Rugged Tablet
Power Button*
Screen Brightness
Buttons
Kensington lock
Left Side
Back Side
Notes:
(1) Press F12 key at system startup
with a keyboard connected to
enter Boot Priority Menu
(2) Press DEL key at system startup
with a keyboard connected to
enter BIOS
Programmable Button
Front
Bottom
Barcode Scanner (if equipped)
Speaker
Front Camera
· Camera/Barcode Trigger
light Sensor
Microphone
Camera Flash
Battery
Right Side
DC Jack
*Special Function Press
Power Button
Windows Start Button
CNTL
Battery Release lock
DATALUX TM110 Tablet
SIM slot uses
standard SIM
or 2FF Size
SIM Slot
USB 3.0
USB 3.0
Audio Combo Jack
+
=
+
+
ALT
DEL
®
