Summary of Contents for Emtech Electronics IA-250
- Page 1 IA-250 2 Ch. Mixer / 20W Class D Amp 09/2008 Emtech Electronics, Inc. 1126 N. 1200 West, Orem, Utah 84057 1-866-200-2878 801-426-8334 (fax)
- Page 2 IA-250 2 Ch. Mixer/20W Class D Amp The IA-250 is a two channel mic/line audio mixer, and 20W Class D amplifier mounted in a 3-gang in-wall box. It was designed to be compact and easy to operate, while providing high quality sound reinforcement for a small room.
- Page 3 IA-250. Step One: Locate the mic/line selector switches on the back of the IA-250. The mic/line selector switches are the two bottom switches on the printed circuit board (see figure 2 below). Select the input for each mixer channel by choosing between mic or line.
- Page 4 (see figure 1 above). The power ground connection goes to pin 1, and the +24Vdc goes to pin 2, as shown in the figure 1 illustration. The IA-250 is supplied with a dedicated +24Vdc regulated power supply. The ground wire on the power supply has lettering printed down the length of the wire.
- Page 5 Weight ..............1 lbs. Warranty Emtech Electronics, Inc. warrants the IA-250 for a period of one year, from the original date of purchase, against defects in parts and workmanship. If a defect occurs, the unit will be repaired or replaced, at our option, free of all charges if delivered prepaid to the factory.
- Page 6 IA-250 2 Ch. Mixer/20W Class D Amp ©2008, Emtech Electronics, Inc. All rights reserved.
