangerous.

  • Page 38: Lubrication Points

    Lubrication Points To assure proper lubrication on moving parts, it is recommended that you lubricate the following components with a high-quality EP2 high temperature based grease or equivalent. Should the conditions of operation be more severe than normal, the lubrication interval may be shorter than recommended. GTR/OPE Grease is the recommended lubricant.

  • Page 39: Service Adjustments

    SERVICE ADJUSTMENTS DANGER: BEFORE MAKING ANY ADJUSTMENTS AND/OR SERVICING YOUR MOWER, MAKE SURE THE MOWER IS ON LEVEL GROUND, BLADES DISENGAGED, KEY REMOVED, AND THE ENGINE OFF WITH THE SPARK PLUG WIRE(S) REMOVED FROM THE SPARK PLUG(S) TO PREVENT ACCIDENTAL CONTACT.

  • Page 40: Engine To Blade Belt

    Engine To Blade Belt Adjustment (Refer to Figure 12) DANGER: BEFORE MAKING ANY ADJUSTMENTS AND/OR SERVICING YOUR MOWER, MAKE SURE THE MOWER IS ON LEVEL GROUND, BLADES DISENGAGED, KEY REMOVED, AND THE ENGINE OFF WITH THE SPARK PLUG WIRE(S) REMOVED FROM THE SPARK PLUG(S) TO PREVENT ACCIDENTAL CONTACT. IF ADJUSTMENTS OR MAINTENANCE IS BEING PERFORMED AFTER OPERATION OF THE MOWER, ALLOW THE UNIT TO COOL SINCE HEAT BUILD UP COULD CAUSE SEVERE BURNS.

  • Page 41: Blade To Blade Belt

    48” Blade To Blade Belt Adjustment: (Refer to figure 13) 1. Remove the deck cover. 2. With approximately 10 lbs. of pressure being applied on the blade to blade belt, midway between the pulleys, the belt should move approximately 1/2”. 3.

  • Page 42: Troubleshooting Guide

    TROUBLE SHOOTING Problem Possible Cause Solution Engine Does Not Start Key in the OFF position Turn key to ON Transmission shift lever not in the Move lever into the neutral neutral position (Page 10). Blade control not in the OFF position Move blade control lever to OFF Fuel tank empty Fill fuel tank...
  • Page 43 TROUBLE SHOOTING Problem Possible Cause Solution Mower Does Not Move Transmission is in neutral Move transmission lever (page 9) When Traction Levers Engine to transmission belt loose Check and adjust (page 17) Are Released Incorrect drive wheel belt adjustment Check and adjust (page 17) Drive belts worn or damaged Check and replace if necessary Mower Pulls To One Side...
  • Page 45 City: ___________________________________ State: _________ Zip: ___________________ Phone Number ____________________________ Fax Number:_____________________________ Date Purchased: _________________________ Email Address:___________________________ DEALER INFORMATION Authorized Red Hawk Mower Dealer Name:______________________________________________ Mailing Address: ___________________________________________________________________ City: ___________________________________ State: _________ Zip: ___________________ PRODUCT INFORMATION Model Number ____________________________ Serial Number: __________________________...
  • Page 46 NOTES _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________...
  • Page 47 NOTES _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________...
  • Page 48 Havener Enterprises’ Complete Line Of Turf Care Products • One wheel, two wheel, and swivel caster wheel sulkies • Sit down sulky Equipment Guard • Powder coated trimmer/brushcutter racks, water cooler racks,back pack blower racks, multi-purpose racks and hand tool racks •...
